Brand:Schneider PLC Item No.:TM2AMO2HTN Product Origin:France Product Dimensions:23.65 × 73.3 × 90 mm Product Weight:0.10 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM2AMO2HTN Analog Output Module is a compact expansion module developed for Modicon automation platforms requiring additional analog control capability. With two configurable analog output channels, it enables PLC systems to interface with a wide range of industrial devices requiring voltage or current command signals.
Designed for machine builders and automation engineers, the TM2AMO2HTN provides dependable signal output performance in a compact modular format. Its compatibility with Schneider Electric controller architectures makes it a practical solution for enhancing automation flexibility and improving system control accuracy.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM2AMO2HTN
Product Family
Modicon TM2
Module Type
Analog Output Module
Compatible Controller
Modicon M238
Number of Outputs
2 Analog Outputs
Output Type
Voltage / Current
Voltage Output Range
-10...+10 V DC / 0...10 V DC
Current Output Range
0...20 mA / 4...20 mA
Output Resolution
12 bits
Conversion Type
Digital-to-Analog Conversion
Connection Type
Removable Screw Terminal Block
Power Supply
Supplied through Ribbon Cable
Rated Supply Voltage
24 V DC
Supply Voltage Range
19.2...30 V DC
Mounting Method
DIN Rail Mount
Status Indicators
PWR / ERR LED
Dimensions
Approx. 23.65 × 73.3 × 90 mm
Weight
Approx. 0.10 kg
Recommended Companion Models
Model
Product Name
TM2AMI4LT
Schneider Modicon TM2 4-Channel Analog Input Module
TM2AMM6HT
Schneider Modicon TM2 Analog Mixed Input/Output Module
TM2AMO1HT
Schneider Modicon TM2 Single Analog Output Module
TM2AMI4HTN
Schneider Modicon TM2 4-Channel Analog Input Module
Frequently Selected Alternatives
Model
Product Name
TM3AQ2
Schneider Modicon TM3 2-Channel Analog Output Module
TM3AQ4
Schneider Modicon TM3 4-Channel Analog Output Module
BMXAMO0210
Schneider Modicon X80 2-Channel Analog Output Module
BMXAMO0410
Schneider Modicon X80 4-Channel Analog Output Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon automation systems requiring accurate analog output control for actuators, drives, valves, and industrial regulation equipment.
• Suitable for machine automation, process control, motion-related applications, and industrial equipment where precise voltage or current output signals are required.
• Ideal for expanding Modicon M238 controller capabilities by providing additional analog output channels for external field devices and control components.
Key Strengths at a Glance
• Provides two configurable analog output channels supporting voltage and current output modes for flexible industrial applications.
• Supports -10...+10 V DC, 0...10 V DC, 0...20 mA, and 4...20 mA output ranges to accommodate different actuator and control requirements.
• Uses removable screw terminal connections and compact expansion design, allowing convenient wiring, installation, and maintenance.
• Provides reliable analog signal generation for integrating PLC systems with variable speed drives, control valves, and proportional devices.
Technical FAQs
1. What type of module is the Schneider TM2AMO2HTN?
The Schneider TM2AMO2HTN is a two-channel analog output expansion module designed for Modicon M238 controller systems.
2. How many analog output channels does the TM2AMO2HTN provide?
The module provides two analog output channels for controlling external analog devices.
3. What output signal types are supported by the TM2AMO2HTN?
The module supports voltage outputs of -10...+10 V DC and 0...10 V DC, as well as current outputs of 0...20 mA and 4...20 mA.
4. Which Schneider Electric controllers are compatible with the TM2AMO2HTN?
The module is designed for Modicon M238 controller platforms and compatible TM2 expansion architectures.
5. Does the TM2AMO2HTN require separate programming software?
The module parameters are configured through compatible Schneider Electric controller programming environments, including EcoStruxure Machine Expert configurations.
6. How are the output channels configured?
The output channels can be configured according to the required signal type, including voltage or current operation modes.
7. What type of wiring connection does the TM2AMO2HTN use?
The module uses removable screw terminal blocks for field device connections.
8. Can the TM2AMO2HTN control external actuators?
Yes, it can provide analog control signals for compatible actuators, drives, valves, and industrial devices.
9. What applications commonly use the TM2AMO2HTN?
The module is commonly used in speed reference control, valve positioning, pressure regulation, temperature control, and industrial machine automation.
10. What advantage does an analog output module provide in a PLC system?
It allows PLC controllers to convert digital control commands into continuous analog signals for precise regulation of external equipment.
