Brand:Schneider PLC Item No.:TM5ACTB12 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACTB12 Terminal Block Module is a dedicated connection accessory for the Modicon TM5 modular I/O platform. Designed with twelve contacts and a removable structure, it provides a reliable interface between TM5 electronic modules and external field devices.
Engineered for industrial automation environments, the TM5ACTB12 helps simplify cabinet wiring, improve system serviceability, and support flexible distributed I/O configurations. Its modular design makes it a practical choice for machine builders and control engineers developing scalable automation solutions.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5ACTB12
Product Family
Modicon TM5
Module Type
Terminal Block Module
Accessory Type
Connection Accessory
Number of Contacts
12 Contacts
Compatible Modules
24 V DC I/O Modules / Common Distribution Modules / Transmitter Modules
Terminal Technology
Spring-Clamp Push-In Terminal
Color
White
Maximum Voltage
300 V
Maximum Current
10 A per Connector
Contact Resistance
≤ 5 mΩ
Wire Connection Range
0.08...2.5 mm²
Installation Method
Plug-In Terminal Connection
Application
TM5 Modular I/O Wiring
Dimensions
Approx. 30 × 15 × 90 mm
Weight
Approx. 0.02 kg
Recommended Companion Models
Model
Product Name
TM5ACBN1
Schneider Modicon TM5 Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
TM5NCO1
Schneider Modicon TM5 CANopen Interface Module
TM5ACTB12PS
Schneider Modicon TM5 12-Contact Power Distribution Terminal Block
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing a dependable 12-contact wiring interface for distributed automation and industrial control applications.
• Suitable for machine automation cabinets, remote I/O stations, and modular PLC systems where flexible field wiring, quick maintenance, and reliable signal connections are required.
• Ideal for Modicon M258, LMC058, and LMC078 automation platforms, supporting 24 V DC I/O modules, Common Distribution Modules, and transmitter modules within TM5 architectures.
Key Strengths at a Glance
• Provides a 12-contact removable terminal interface designed for 24 V DC I/O modules, Common Distribution Modules, and TM5 transmitter modules.
• Uses spring-clamp push-in terminal technology, enabling fast tool-free wiring, secure connections, and simplified maintenance procedures.
• Supports clear terminal labeling and test access points, helping engineers improve commissioning efficiency and troubleshooting convenience.
• Offers a compact modular design that enhances cabinet organization and supports scalable TM5 distributed I/O system configurations.
Technical FAQs
1. What type of component is the Schneider TM5ACTB12?
The Schneider TM5ACTB12 is a 12-contact terminal block accessory designed for the Modicon TM5 modular I/O system.
2. What is the main function of the TM5ACTB12?
The TM5ACTB12 provides the electrical connection interface between TM5 electronic modules and external field wiring.
3. Which Schneider Electric modules are compatible with the TM5ACTB12?
The TM5ACTB12 is designed for 24 V DC I/O modules, Common Distribution Modules, and TM5 transmitter modules.
4. How many contacts does the TM5ACTB12 provide?
The TM5ACTB12 provides twelve terminal connection points for compatible TM5 modules.
5. What wiring technology is used by the TM5ACTB12?
The module uses spring-clamp push-in terminal technology for secure and efficient electrical connections.
6. Does the TM5ACTB12 require software configuration?
No. The TM5ACTB12 is a passive connection accessory and does not require programming or parameter configuration.
7. What is the maximum electrical rating of the TM5ACTB12 terminal connection?
The terminal block supports up to 300 V maximum voltage and 10 A maximum current per connector, depending on the connected electronic module specifications.
8. Can the TM5ACTB12 be replaced independently from the electronic module?
Yes. The removable terminal block design allows replacement or wiring changes without replacing the complete TM5 electronic module.
9. What applications commonly use the TM5ACTB12?
It is commonly used in PLC expansion systems, distributed I/O networks, industrial machinery, and automated production equipment.
10. What advantage does the TM5ACTB12 provide in automation systems?
It improves wiring flexibility, simplifies maintenance operations, and supports efficient modular control system expansion.
