Schneider TM5NEIP1 EtherNet/IP Communication Module
Schneider TM5NEIP1 EtherNet/IP Communication Module
0.0
Points
Brand:Schneider PLC Item No.:TM5NEIP1 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5NEIP1 EtherNet/IP Communication Module is a dedicated fieldbus interface solution developed for the Modicon TM5 modular I/O platform. It enables distributed TM5 I/O islands to communicate through EtherNet/IP networks, providing a reliable connection between field-level devices and industrial controllers.
Designed for modern automation environments, the TM5NEIP1 helps machine builders create flexible distributed control architectures while improving installation efficiency and system expandability. With industrial Ethernet connectivity, compact modular construction, and compatibility with TM5 remote I/O solutions, it is a practical choice for demanding automation projects.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5NEIP1
Product Family
Modicon TM5
Module Type
EtherNet/IP Communication Module
Communication Interface
EtherNet/IP Fieldbus Interface
Supported Protocol
EtherNet/IP
Ethernet Ports
2 × RJ45 Switched Ethernet Ports
Ethernet Speed
10/100 Mbps
Network Topology
Line Topology
Power Supply
24 V DC
Isolation Type
Isolated Ethernet Interface
Status Indicators
LED Diagnostic Indicators
Compatible System
Modicon TM5 Distributed I/O
Required Bus Base
TM5ACBN1
Compatible Power Module
TM5SPS3
Terminal Block
TM5ACTB12PS
Installation Method
DIN Rail Mount
Protection Rating
IP20
Dimensions
Approx. 99 × 62.5 × 75 mm
Weight
Approx. 52 g
Recommended Companion Models
Model
Product Name
TM5ACBN1
Schneider Modicon TM5 Fieldbus Interface Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Distribution Module
TM5ACTB12PS
Schneider Modicon TM5 12-Pin Power Distribution Terminal Block
TM5C24D18T
Schneider Modicon TM5 Compact Digital I/O Expansion Block Module
Frequently Selected Alternatives
Model
Product Name
TM5NCO1
Schneider Modicon TM5 CANopen Communication Module
TM5NS31
Schneider Modicon TM5 SERCOS III Communication Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
TM5ACBN1
Schneider Modicon TM5 Fieldbus Interface Bus Base Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 distributed I/O systems, providing an EtherNet/IP fieldbus interface that enables remote I/O islands to connect with industrial Ethernet networks and automation controllers.
• Suitable for packaging equipment, material handling systems, production machinery, and complex machine control applications where high-performance distributed I/O communication is required.
• Ideal for Modicon TM5 architectures that require flexible remote I/O expansion, allowing engineers to place I/O closer to field devices while reducing control cabinet wiring complexity.
Key Strengths at a Glance
• Provides EtherNet/IP fieldbus communication capability for TM5 distributed I/O islands, supporting scalable industrial Ethernet automation solutions.
• Equipped with two isolated switched Ethernet ports supporting 10/100 Mbps communication, enabling convenient network integration for industrial applications.
• Supports line network topology, helping simplify machine layouts and reduce additional Ethernet switching requirements in suitable applications.
• Compact TM5 modular design with DIN rail mounting helps optimize cabinet space while maintaining easy installation and maintenance.
Technical FAQs
1. What type of module is the Schneider TM5NEIP1?
The Schneider TM5NEIP1 is a Modicon TM5 EtherNet/IP fieldbus interface module designed for distributed I/O communication.
2. What is the main function of the TM5NEIP1?
The TM5NEIP1 provides Ethernet-based communication between a TM5 distributed I/O island and an EtherNet/IP scanner or controller.
3. Which communication protocol does the TM5NEIP1 support?
The TM5NEIP1 supports the EtherNet/IP industrial communication protocol for distributed automation applications.
4. How many Ethernet ports does the TM5NEIP1 provide?
The TM5NEIP1 provides two isolated switched Ethernet ports for industrial network connections.
5. Does the TM5NEIP1 provide direct digital or analog I/O channels?
No. The TM5NEIP1 is a communication interface module and does not contain direct field I/O channels.
6. Which TM5 components are required to build a complete EtherNet/IP interface assembly?
A complete assembly typically includes the fieldbus interface bus base, TM5NEIP1 interface module, Interface Power Distribution Module, and terminal block.
7. What power supply voltage does the TM5NEIP1 require?
The TM5NEIP1 operates with a 24 V DC power supply system.
8. Can the TM5NEIP1 be used with remote I/O configurations?
Yes. It is specifically designed to manage TM5 distributed I/O islands connected through EtherNet/IP networks.
9. Does the TM5NEIP1 require software configuration?
Yes. Network parameters and I/O communication settings must be configured through compatible Schneider Electric automation software.
10. What advantages does the TM5NEIP1 provide in automation systems?
It improves system scalability, reduces field wiring requirements, and enables flexible placement of distributed I/O modules in industrial machines.
