Brand:Schneider PLC Item No.:TM5NEIP1K Product Origin:France Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5NEIP1K EtherNet/IP Fieldbus Interface Kit Module is a complete communication solution developed for the Modicon TM5 distributed I/O platform. It combines the EtherNet/IP interface module and supporting TM5 components to provide a ready-to-install communication foundation for industrial automation systems.
Designed for modern machine control environments, the TM5NEIP1K helps engineers build flexible remote I/O architectures with simplified wiring, efficient maintenance, and reliable industrial Ethernet connectivity. Its integrated design makes it a practical choice for OEM machinery, production equipment, and scalable automation applications.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5NEIP1K
Product Family
Modicon TM5
Module Type
EtherNet/IP Fieldbus Interface Kit
Communication Protocol
EtherNet/IP
Included Interface Module
TM5NEIP1
Included Bus Base
TM5ACBN1
Included Power Module
TM5SPS3
Included Terminal Block
TM5ACTB12PS
Ethernet Ports
2 × RJ45 Switched Ports
Ethernet Speed
10/100 Mbps
Power Supply
24 V DC
Mounting Type
DIN Rail Mount
Protection Rating
IP20
Compatible System
Modicon TM5 Distributed I/O
Configuration Software
EcoStruxure Machine Expert
Dimensions
Approx. 99 × 38 × 75 mm
Weight
Approx. 0.075 kg
Recommended Companion Models
Model
Product Name
TM5C24D18T
Schneider Modicon TM5 Compact Digital I/O Expansion Block Module
Schneider Modicon TM5 Interface Power Distribution Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 distributed I/O systems, providing a complete EtherNet/IP fieldbus interface kit for building remote I/O islands in industrial automation networks.
• Suitable for packaging machines, material handling equipment, automated production lines, and machine control systems requiring reliable Ethernet-based distributed I/O communication.
• Ideal for applications where engineers need a complete communication assembly that combines EtherNet/IP interface capability, bus connection, power distribution, and terminal connection in one integrated solution.
Key Strengths at a Glance
• Provides a complete Modicon TM5 EtherNet/IP communication solution, including the TM5NEIP1 interface module, TM5ACBN1 bus base, TM5SPS3 power distribution module, and TM5ACTB12PS terminal block.
• Supports industrial Ethernet communication through two switched RJ45 ports, enabling flexible network integration and simplified distributed I/O architecture design.
• Reduces system configuration complexity by supplying the required interface components as a matched factory kit, improving installation efficiency and maintenance convenience.
• Designed for Modicon TM5 scalable I/O systems, allowing machine builders to expand automation networks while maintaining compact cabinet layouts.
Technical FAQs
1. What type of module is the Schneider TM5NEIP1K?
The Schneider TM5NEIP1K is an EtherNet/IP Fieldbus Interface Kit designed for Modicon TM5 distributed I/O systems.
2. What is the main function of the TM5NEIP1K?
The TM5NEIP1K provides an Ethernet communication gateway that allows TM5 remote I/O islands to exchange data with EtherNet/IP-based controllers and industrial networks.
3. What components are included in the TM5NEIP1K kit?
The kit includes the TM5NEIP1 EtherNet/IP interface module, TM5ACBN1 bus base, TM5SPS3 interface power distribution module, and TM5ACTB12PS spring terminal block.
4. Which communication protocol does the TM5NEIP1K support?
The TM5NEIP1K supports EtherNet/IP communication for distributed automation and remote I/O applications.
5. Does the TM5NEIP1K provide direct I/O channels?
No. The TM5NEIP1K is a fieldbus interface solution and requires additional TM5 I/O modules to provide digital or analog signal processing.
6. How does the TM5NEIP1K improve automation system design?
It simplifies distributed I/O installation by providing a complete communication interface assembly, reducing component selection and wiring effort.
7. What type of network connection does the TM5NEIP1K use?
The TM5NEIP1K uses industrial Ethernet connectivity through RJ45 interfaces for EtherNet/IP communication.
8. Is the TM5NEIP1K compatible with Modicon TM5 I/O modules?
Yes. The kit is designed to operate as part of a Modicon TM5 modular distributed I/O architecture.
9. Does the TM5NEIP1K require software configuration?
Yes. Network parameters and I/O mapping are configured through Schneider Electric automation engineering software.
10. What advantages does the TM5NEIP1K provide compared with separate component selection?
It reduces integration time by combining essential EtherNet/IP interface components into one matched package, improving system reliability and commissioning efficiency.
