Honeywell CC-TOIL01 Digital Output Termination Assembly
Honeywell CC-TOIL01 Digital Output Termination Assembly
0.0
Points
Brand:Honeywell DCS Item No.: CC-TOIL01 Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Honeywell CC-TOIL01 Digital Output Termination Assembly is a field termination component developed for the Honeywell Experion PKS Series C platform. It provides a reliable interface between compatible digital output modules and field wiring, simplifying installation while improving cabinet organization and long-term maintenance efficiency.
Designed for industrial automation environments, the CC-TOIL01 helps ensure dependable connections for discrete output devices such as relays, solenoid valves, alarms, and motor control equipment. Its modular construction supports efficient system expansion and straightforward replacement during maintenance.
With seamless compatibility across Honeywell Series C control architectures, the CC-TOIL01 delivers reliable field connectivity for mission-critical distributed control system applications.
Technical Specifications
Specification
Details
Manufacturer
Honeywell
Model
CC-TOIL01
Product Type
Digital Output Termination Assembly
Product Series
Experion PKS Series C
Function
Digital Output Field Termination
Compatible Platform
Honeywell Experion PKS
Compatible Module Type
Series C Digital Output Modules
Application
Field Device Wiring Interface
Mounting Type
Carrier / Cabinet Mount
Wiring Method
Terminal Assembly
Installation Environment
Industrial Control Cabinet
Protection Rating
IP20
Operating Temperature
0°C to +60°C*
Storage Temperature
-40°C to +85°C*
Dimensions
Approx. 150 × 90 × 40 mm*
Weight
Approx. 0.35 kg*
*Some standalone specifications for the CC-TOIL01 are not separately published by Honeywell and may vary depending on the associated Series C hardware. Verify installation details using the official system documentation before deployment.
Recommended Companion Models
Model
Product Name
CC-PDIL01
Honeywell Series C Digital Input Module
CC-PDOB01
Honeywell Series C Digital Output Module
CC-PAIH01
Honeywell Series C Analog Input Module
CC-PAOH01
Honeywell Series C Analog Output Module
Frequently Selected Alternatives
Model
Product Name
CC-TDIL01
Honeywell Series C Digital Input Termination Assembly
CC-TAIX01
Honeywell Series C Analog Input Termination Assembly
CC-TAOX01
Honeywell Series C Analog Output Termination Assembly
CC-TCNT01
Honeywell Series C Network Interface Termination Assembly
Where It Excels in Industrial Use
Honeywell Experion PKS Series C distributed control systems
Industrial process automation requiring reliable digital output field termination
Oil & gas, petrochemical, and refinery control applications
Power generation and utility automation systems
Solenoid valve, relay, and actuator wiring applications
Process industries requiring high-density discrete output interfaces
New Experion PKS installations and control system upgrades
Mission-critical automation cabinets requiring dependable field connectivity
Key Strengths at a Glance
Designed for Honeywell Series C digital output architectures
Provides field termination for digital output modules
Supports organized wiring for simplified installation and maintenance
Improves cabinet wiring efficiency and serviceability
Engineered for reliable industrial control system operation
Native integration with Honeywell Experion PKS platforms
Built for long-term performance in continuous process environments
Technical FAQs
1. What is the primary function of the Honeywell CC-TOIL01?
The CC-TOIL01 is a digital output termination assembly that provides field wiring connections between Honeywell Series C digital output modules and external field devices.
2. Which Honeywell platform is compatible with the CC-TOIL01?
The CC-TOIL01 is designed for Honeywell Experion PKS Series C control systems using compatible Series C digital output modules.
3. Is the CC-TOIL01 an active I/O module?
No. It is a passive termination assembly that provides organized field wiring connections rather than performing signal processing.
4. What devices are commonly connected through the CC-TOIL01?
Typical connected devices include solenoid valves, relays, motor starters, indicator lamps, alarms, and other discrete industrial loads.
5. Does the CC-TOIL01 simplify cabinet wiring?
Yes. It provides clearly organized terminal connections that reduce installation time and simplify maintenance activities.
6. Can the CC-TOIL01 be used in continuous industrial operation?
Yes. It is designed for long-term operation in demanding industrial automation environments.
7. Is the CC-TOIL01 suitable for process industries?
Yes. It is widely suited for oil & gas, petrochemical, power generation, chemical processing, and other continuous manufacturing industries.
8. Does the CC-TOIL01 support system expansion?
Yes. It can be incorporated into new installations or expansion projects within compatible Honeywell Series C control systems.
9. Does the module require separate programming?
No. As a passive termination assembly, it requires no programming or configuration.
10. Why choose the Honeywell CC-TOIL01?
Its native compatibility with Honeywell Series C systems, organized wiring design, and dependable industrial construction make it an excellent field termination solution for digital output applications.
