Brand:Schneider PLC Item No.:TM5ACTB16 Product Origin:France Product Dimensions:109 × 64 × 58 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACTB16 Terminal Block Module is a dedicated connection accessory developed for the Modicon TM5 modular I/O platform. Featuring 16 contacts and a compact removable design, it provides a reliable interface between electronic modules and external field devices.
Designed for demanding industrial automation environments, the TM5ACTB16 helps engineers create cleaner wiring structures, improve commissioning efficiency, and maintain flexible system configurations. Its compatibility with multiple TM5 I/O modules makes it a practical choice for machine builders and automation professionals.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5ACTB16
Product Family
Modicon TM5
Module Type
Terminal Block Module
Accessory Type
Connection Accessory
Number of Contacts
16 Contacts
Compatible Systems
Modicon TM5 Modular I/O
Compatible Controllers
Modicon M258 / LMC058
Compatible Modules
24 V DC I/O Modules / Common Distribution Modules / Transmitter Modules
Terminal Technology
Spring-Clamp Push-In Terminal
Color
White
Maximum Voltage
300 V
Maximum Current
10 A per Connector
Contact Resistance
≤ 5 mΩ
Wire Cross Section
0.08...2.5 mm² (AWG 28...14)
Mounting Method
Plug-In Terminal Connection
Installation Type
TM5 Modular Assembly
Dimensions
Approx. 12 × 3 × 1.5 cm
Weight
Approx. 0.02 kg
Recommended Companion Models
Model
Product Name
TM5ACBN1
Schneider Modicon TM5 Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
• Designed for Schneider Electric Modicon TM5 modular I/O systems, providing a 16-contact removable terminal connection solution for 24 V DC I/O modules, common distribution modules, and transmitter modules.
• Suitable for industrial automation cabinets, distributed I/O stations, and machine control systems where efficient field wiring, reliable signal transmission, and simplified maintenance are required.
• Ideal for Modicon M258 and LMC058 controller platforms, supporting flexible TM5 modular configurations in advanced machine automation applications.
Key Strengths at a Glance
• Provides 16 connection points for compatible TM5 electronic modules, allowing convenient integration of multiple field signals within compact automation assemblies.
• Uses spring-clamp push-in terminal technology, enabling fast wiring installation, secure electrical connections, and reduced maintenance time.
• Supports solid and flexible conductors with optimized wire cross-section compatibility, making it suitable for various industrial wiring requirements.
• Features a removable white terminal design that improves module replacement efficiency and helps maintain organized control cabinet layouts.
Technical FAQs
1. What type of component is the Schneider TM5ACTB16?
The Schneider TM5ACTB16 is a 16-contact terminal block accessory designed for Modicon TM5 modular I/O systems.
2. What is the main function of the TM5ACTB16?
The TM5ACTB16 provides the electrical connection interface between TM5 electronic modules and external field wiring.
3. How many terminals does the TM5ACTB16 provide?
The TM5ACTB16 provides sixteen terminal connection points for compatible TM5 modules.
4. Which Schneider Electric modules are compatible with the TM5ACTB16?
The TM5ACTB16 is designed for 24 V DC I/O modules, Common Distribution Modules, and transmitter modules within the Modicon TM5 system.
5. Which controller platforms support the TM5ACTB16?
The TM5ACTB16 is compatible with Modicon M258 and LMC058 automation platforms.
6. Does the TM5ACTB16 require software configuration?
No. The TM5ACTB16 is a passive terminal accessory and does not require programming or parameter configuration.
7. What connection technology does the TM5ACTB16 use?
The module uses spring-clamp push-in terminals for reliable field wiring connections.
8. What is the maximum current capacity of the TM5ACTB16?
The TM5ACTB16 supports up to 10 A maximum per connector, depending on the connected electronic module specifications.
9. Can the TM5ACTB16 be replaced separately from the electronic module?
Yes. The removable terminal structure allows replacement without changing the complete TM5 electronic module assembly.
10. What advantage does the TM5ACTB16 provide in automation systems?
It improves wiring flexibility, simplifies maintenance procedures, and supports scalable TM5 modular I/O system expansion.
