Brand:Schneider PLC Item No.:TM5ACNB1 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACNB1 Bus Base Module is an essential component of the Modicon TM5 modular automation platform, providing a secure connection foundation for fieldbus interface modules and interface power distribution solutions. Designed for demanding industrial environments, it helps create reliable and expandable automation architectures for complex machine control applications.
With its compact modular design and compatibility with Schneider Electric controller platforms, the TM5ACNB1 simplifies system expansion while maintaining stable bus communication and power distribution performance. It is widely suited for machine builders seeking efficient, flexible, and maintainable control system designs.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5ACNB1
Product Family
Modicon TM5
Module Type
Bus Base Module
Accessory Type
Communication Accessory
Function
Fieldbus Interface Module Base
Compatible Modules
TM5NCO1 / TM5NS31 / TM5SPS3
Compatible Controllers
Modicon M258 / LMC058 / LMC078
Rated Voltage
24 V DC
Color
White
Installation Method
DIN Rail Mount
Protective Plates
Included (2 pcs)
Application
TM5 Modular I/O Expansion
Dimensions
Approx. 23.65 × 73.3 × 90 mm
Weight
Approx. 0.02 kg
Recommended Companion Models
Model
Product Name
TM5NS31
Schneider Modicon TM5 SERCOS III Interface Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing a reliable mounting and connection foundation for fieldbus interface modules and interface power distribution components.
• Suitable for advanced machine automation applications using Modicon M258, LMC058, and LMC078 controller platforms where distributed I/O expansion and communication integration are required.
• Ideal for industrial control cabinets, motion applications, and complex machine architectures requiring stable TM5 bus communication and modular system expansion.
Key Strengths at a Glance
• Provides a dedicated bus base interface for installing TM5 fieldbus interface modules and Interface Power Distribution Modules (IPDM).
• Supports 24 V DC power distribution, ensuring dependable operation of connected TM5 communication and power modules.
• Enables flexible modular system configuration, helping engineers build scalable automation solutions with simplified cabinet integration.
• Supplied with protective plates to enhance installation safety and provide a more secure modular assembly structure.
Technical FAQs
1. What type of module is the Schneider TM5ACNB1?
The Schneider TM5ACNB1 is a Modicon TM5 bus base module used for fieldbus interface modules and interface power distribution components.
2. What is the main function of the TM5ACNB1?
The TM5ACNB1 provides the mechanical mounting structure and electrical bus connection between TM5 system components.
3. Which Schneider Electric products are compatible with the TM5ACNB1?
The module is compatible with TM5NCO1 interface modules, TM5NS31 interface modules, and TM5SPS3 power supply modules.
4. Which controller platforms can use the TM5ACNB1?
The TM5ACNB1 is designed for Modicon M258, LMC058, and LMC078 controller systems.
5. What voltage does the TM5ACNB1 support?
The module operates with a rated 24 V DC supply system.
6. Is the TM5ACNB1 a communication module?
No. The TM5ACNB1 is a bus base accessory that supports the installation of communication interface modules but does not independently provide communication functions.
7. Can the TM5ACNB1 be used for fieldbus expansion?
Yes. It is designed as the mounting and connection base for TM5 fieldbus interface solutions.
8. Does the TM5ACNB1 require configuration software?
No. The bus base itself does not require programming or software configuration.
9. What type of installation does the TM5ACNB1 use?
The module is installed as part of a modular TM5 assembly, typically mounted on a DIN rail within an industrial control cabinet.
10. What advantage does the TM5ACNB1 provide in automation systems?
It improves system flexibility by allowing communication interfaces and power distribution components to be integrated into scalable TM5 automation architectures.
