Brand:Schneider PLC Item No.:TM2AMM6HT Product Origin:France Product Dimensions:23.5 × 70 × 90 mm Product Weight:0.085 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM2AMM6HT Analog Mixed I/O Module is a flexible expansion module designed for Modicon M238 controller platforms. Combining four analog inputs with two analog outputs, it provides a practical solution for machine builders requiring both measurement and control functions within a compact automation architecture.
Built for industrial applications, the TM2AMM6HT supports commonly used voltage and current signals, enabling seamless connection with sensors, transmitters, valves, drives, and other analog devices. Its modular design helps engineers enhance system capability while maintaining efficient cabinet space utilization.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM2AMM6HT
Product Family
Modicon TM2
Module Type
Analog Mixed I/O Module
Compatible Controller
Modicon M238
Analog Inputs
4 Channels
Analog Outputs
2 Channels
Input Signal Type
0...10 V DC / 4...20 mA
Output Signal Type
0...10 V DC / 4...20 mA
Input Type
Non-differential
Output Type
Voltage / Current
Resolution
12 bits (4096 points)
Conversion Type
Sigma-Delta ADC
Connection Type
Removable Screw Terminal Block
Power Supply
24 V DC
Supply Voltage Range
19.2...30 V DC
Internal Current Consumption
60 mA at 5 V DC
External Current Consumption
80 mA at 24 V DC
Mounting Method
DIN Rail Mount
Dimensions
Approx. 23.5 × 70 × 90 mm
Weight
Approx. 0.085 kg
Recommended Companion Models
Model
Product Name
TM2AMI4LT
Schneider Modicon TM2 4-Channel Analog Input Module
TM2AOS4LT
Schneider Modicon TM2 4-Channel Analog Output Module
TM2AMM3HT
Schneider Modicon TM2 Analog Mixed Input/Output Module
TM2ARI8HT
Schneider Modicon TM2 8-Channel Temperature Input Module
Frequently Selected Alternatives
Model
Product Name
TM3AI4
Schneider Modicon TM3 4-Channel Analog Input Module
TM3AM6
Schneider Modicon TM3 Analog Mixed I/O Expansion Module
BMXAMM0600
Schneider Modicon X80 Analog Mixed I/O Module
BMXAMI0410
Schneider Modicon M340 4-Channel Analog Input Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon M238 automation systems requiring combined analog input and output capabilities for flexible machine control applications.
• Suitable for packaging equipment, conveying systems, process monitoring, temperature regulation, and industrial machinery where accurate analog signal processing is required.
• Ideal for expanding PLC control systems with both sensor acquisition and actuator regulation functions through a single compact analog expansion module.
Key Strengths at a Glance
• Provides four analog input channels and two analog output channels, supporting both voltage and current signal processing for versatile automation integration.
• Supports 0...10 V DC voltage signals and 4...20 mA current signals, allowing connection with a wide range of industrial transmitters and control devices.
• Delivers 12-bit input and output resolution, improving measurement stability and control accuracy in industrial applications.
• Features removable screw terminal wiring and compact DIN rail mounting, simplifying installation, maintenance, and system expansion.
Technical FAQs
1. What type of module is the Schneider TM2AMM6HT?
The Schneider TM2AMM6HT is an analog mixed I/O expansion module designed for Modicon M238 logic controller systems.
2. How many analog channels does the TM2AMM6HT provide?
The module provides four analog inputs and two analog outputs for combined signal acquisition and control operations.
3. What input signals are supported by the TM2AMM6HT?
The analog inputs support 0...10 V DC voltage signals and 4...20 mA current signals for industrial sensor connections.
4. What output signals are supported by the TM2AMM6HT?
The analog outputs support 0...10 V DC voltage output and 4...20 mA current output for controlling compatible field devices.
5. What is the resolution of the TM2AMM6HT?
The module provides 12-bit analog conversion resolution with 4096 available measurement increments for input and output processing.
6. Which controllers are compatible with the TM2AMM6HT?
The module is designed for Modicon M238 logic controllers and is also compatible with certain Twido and Advantys OTB automation architectures.
7. Does the TM2AMM6HT require configuration software?
Yes. Channel settings and analog operating parameters are configured through compatible Schneider Electric programming software.
8. What type of connection does the TM2AMM6HT use?
The module uses a removable screw terminal block for convenient field wiring and maintenance operations.
9. What applications commonly use the TM2AMM6HT?
It is commonly used for pressure control, flow regulation, level monitoring, speed references, and analog actuator control in industrial machines.
10. How does the TM2AMM6HT improve automation systems?
It expands controller functionality by allowing PLC systems to both collect analog sensor data and generate analog control signals for external equipment.
