Brand:Schneider PLC Item No.:TM5C12D18T Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5C12D18T Compact I/O Module is a versatile digital expansion module developed for the Modicon TM5 automation platform. Combining digital input and transistor output capabilities, it provides a practical solution for machine builders requiring compact yet powerful I/O integration.
Engineered for modern industrial automation environments, the TM5C12D18T helps optimize control cabinet layouts while maintaining reliable communication between field devices and PLC systems. Its compact structure, modular installation method, and flexible I/O capability make it a strong choice for automated machinery, production systems, and distributed control applications.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5C12D18T
Product Family
Modicon TM5
Module Type
Compact I/O Module
Input Type
Digital Input
Output Type
Digital Transistor Output
Number of Digital Inputs
12 Channels
Number of Digital Outputs
6 Channels
Input Voltage
24 V DC
Output Voltage
24 V DC
Output Technology
Transistor Source Output
Controller Compatibility
Modicon M258 / LMC058
Installation Method
DIN Rail Mount
Connection Type
Removable Spring Terminal
Application
Machine Automation / Distributed I/O
Protection Level
IP20
Dimensions
Approx. 99 × 62.5 × 75 mm
Weight
Approx. 0.24 kg
Recommended Companion Models
Model
Product Name
TM5C24D18T
Schneider Modicon TM5 Compact Digital I/O Module
TM5C12D8T
Schneider Modicon TM5 Compact Digital Input/Output Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
• Designed for Schneider Electric Modicon TM5 compact I/O systems, providing a high-density mixed digital I/O solution for machine automation, packaging equipment, and distributed control applications.
• Suitable for industrial control systems that require compact installation, flexible signal processing, and efficient integration with Modicon M258 and LMC058 controller platforms.
• Ideal for automated machinery, production lines, and modular PLC architectures where multiple digital input and transistor output channels are needed within a space-saving design.
Key Strengths at a Glance
• Combines digital input and transistor output functions in a single compact TM5 module, reducing cabinet space requirements and simplifying system architecture.
• Provides multiple 24 V DC signal channels for connecting sensors, actuators, and machine control devices in industrial automation environments.
• Supports modular TM5 expansion concepts with removable spring terminals and DIN rail installation, improving wiring efficiency and maintenance convenience.
• Delivers reliable signal handling for demanding automation applications requiring fast response and flexible I/O configuration.
Technical FAQs
1. What type of module is the Schneider TM5C12D18T?
The Schneider TM5C12D18T is a Modicon TM5 Compact I/O Module combining digital input and digital transistor output functions.
2. What is the main function of the TM5C12D18T?
The module provides field signal acquisition and actuator control by processing digital input signals and driving transistor-based digital outputs.
3. How many input and output channels does the TM5C12D18T provide?
The TM5C12D18T provides 12 digital inputs and 6 digital transistor outputs.
4. What voltage level does the TM5C12D18T use?
The module operates with a 24 V DC I/O power supply system for industrial control applications.
5. Which Schneider Electric controllers are compatible with the TM5C12D18T?
The TM5C12D18T is designed for use with Modicon TM5 automation systems, including controller platforms such as Modicon M258 and LMC058.
6. Is the TM5C12D18T an analog I/O module?
No. The TM5C12D18T is a digital I/O module and does not provide analog input or output channels.
7. What type of output technology does the TM5C12D18T use?
The module uses transistor-based digital outputs designed for controlling compatible DC loads.
8. Does the TM5C12D18T require additional software configuration?
Yes. The module is configured through Schneider Electric automation software when integrated into a TM5 controller system.
9. What types of devices can connect to the TM5C12D18T?
The module can connect to digital sensors, switches, proximity detectors, solenoid valves, indicators, and other compatible DC field devices.
10. What advantages does the TM5C12D18T provide compared with separate I/O modules?
It combines multiple I/O functions in one compact module, helping reduce wiring complexity and improve cabinet space utilization.
