Brand:Schneider PLC Item No.: TM5ACTB1210 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACTB1210 Terminal Block Module is a dedicated connection accessory for the Modicon TM5 modular I/O platform. Designed with 12 terminals, it provides a dependable wiring interface for various TM5 electronic modules used in industrial automation systems.
Engineered for machine builders and automation professionals, the TM5ACTB1210 helps create cleaner cabinet layouts, improves installation efficiency, and supports long-term system maintainability. Its compatibility with multiple TM5 module categories makes it a practical component for scalable control solutions.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5ACTB1210
Product Family
Modicon TM5
Module Type
Terminal Block Module
Accessory Type
Connection Accessory
Number of Terminals
12 Contacts
Compatible Systems
Modicon TM5 Modular I/O
Compatible Controllers
Modicon M258 / LMC058
Compatible Modules
24 V DC Discrete I/O Module / Analog I/O Module / Common Distribution Module / Remote Transmitter Module / Counter Module
Terminal Technology
Spring Terminal
Color
White
Rated Voltage
24 V DC
Installation Method
Plug-In Terminal Connection
Mounting System
TM5 Modular Assembly
Quantity per Package
10 Units
Dimensions
Approx. 13.6 × 8.1 × 2.9 cm (package reference)
Weight
Approx. 0.20 kg
Recommended Companion Models
Model
Product Name
TM5ACBM11
Schneider Modicon TM5 Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing a reliable 12-contact terminal connection solution for distributed control architectures and industrial automation equipment.
• Suitable for machine control cabinets, remote I/O expansion systems, and modular PLC installations where secure field wiring and efficient maintenance are essential.
• Ideal for Modicon M258 and LMC058 controller platforms, supporting 24 V DC discrete I/O modules, analog I/O modules, common distribution modules, remote transmitter modules, and counter modules.
Key Strengths at a Glance
• Provides 12 spring-clamp terminals for flexible connection between TM5 electronic modules and external field devices.
• Supports quick installation and replacement through a removable terminal design, reducing downtime during system maintenance.
• Compatible with multiple TM5 module types, allowing engineers to build scalable and easily serviceable automation systems.
• Offers a compact white terminal block design that integrates seamlessly into TM5 modular I/O assemblies.
Technical FAQs
1. What type of component is the Schneider TM5ACTB1210?
The Schneider TM5ACTB1210 is a Modicon TM5 12-contact terminal block accessory used for modular I/O system connections.
2. What is the main function of the TM5ACTB1210?
The TM5ACTB1210 provides the electrical interface between TM5 electronic modules and external wiring connections.
3. How many terminals does the TM5ACTB1210 provide?
The module provides twelve terminal connection points for compatible TM5 automation modules.
4. Which Schneider Electric modules are compatible with the TM5ACTB1210?
The TM5ACTB1210 is compatible with 24 V DC discrete I/O modules, analog I/O modules, common distribution modules, remote transmitter modules, and counter modules.
5. Which controller platforms use the TM5ACTB1210?
The terminal block is designed for Modicon TM5 systems used with platforms such as Modicon M258 and LMC058 controllers.
6. Does the TM5ACTB1210 require software configuration?
No. The TM5ACTB1210 is a passive terminal accessory and does not require programming or parameter configuration.
7. What connection technology does the TM5ACTB1210 use?
The module uses spring terminal technology to provide secure electrical connections for field wiring.
8. Can the TM5ACTB1210 be replaced separately from the electronic module?
Yes. Its removable terminal structure allows independent replacement without changing the complete TM5 electronic module.
9. What applications commonly use the TM5ACTB1210?
It is commonly used in PLC expansion systems, industrial machinery, automated production lines, and distributed I/O control panels.
10. What advantage does the TM5ACTB1210 provide in automation systems?
It improves wiring organization, simplifies maintenance procedures, and enhances the flexibility of TM5 modular control system designs.
