The Emerson VE4003S2B9 Analog Input Terminal Block is a dedicated field termination assembly developed for the DeltaV Series 2 Plus Distributed Control System. Designed for 16-channel, 2-wire analog input applications, it supports both 4–20 mA process signals and HART communication, providing an efficient interface between field instruments and DeltaV analog input modules.
Its high-density design helps reduce control cabinet wiring while improving installation efficiency and long-term maintenance. Engineered specifically for process automation environments, the VE4003S2B9 delivers dependable signal integrity and streamlined field wiring for demanding industrial applications.
Whether deployed in new DeltaV installations or system expansion projects, the VE4003S2B9 offers the reliability, compatibility, and engineering quality expected from Emerson process automation products.
Technical Specifications
Specification
Details
Manufacturer
Emerson
Model
VE4003S2B9
Product Type
Analog Input Terminal Block
Product Series
DeltaV Series 2 Plus
Supported Channels
16 Analog Input Channels
Input Type
2-Wire Analog Input
Signal Type
4–20 mA
HART Support
Yes
Compatible Module
DeltaV Series 2 Plus AI Card
Wiring Method
Terminal Block
Installation
DeltaV I/O Carrier
Protection Rating
IP20
Operating Temperature
-40°C to +70°C
Storage Temperature
-40°C to +85°C
Relative Humidity
5–95%, Non-condensing
Dimensions (H × W × D)
Approx. 107 × 41 × 105 mm
Weight
Approx. 0.30 kg
The environmental specifications and Series 2 Plus compatibility are defined in the Emerson DeltaV M-series Traditional I/O documentation.
Recommended Companion Models
Model
Product Name
VE4003S2B10
DeltaV Series 2 Plus 16-Channel 4-Wire Analog Input Terminal Block
VE4033S2B10
DeltaV Series 2 Plus Redundant Analog Input Terminal Block
KJ3002X1-BA1
DeltaV Series 2 Plus 16-Channel Analog Input Card
VE4003S2B11
DeltaV Series 2 Plus 48-Pin Analog Input Mass Termination Block
Frequently Selected Alternatives
Model
Product Name
VE4003S2B6
DeltaV 16-Channel Standard Analog Input Terminal Block
VE4003S2B7
DeltaV 16-Channel 4-Wire Analog Input Terminal Block
VE4003S2B5
DeltaV 24-Pin Analog Input Mass Termination Block
VE4033S2B1
DeltaV Redundant Standard Analog Input Terminal Block
Where It Excels in Industrial Use
Emerson DeltaV Distributed Control System (DCS) installations
Process industries requiring high-density analog signal acquisition
Oil & gas, chemical, and petrochemical processing plants
Power generation and utility automation systems
Water and wastewater treatment facilities
Pharmaceutical and food & beverage process control
Large-scale HART-enabled instrumentation projects
New DeltaV Series 2 Plus installations and system upgrades
Key Strengths at a Glance
Designed for Emerson DeltaV Series 2 Plus I/O architecture
Supports 16-channel 2-wire analog input applications
Compatible with 4–20 mA and HART field devices
Simplifies wiring with integrated terminal block design
Optimized for high-density process instrumentation
Reduces installation time and cabinet wiring complexity
Ensures reliable signal transmission for critical process control
Engineered for seamless integration with DeltaV analog input cards
Technical FAQs
1. What is the primary function of the Emerson VE4003S2B9?
The VE4003S2B9 is a 16-channel, 2-wire analog input terminal block designed for Emerson DeltaV Series 2 Plus analog input cards, providing field wiring termination for 4–20 mA and HART signals.
2. Which DeltaV hardware is compatible with the VE4003S2B9?
It is designed specifically for DeltaV Series 2 Plus 16-channel Analog Input (AI Plus) cards used in Emerson Distributed Control Systems.
3. Does the VE4003S2B9 support HART communication?
Yes. The terminal block supports HART-enabled 4–20 mA transmitters, allowing simultaneous analog measurement and digital device communication.
4. How many field devices can be connected?
The terminal block accommodates up to 16 independent two-wire analog input channels.
5. Is this terminal block intended for four-wire transmitters?
No. The VE4003S2B9 is specifically designed for 2-wire analog input applications. Four-wire applications use a different Series 2 Plus termination block.
6. Does the VE4003S2B9 require external power?
No. It serves as a passive termination assembly for field wiring and interfaces directly with the associated DeltaV analog input module.
7. Can the VE4003S2B9 be used in redundant DeltaV systems?
The standard VE4003S2B9 is intended for simplex configurations. Dedicated redundant terminal block models are available for redundant controller architectures.
8. What types of field instruments are commonly connected?
Typical connected devices include pressure transmitters, temperature transmitters, flow transmitters, level transmitters, and other HART-compatible process instruments.
9. Does the terminal block improve maintenance efficiency?
Yes. Its organized terminal layout simplifies installation, commissioning, troubleshooting, and field device replacement.
10. Why choose an original Emerson DeltaV terminal block?
Original Emerson termination hardware provides verified compatibility, dependable electrical performance, and reliable long-term operation within DeltaV control systems.
