Brand:Schneider PLC Item No.:TM5NS31 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5NS31 SERCOS III Communication Module is a specialized fieldbus interface designed for the Modicon TM5 modular I/O platform. It enables distributed TM5 I/O islands to communicate with SERCOS III-based motion control systems, providing a reliable foundation for high-performance automation applications.
With dual RJ45 communication ports, compact modular construction, and compatibility with Schneider Electric motion control solutions, the TM5NS31 helps machine builders create efficient and scalable automation architectures. It is particularly suitable for applications where precise synchronization, fast communication, and dependable field connectivity are essential.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5NS31
Product Family
Modicon TM5
Module Type
SERCOS III Communication Module
Communication Protocol
SERCOS III
Physical Interface
RJ45
Communication Ports
2 × RJ45 SERCOS III Ports
Communication Speed
100 Mbit/s
Compatible Controller
Modicon LMC078 Motion Controller
Network Type
Industrial Ethernet-Based Fieldbus
Status Indicators
SERCOS Status LEDs
Power Consumption
350 mA at 5 V DC
Maximum Power Dissipation
1.75 W
Installation Method
DIN Rail Mount
Protection Rating
IP20
Module Color
White
Dimensions
Approx. 99 × 62.5 × 75 mm
Weight
Approx. 0.03 kg
Recommended Companion Models
Model
Product Name
TM5ACBN1
Schneider Modicon TM5 Fieldbus Interface Bus Base Module
TM5SPS3
Schneider Modicon TM5 Interface Power Distribution Module
TM5ACTB12PS
Schneider Modicon TM5 Power Distribution Terminal Block Module
TM5C24D18T
Schneider Modicon TM5 Compact Digital I/O Expansion Block Module
Frequently Selected Alternatives
Model
Product Name
TM5NEIP1
Schneider Modicon TM5 EtherNet/IP Communication Module
TM5NCO1
Schneider Modicon TM5 CANopen Communication Module
TM5NS31
Schneider Modicon TM5 SERCOS III Communication Module
TM5SPS3
Schneider Modicon TM5 Interface Power Supply Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon TM5 distributed I/O systems, providing a SERCOS III fieldbus interface for high-performance motion control and synchronized automation applications.
• Suitable for packaging machinery, material processing equipment, robotic systems, and motion-based automation platforms requiring fast and deterministic communication between controllers and field devices.
• Ideal for Modicon LMC078 motion controller architectures, enabling scalable TM5 remote I/O configurations with efficient network integration and simplified machine design.
Key Strengths at a Glance
• Provides SERCOS III communication capability for Modicon TM5 distributed I/O islands, supporting precise motion-oriented automation networks.
• Features dual RJ45 SERCOS III ports, allowing flexible network topologies and reliable industrial Ethernet-based communication.
• Supports high-speed 100 Mbit/s communication performance, helping maintain accurate synchronization in demanding motion control environments.
• Compact TM5 modular construction with DIN rail installation helps optimize control cabinet space while maintaining convenient system expansion and maintenance.
Technical FAQs
1. What type of module is the Schneider TM5NS31?
The Schneider TM5NS31 is a Modicon TM5 SERCOS III Communication Module designed for fieldbus communication in distributed I/O and motion control systems.
2. What is the main function of the TM5NS31?
The TM5NS31 provides a SERCOS III communication interface that connects TM5 distributed I/O systems with compatible motion controllers and automation networks.
3. Which communication protocol does the TM5NS31 support?
The TM5NS31 supports the SERCOS III communication standard for deterministic industrial communication.
4. How many communication ports does the TM5NS31 provide?
The TM5NS31 provides two RJ45 SERCOS III communication ports for network connection.
5. Is the TM5NS31 an I/O expansion module?
No. The TM5NS31 is a communication interface module and requires additional TM5 I/O modules to provide digital or analog signal processing.
6. Which controller is commonly used with the TM5NS31?
The TM5NS31 is designed for use with Schneider Electric Modicon LMC078 motion controller systems.
7. What connector type is used by the TM5NS31?
The TM5NS31 uses RJ45 connectors for SERCOS III communication connections.
8. Does the TM5NS31 support Ethernet-based communication?
Yes. The module uses SERCOS III technology, which operates through industrial Ethernet physical interfaces.
9. Does the TM5NS31 require configuration before operation?
Yes. Communication parameters, addressing, and network settings must be configured within the Schneider Electric automation environment.
10. What advantages does the TM5NS31 provide in motion applications?
It provides deterministic communication performance, flexible distributed I/O expansion, and reliable synchronization for advanced machine automation systems.
