Brand:Schneider PLC Item No.:TM2AVO2HT Product Origin:France Product Dimensions:109 × 64 × 58 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM2AVO2HT Analog Output Module is a compact expansion module designed to enhance the analog control capability of Schneider Electric Modicon automation platforms. With two voltage output channels and ±10 V DC signal support, it provides a dependable interface between PLC systems and external analog-controlled equipment.
Engineered for industrial machine builders and automation professionals, the TM2AVO2HT offers stable signal conversion, modular installation, and efficient cabinet integration. It is well suited for applications requiring accurate analog commands, including drive control, actuator positioning, and process regulation.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM2AVO2HT
Product Family
Modicon TM2
Module Type
Analog Output Module
Compatible Controller
Modicon M238 Logic Controller
Compatible Platforms
Twido / Advantys OTB
Number of Outputs
2 Analog Outputs
Output Signal Type
Voltage
Output Range
±10 V DC
Resolution
11 bits + sign
LSB Value
±9.8 mV
Load Type
Resistive
Maximum Load Impedance
≤3000 Ω
Conversion Time
2 ms + 1 controller cycle
Stabilization Time
2 ms
Measurement Error
±0.5% FS at 25°C
Connection Type
Removable Screw Terminal Block
Supply Voltage
24 V DC
Supply Voltage Range
19.2–30 V DC
Current Consumption
Approx. 60 mA
Mounting Method
DIN Rail Mount
Dimensions
Approx. 23.5 × 70 × 90 mm
Weight
Approx. 0.085 kg
Recommended Companion Models
Model
Product Name
TM2AMO1HT
Schneider Modicon TM2 Single Analog Output Module
TM2AMM6HT
Schneider Modicon TM2 Analog Mixed Input/Output Module
TM2AMI4HTN
Schneider Modicon TM2 4-Channel Analog Input Module
TM2ARI8LT
Schneider Modicon TM2 8-Channel Temperature Input Module
Frequently Selected Alternatives
Model
Product Name
TM3AQ2
Schneider Modicon TM3 2-Channel Analog Output Module
TM3AQ4
Schneider Modicon TM3 4-Channel Analog Output Module
BMXAMO0210
Schneider Modicon X80 2-Channel Analog Output Module
BMXAMO0410
Schneider Modicon X80 4-Channel Analog Output Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon automation systems requiring reliable analog voltage output control for industrial actuators, drives, and regulation devices.
• Suitable for machine automation, motion control, process adjustment, and equipment applications where precise ±10 V DC control signals are required.
• Ideal for expanding Modicon M238 controller capabilities by adding dedicated analog output channels for external control devices such as variable speed drives, proportional valves, and signal converters.
Key Strengths at a Glance
• Provides two analog voltage output channels with ±10 V DC signal capability, supporting flexible industrial control applications.
• Delivers 11-bit resolution plus sign, allowing accurate voltage regulation for demanding automation processes.
• Features removable screw terminal wiring, enabling convenient installation, troubleshooting, and maintenance in control cabinets.
• Supports Modicon M238, Twido, and Advantys OTB compatible architectures, providing a practical expansion option for existing automation systems.
Technical FAQs
1. What type of module is the Schneider TM2AVO2HT?
The Schneider TM2AVO2HT is an analog output expansion module designed for Modicon automation controllers.
2. How many analog output channels does the TM2AVO2HT provide?
The module provides two analog voltage output channels for controlling compatible external devices.
3. What output signal does the TM2AVO2HT support?
The module supports ±10 V DC analog voltage output signals.
4. What is the resolution of the TM2AVO2HT output signal?
The module provides 11-bit resolution plus sign for accurate analog output conversion.
5. Which Schneider Electric controllers are compatible with the TM2AVO2HT?
The module is compatible with Modicon M238 logic controllers and related TM2 expansion architectures.
6. Can the TM2AVO2HT control variable speed drives?
Yes. The module can provide analog voltage references commonly used for compatible drives and proportional control devices.
7. What type of connection does the TM2AVO2HT use?
The module uses a removable screw terminal block for field wiring connections.
8. Does the TM2AVO2HT require external configuration?
Yes. Output channel parameters are configured through compatible Schneider Electric programming environments.
9. What applications commonly use the TM2AVO2HT?
It is commonly used in speed reference control, valve positioning, actuator regulation, and industrial process adjustment systems.
10. What advantage does the TM2AVO2HT provide in automation systems?
It enables PLC controllers to generate precise analog control signals for integrating digital automation systems with analog field equipment.
