Brand:Ingersoll Rand Item No.:47588684001 85561066 Product Origin:USA Product Dimensions:920 × 45 × 45 mm Product Weight:1.48 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47588684001 85561066 Water-Cooled Hose Maintenance Kit is intended for maintenance of compatible Ingersoll Rand water-cooled screw compressor systems. The 47588684001 is identified as a water-cooled hose maintenance kit, while 85561066 is a specific hydraulic hose used within the associated cooling arrangement.
The 85561066 hose is documented in water-cooled compressor parts information as the connection between the aftercooler and coolant cooler. It is specified as a hydraulic hose with straight JIC connections, a nominal 1.00-inch size, and a 34-inch length.
For maintenance personnel, this combination addresses an important part of the compressor cooling system. Water-cooled screw compressors rely on effective coolant circulation to manage operating heat, and the condition of individual hoses can directly affect the integrity of that circuit.
Using the correct replacement component helps maintain the intended connection geometry and routing of the cooling system. For plants operating compressors for extended production cycles, scheduled hose inspection and replacement can provide a practical way to strengthen equipment reliability and reduce avoidable maintenance interruptions.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Main Part Number
47588684001
Product Type
Water-Cooled Hose Maintenance Kit
Associated Part Number
85561066
Component Type
Hydraulic Hose
Application
Water-Cooled Screw Compressor
Cooling Configuration
Water-Cooled
Hose Application
Aftercooler to Coolant Cooler
Connection Configuration
Straight JIC × Straight JIC
Fitting Standard
JIC 37°
Nominal Hose Size
1.00 in
Hose Length
34.00 in
Approx. Hose Length
863.6 mm
Package Dimensions
Approx. 920 × 45 × 45 mm
Hose Net Weight
Approx. 1.48 kg
Service Function
Water-Cooling Circuit Maintenance
Installation
Compatible Ingersoll Rand Compressor Service Application
The 85561066 component is listed with a net weight of approximately 1.48 kg and package dimensions of approximately 920 × 45 × 45 mm. These measurements refer to the associated hose component/package and should not be interpreted as the packed dimensions of the complete 47588684001 maintenance kit.
• Water-Cooled Screw Compressor Service — The Ingersoll Rand 47588684001 is designed for maintenance work on compatible water-cooled screw compressor systems, providing a focused solution for servicing hose components within the cooling circuit.
• Aftercooler Cooling Connections — The associated 85561066 hose is specified for the water-cooled connection between the aftercooler and coolant cooler, making it particularly relevant to compressor cooling-system maintenance.
• Preventive Maintenance Operations — Replacing cooling hoses during scheduled service helps maintenance teams address wear and aging before they develop into coolant leakage, restricted circulation, or unexpected equipment downtime.
• Continuous Industrial Compressor Operation — In facilities where compressed air is essential to production, maintaining the water-cooling circuit supports dependable heat management and helps keep the compressor operating within its intended thermal conditions.
Key Strengths at a Glance
• Purpose-Built Water-Cooled Maintenance Kit — Part number 47588684001 is identified as an Ingersoll Rand water-cooled hose maintenance kit, providing a dedicated service solution rather than a generic hose replacement approach.
• Defined Hose Configuration — Part number 85561066 is identified as a hydraulic hose with straight JIC connections, a 1.00-inch nominal size, and a 34-inch length, giving technicians a clearly defined component for compatible applications.
• Supports Cooling-Circuit Integrity — The 85561066 hose is used between the aftercooler and coolant cooler in documented water-cooled configurations, where reliable fluid circulation is important to compressor temperature control.
• Maintenance-Focused Reliability — Incorporating the hose into a planned maintenance strategy can help reduce the operational risks associated with aged, damaged, or leaking cooling-circuit hoses.
Technical FAQs
1. What is Ingersoll Rand 47588684001?
Ingersoll Rand 47588684001 is a water-cooled hose maintenance kit intended for compatible Ingersoll Rand screw compressor systems.
2. What is Ingersoll Rand 85561066?
85561066 is a hydraulic hose used in compatible Ingersoll Rand water-cooled compressor systems. It is specified as a straight JIC × straight JIC hose with a 1.00-inch nominal size and 34-inch length.
3. Where is 85561066 installed in the cooling circuit?
Parts documentation identifies 85561066 as the hose connecting the aftercooler to the coolant cooler in applicable water-cooled compressor configurations.
4. What type of fittings are used on 85561066?
The hose is specified with straight JIC connections at both ends, using a 37-degree JIC connection arrangement.
5. What is the nominal size of 85561066?
The documented hose size is 1.00 inch, with an overall hose length of 34 inches.
6. Why is the aftercooler-to-coolant-cooler hose important?
This hose forms part of the water-cooling circuit. Maintaining the connection and hose condition helps preserve coolant circulation between the relevant cooling components.
7. Can 85561066 be installed on any Ingersoll Rand compressor?
No. Hose compatibility depends on the compressor model, cooling configuration, connection arrangement, and applicable parts documentation. The part number should be verified against the specific compressor before installation.
8. What should be inspected when replacing 85561066?
Technicians should inspect the hose routing, fittings, sealing surfaces, connection condition, surrounding components, and any signs of abrasion or leakage before commissioning the replacement.
9. Is 47588684001 suitable for preventive maintenance?
Yes. As a water-cooled hose maintenance kit, it is appropriate for planned compressor service where cooling hoses are inspected and replaced as part of a preventive maintenance program.
10. What could happen if a water-cooling hose develops a leak?
A leaking hose can reduce coolant circulation and may lead to inadequate heat removal, abnormal operating temperatures, or an unplanned compressor shutdown if the condition is not corrected.
