Brand:Schneider PLC Item No.: TM2AMI4LT Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM2AMI4LT Analog Input Module is a compact expansion module designed to enhance the analog measurement capability of Schneider Electric Modicon automation systems. Supporting multiple input types including voltage, current, and temperature signals, it provides engineers with a flexible solution for connecting industrial sensors and monitoring devices.
Built for machine automation and industrial control applications, the TM2AMI4LT combines dependable signal processing, modular installation, and versatile sensor compatibility. Its integration with Modicon controller platforms makes it a practical choice for expanding existing automation systems while maintaining reliable data acquisition performance.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM2AMI4LT
Module Type
Analog Input Module
Product Family
Modicon TM2
Compatible Controllers
Modicon M238 / Twido / Advantys OTB
Number of Inputs
4 Analog Inputs
Input Type
Voltage / Current / Temperature
Voltage Input Range
0...10 V DC
Current Input Range
0...20 mA
Temperature Input
PT100, PT1000, Ni100, Ni1000
Input Type
Non-differential
Resolution
12 bits (4096 points)
Conversion Type
Sigma-Delta ADC
Connection Type
Removable Screw Terminal
Power Supply
24 V DC
Internal Current Consumption
50 mA at 5 V DC
External Current Consumption
60 mA at 24 V DC
Mounting Method
DIN Rail Mount
Dimensions
Approx. 23.65 × 73.3 × 90 mm
Weight
Approx. 85 g
Recommended Companion Models
Model
Product Name
TM2AMI2LT
Schneider Modicon TM2 2-Channel Analog Input Module
TM2AMI8HT
Schneider Modicon TM2 8-Channel Analog Input Module
TM2AMM3HT
Schneider Modicon TM2 Analog Mixed Input/Output Module
TM2ARI8LT
Schneider Modicon TM2 Temperature Input Module
Frequently Selected Alternatives
Model
Product Name
TM3AI4
Schneider Modicon TM3 4-Channel Analog Input Module
TM3AI8
Schneider Modicon TM3 8-Channel Analog Input Module
BMXAMI0410
Schneider Modicon M340 4-Channel Analog Input Module
BMXAMI0810
Schneider Modicon M340 8-Channel Analog Input Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon automation platforms requiring accurate analog signal acquisition for voltage, current, and temperature measurement applications.
• Suitable for machine automation, process monitoring, temperature control, and industrial equipment applications where reliable analog data collection is required.
• Ideal for Modicon M238, Twido, and compatible Advantys OTB automation systems that need additional analog input capacity for sensors and field instruments.
Key Strengths at a Glance
• Provides four analog input channels supporting voltage, current, and temperature sensor signals for flexible industrial measurement applications.
• Supports 0...10 V voltage input, 0...20 mA current input, and PT100/PT1000/Ni100/Ni1000 temperature probe connection for diversified sensor integration.
• Delivers 12-bit analog conversion resolution with stable measurement accuracy for improved process monitoring performance.
• Uses removable screw terminal connections, simplifying wiring installation, maintenance, and field replacement procedures.
Technical FAQs
1. What type of module is the Schneider TM2AMI4LT?
The Schneider TM2AMI4LT is an analog input expansion module designed for Modicon automation controllers.
2. How many analog input channels does the TM2AMI4LT provide?
The TM2AMI4LT provides four analog input channels for connecting compatible industrial sensors.
3. What signal types are supported by the TM2AMI4LT?
The module supports 0...10 V voltage signals, 0...20 mA current signals, and temperature sensors including PT100, PT1000, Ni100, and Ni1000 probes.
4. What is the resolution of the TM2AMI4LT analog conversion?
The module provides 12-bit analog resolution, allowing input values to be processed across 4096 measurement points.
5. Which Schneider Electric controllers are compatible with the TM2AMI4LT?
The module is designed for use with compatible Modicon platforms including M238 controllers and related TM2 expansion architectures.
6. Does the TM2AMI4LT require external configuration software?
Yes. Input channel types and operating parameters are configured through compatible Schneider Electric programming software.
7. What type of connection terminal does the TM2AMI4LT use?
The module uses a removable screw terminal block for field wiring connections.
8. Can each input channel be configured independently?
Temperature probe configurations can be selected individually, while voltage/current input configurations follow the module operating settings.
9. What applications commonly use the TM2AMI4LT?
It is commonly used for temperature monitoring, pressure measurement, flow measurement, level detection, and industrial sensor integration.
10. How does the TM2AMI4LT improve automation systems?
The module expands controller measurement capability by allowing precise analog field signals to be integrated into PLC-based control systems.
