Brand:Schneider PLC Item No.:ATV71HD30N4Z Product Origin:France Product Dimensions:550 x 266 x 240 mm Product Weight:37 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV71HD30N4Z Variable Speed Drive is an advanced industrial inverter designed for high-performance motor control applications. It belongs to the Altivar 71 family and is engineered for machines that require accurate speed control, strong torque capability, and flexible automation integration.
This model supports 30 kW three-phase motors at 380–480 V, making it suitable for medium and high-power industrial applications. The drive combines multiple motor control methods with practical communication functions, allowing engineers to develop efficient and reliable automation systems.
The ATV71HD30N4Z is commonly used in industries where continuous operation and precise motor management are critical. Its robust design supports demanding environments while providing convenient commissioning and diagnostic functions for maintenance teams.
For machine builders and system integrators, this variable speed drive provides a dependable platform for improving machine performance, optimizing energy usage, and expanding automation capabilities.
With advanced control technology and industrial reliability, the ATV71HD30N4Z remains a valuable solution for upgrading existing equipment and developing new automation projects.
Industrial Applications and Automation Integration
The Schneider ATV71HD30N4Z Variable Speed Drive is a high-performance industrial motor control device designed for complex automation systems requiring accurate speed regulation, strong torque performance, and reliable operation under demanding conditions. As part of the Altivar 71 series, this variable speed drive provides advanced control functions for high-power industrial machines and automation equipment.
Designed for 30 kW (40 HP) three-phase motor applications, the ATV71HD30N4Z supports 380–480 V power systems and provides flexible motor control technologies, including sensorless vector control and flux vector control. These capabilities make it suitable for applications where smooth acceleration, stable torque output, and precise motor management are essential.
Typical application areas include:
Heavy-duty conveyor systems
Industrial processing equipment
Material handling machinery
Pump and fan control systems
Hoisting and lifting applications
Packaging production lines
Machine tools and manufacturing equipment
Large automated production systems
The ATV71HD30N4Z provides engineers with a scalable motor control platform that can be integrated into modern industrial automation architectures. Its communication capability and advanced configuration functions help simplify system design while improving equipment efficiency and operational stability.
Engineering Advantages and Product Performance Benefits
The Schneider ATV71HD30N4Z Variable Speed Drive combines powerful motor control technology, flexible communication features, and industrial-grade reliability, making it suitable for demanding automation applications.
Advanced High-Power Motor Control
The drive is designed for 30 kW industrial motors and provides accurate speed and torque management through advanced control algorithms. This allows machines to maintain stable operation even when load conditions change significantly.
Excellent Torque Performance
With flux vector control capability, the ATV71HD30N4Z can provide improved low-speed torque response and enhanced motor control performance for applications requiring strong starting capability and precise movement control.
Flexible Industrial Communication
The drive supports industrial communication interfaces such as Modbus and CANopen, allowing convenient integration with PLC systems and automation networks. This helps engineers create efficient and centralized control architectures.
Energy Optimization Capability
By adjusting motor speed according to actual process requirements, the ATV71HD30N4Z can reduce unnecessary energy consumption while improving overall system efficiency, especially in variable-load applications.
Reliable Industrial Protection Functions
The drive includes multiple protection mechanisms against overload, overvoltage, overcurrent, and thermal stress, helping improve equipment reliability and reduce unexpected downtime.
Suitable for Complex Machine Applications
The Altivar 71 platform is designed for advanced industrial machines that require flexible configuration, precise control, and long-term operational reliability.
