Brand:Schneider PLC Item No.: TM5ACTB06 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACTB06 Terminal Block Module is a dedicated connection accessory for the Modicon TM5 modular I/O platform. Designed for 24 V DC I/O applications, it provides a practical and reliable interface between field wiring and TM5 electronic modules.
With its removable six-pin structure, spring-clamp connection technology, and compact modular format, the TM5ACTB06 helps engineers create cleaner control cabinets and more efficient automation installations. It is an essential component for maintaining flexibility and serviceability in modern industrial control systems.
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing a reliable removable wiring interface for 24 V DC I/O modules and TM5 transmitter modules.
• Suitable for distributed automation systems, machine control cabinets, and modular PLC installations where flexible field wiring and quick maintenance are required.
• Ideal for Modicon M258, LMC058, and related TM5 architectures that require compact, organized, and dependable connection solutions for digital and analog I/O modules.
Key Strengths at a Glance
• Provides a 6-pin removable terminal connection designed specifically for 24 V DC TM5 I/O modules and TM5SBET1 transmitter modules.
• Supports clear terminal identification and testing access, helping simplify commissioning, troubleshooting, and routine maintenance.
• Offers a compact modular design that helps reduce cabinet wiring complexity while maintaining reliable electrical connections in industrial environments.
Technical FAQs
1. What type of component is the Schneider TM5ACTB06?
The Schneider TM5ACTB06 is a removable 6-pin terminal block accessory used with Modicon TM5 modular I/O systems.
2. What is the primary function of the TM5ACTB06?
The module provides the electrical connection interface between TM5 I/O electronic modules and external field wiring.
3. Which Schneider Electric modules use the TM5ACTB06?
The TM5ACTB06 is designed for 24 V DC I/O modules and the TM5SBET1 transmitter module within the Modicon TM5 system.
4. How many connection points does the TM5ACTB06 provide?
The terminal block provides six connection points for compatible TM5 modules.
5. What wiring technology is used by the TM5ACTB06?
The TM5ACTB06 uses spring-clamp push-in terminal technology for secure and efficient wiring.
6. What is the maximum current capacity of the TM5ACTB06 connector?
The terminal block supports up to 10 A maximum per connector, depending on the connected module specifications.
7. Does the TM5ACTB06 require software configuration?
No. The TM5ACTB06 is a passive connection accessory and does not require programming or software configuration.
8. Can the TM5ACTB06 be replaced without changing the electronic module?
Yes. The removable terminal design allows convenient replacement while maintaining the installed TM5 module configuration.
9. What type of automation systems use the TM5ACTB06?
It is commonly used in modular PLC systems, distributed I/O stations, machine automation equipment, and industrial control panels.
10. What maintenance benefits does the TM5ACTB06 provide?
It simplifies wiring management, reduces replacement time, and improves service efficiency during system maintenance.
