Brand:Schneider PLC Item No.:ATV310H075N4E Product Origin:France Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV310H075N4E Variable Speed Drive Module is a compact motor control solution from the Easy Altivar 310 series, developed for simple machine automation applications. Designed for 0.75 kW three-phase asynchronous motors, this drive provides efficient speed regulation, reliable motor protection, and straightforward commissioning for industrial equipment.
Featuring built-in sensorless vector control, flexible frequency adjustment, and integrated Modbus RTU communication, the ATV310H075N4E offers practical performance for OEM machinery, conveyors, pumps, fans, and general automation systems. Its compact design and simplified setup make it a strong choice for applications where dependable motor control and cost-effective integration are essential.
With Schneider Electric’s established automation technology, this variable speed drive provides a balanced combination of performance, reliability, and ease of maintenance for everyday industrial motion applications.
Simple machine automation systems requiring reliable motor speed control
Conveyor, fan, pump, and small machinery applications
Packaging and material handling equipment
HVAC auxiliary motor control systems
OEM machines requiring compact frequency regulation solutions
Industrial equipment modernization and drive replacement projects
Low-power three-phase asynchronous motor applications
Control cabinets requiring efficient variable speed solutions
Key Strengths at a Glance
Designed for Schneider Electric Easy Altivar 310 variable speed drive platform
Supports 0.75 kW (1 hp) three-phase motor applications
Compatible with 380–460 VAC three-phase power supplies
Embedded U/F control and sensorless vector control functions
Supports Modbus RTU communication through RS485 interface
Compact heat sink mounting design for easy cabinet integration
Adjustable output frequency range up to 400 Hz
Provides simple commissioning and reliable motor speed management
Technical FAQs
1. What is the main function of the Schneider ATV310H075N4E?
The ATV310H075N4E is a variable speed drive designed to control the speed and torque of three-phase asynchronous motors in simple industrial machine applications.
2. What motor power rating does the ATV310H075N4E support?
The drive is rated for motors up to 0.75 kW (1 hp) in heavy-duty applications.
3. What input voltage does the ATV310H075N4E require?
The drive operates with a three-phase supply voltage range of 380 to 460 VAC.
4. Does the ATV310H075N4E support Modbus communication?
Yes. It includes Modbus RTU communication through an RS485 physical interface with an RJ45 communication connector.
5. What type of motors can be controlled by this drive?
The ATV310H075N4E is designed primarily for three-phase asynchronous motors used in industrial automation applications.
6. Does the ATV310H075N4E include vector control?
Yes. It includes sensorless vector control and traditional U/F control modes to support different motor control requirements.
7. What is the maximum output frequency of the ATV310H075N4E?
The drive supports an adjustable output frequency range up to 400 Hz, depending on application configuration.
8. Does the ATV310H075N4E require an external EMC filter?
This model is supplied without an integrated EMC filter and may require additional EMC consideration depending on installation requirements.
9. Can the ATV310H075N4E be used in OEM machinery?
Yes. It is designed for simple machines and compact automation equipment where reliable speed control and easy integration are required.
10. How does the ATV310H075N4E improve machine operation?
By controlling motor speed and acceleration, the drive helps optimize energy usage, reduce mechanical stress, and improve process control efficiency.
