Brand:Schneider PLC Item No.:TM5NCO1 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5NCO1 CANopen Communication Module is a dedicated fieldbus interface solution developed for the Modicon TM5 modular I/O platform. It enables TM5 distributed I/O islands to connect with CANopen-based automation networks, providing a reliable communication bridge for industrial control applications.
Designed for modern machine automation environments, the TM5NCO1 helps simplify distributed system architectures by allowing remote I/O expansion closer to field devices. Its compact modular construction, industrial CANopen connectivity, and compatibility with Schneider Electric controller platforms make it a practical choice for machine builders seeking flexible and scalable automation solutions.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5NCO1
Product Family
Modicon TM5
Module Type
CANopen Communication Module
Communication Interface
CANopen Fieldbus Interface
Supported Protocol
CANopen
Connector Type
SUB-D 9 Male
Communication Speed
10 kbit/s to 1000 kbit/s
Compatible Controllers
Modicon M258 / LMC058 / LMC078
Communication Isolation
Isolated CAN Interface
Power Consumption
300 mA
Power Dissipation
1.5 W
Installation Method
DIN Rail Mount
Connection Type
Removable Spring Terminal Block
Protection Rating
IP20
Mounting Position
TM5 Modular System
Dimensions
Approx. 99 × 62.5 × 75 mm
Weight
Approx. 0.05 kg
Recommended Companion Models
Model
Product Name
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
TM5ACBN1
Schneider Modicon TM5 Bus Base Module
TM5ACTB12PS
Schneider Modicon TM5 Power Distribution Terminal Block Module
Schneider Modicon TM5 Serial Communication Interface Module
TM5SBET7
Schneider Modicon TM5 Ethernet Interface Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 distributed I/O systems, providing a CANopen fieldbus interface that enables remote I/O islands to communicate with Modicon controllers in advanced automation architectures.
• Suitable for packaging machinery, material handling systems, production equipment, and machine control applications where flexible distributed I/O expansion and reliable field communication are required.
• Ideal for industrial installations using Modicon M258, LMC058, and LMC078 controllers, allowing engineers to build scalable CANopen-based automation networks with efficient cabinet integration.
Key Strengths at a Glance
• Provides CANopen communication capability for Modicon TM5 remote I/O islands, supporting distributed control architectures and efficient field device connectivity.
• Features an isolated CANopen interface through a male SUB-D 9 connector, ensuring stable communication in industrial environments.
• Supports flexible baud rate configuration from 10 kbit/s to 1000 kbit/s, enabling adaptation to different CANopen network requirements.
• Compact TM5 modular design with DIN rail installation helps reduce control cabinet space requirements while maintaining system scalability and service convenience.
Technical FAQs
1. What type of module is the Schneider TM5NCO1?
The Schneider TM5NCO1 is a Modicon TM5 CANopen communication module used as a fieldbus interface for distributed I/O systems.
2. What is the main function of the TM5NCO1?
The TM5NCO1 provides CANopen network communication between a TM5 I/O island and a compatible automation controller or CANopen master system.
3. Which communication protocol does the TM5NCO1 support?
The TM5NCO1 supports the CANopen communication protocol through its integrated CAN interface.
4. Which Schneider Electric controllers are compatible with the TM5NCO1?
The TM5NCO1 is compatible with Modicon M258, LMC058, and LMC078 controller platforms.
5. What type of connector is used for CANopen communication?
The TM5NCO1 uses a male SUB-D 9 connector for CANopen network connection.
6. Does the TM5NCO1 provide I/O channels directly?
No. The TM5NCO1 is a communication interface module and does not provide direct digital or analog I/O channels.
7. Does the TM5NCO1 require a separate power supply module?
Yes. The module requires the appropriate TM5 bus base and power supply components within the TM5 modular system configuration.
8. What software is used to configure the TM5NCO1?
The TM5NCO1 configuration is managed through Schneider Electric automation engineering software used for Modicon controller programming and network setup.
9. What applications commonly use the TM5NCO1?
It is commonly used in distributed machine automation, remote I/O stations, packaging equipment, and complex motion control systems.
10. What advantage does the TM5NCO1 provide in automation systems?
It allows engineers to extend I/O systems over CANopen networks, improving machine flexibility, reducing wiring complexity, and supporting modular automation designs.
