Product Introduction
The Honeywell FS-BCU-0036 FTE Bridge Module is a communication interface component designed for Honeywell Fail Safe Controller (FSC) safety systems. It provides fault-tolerant Ethernet connectivity, enabling reliable communication between safety controllers and industrial network infrastructures.
Designed for high-availability safety applications, the FS-BCU-0036 supports redundant communication paths and stable network operation in demanding industrial environments. Its compact design allows integration into control cabinets while maintaining dependable performance for critical automation systems.
The module is widely applied in safety instrumented systems where communication reliability is essential, including emergency shutdown, process protection, and industrial safety control applications.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Honeywell |
| Model | FS-BCU-0036 |
| Product Type | FTE Bridge Module |
| Product Series | Honeywell FSC Safety Controller |
| Function | Fault-Tolerant Ethernet Communication Interface |
| Communication Protocol | Ethernet with Fault-Tolerant Mechanisms |
| Redundancy Support | Dual Redundant Communication Paths |
| Input Voltage | 24 VDC / 120–240 VAC |
| Power Consumption | Typically <10 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% RH, Non-condensing |
| Installation | Industrial Control Cabinet |
| Application | Safety Network Communication |
| Weight | Approx. 0.55 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| FS-CPCHAS-0001 | Honeywell FSC Controller Chassis Assembly |
| FS-CPUI-0001 | Honeywell FSC Processor Interface Module |
| FS-SAI-1620M | Honeywell FSC Safety Analog Input Module |
| FS-DI-24VDC | Honeywell FSC Safety Digital Input Module |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| FC-TDIO52 | Honeywell Safety Controller Digital I/O Module |
| FS-BCU-0035 | Honeywell FSC Communication Bridge Module |
| 51403422-150 | Honeywell Safety System I/O Interface Module |
| FC-SAI-1620M | Honeywell Safety Analog Input Module |
Technical FAQs
1. What is the primary function of the Honeywell FS-BCU-0036?
The Honeywell FS-BCU-0036 is an FTE Bridge Module used within Honeywell safety controller systems to provide reliable Ethernet communication connectivity and fault-tolerant network integration.
2. Which Honeywell system is compatible with the FS-BCU-0036?
The module is designed for Honeywell Fail Safe Controller (FSC) systems and related safety automation network architectures.
3. What communication protocol does the FS-BCU-0036 support?
The FS-BCU-0036 supports Ethernet communication with fault-tolerant mechanisms, enabling reliable network operation in industrial safety applications.
4. Does the FS-BCU-0036 support redundant communication?
Yes. The module supports dual redundant communication paths to improve network availability and reduce the impact of communication failures.
5. What type of power supply does the FS-BCU-0036 require?
The module supports 24 VDC or 120/240 VAC power input configurations depending on system installation requirements.
6. Is the FS-BCU-0036 an I/O module?
No. It is a communication bridge module rather than a process input/output module. Its main function is network connectivity within the safety control system.
7. What applications commonly use the FS-BCU-0036?
Typical applications include safety controllers, emergency shutdown systems, process interlocks, and high-availability industrial automation networks.
8. Does the FS-BCU-0036 improve system availability?
Yes. By providing fault-tolerant Ethernet communication capability, it helps maintain reliable communication between safety system components.
9. What industries commonly use the FS-BCU-0036?
It is commonly used in oil & gas, chemical processing, refining, power generation, and other industries requiring high-integrity safety control.
10. Why choose the Honeywell FS-BCU-0036?
The module provides reliable Ethernet bridging, redundant communication support, and compatibility with Honeywell FSC safety architectures, making it suitable for mission-critical automation systems.
