Brand:Ingersoll Rand Item No.:47588685001 89246524 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47588685001 89246524 Gear Box Maintenance Package is intended for planned maintenance of compatible Ingersoll Rand screw compressor drivetrain systems. The 47588685001 reference is identified as a Gear Box Maintenance Package, while 89246524 is specifically a Shaft Sleeve used within the motor shaft sealing assembly.
The 89246524 sleeve performs an important mechanical function within the shaft-sealing arrangement. Rather than serving as the sealing element itself, it provides the working surface for the shaft seal. In documented Ingersoll Rand assemblies, the sleeve is installed together with the 89244024 high-pressure shaft seal and 89244040 seal housing, with O-rings completing the associated sealing arrangement.
This distinction is important when planning compressor maintenance. A shaft seal may appear to be the primary wear component, but the sleeve surface directly affects how effectively the seal can operate. If the sleeve is grooved, damaged, or otherwise worn, installing a new seal alone may not provide the expected service life.
For maintenance professionals, 89246524 therefore represents a precision mechanical component within the larger gearbox and drivetrain service strategy. Correct identification and careful installation help preserve shaft-sealing integrity, support lubricant containment, and contribute to dependable compressor operation.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Main Part Number
47588685001
Main Product Type
Gear Box Maintenance Package
Associated Part Number
89246524
Component Type
Shaft Sleeve
Alternative Description
Sleeve, Shaft
Component Location
Motor Shaft / Shaft-Seal Assembly
Primary Function
Shaft-Seal Running Surface
Associated Shaft Seal
89244024
Associated Seal Housing
89244040
Associated O-Ring
95023107
Associated O-Ring
96958111
Application
Compatible Ingersoll Rand Screw Compressors
Service Category
Gearbox / Drivetrain Maintenance
Product Dimensions
Approx. 51 × 75 × 75 mm package dimensions
Individual Net Weight
Approx. 0.68 kg
Installation
Professional compressor service recommended
The available product data lists 89246524 at approximately 0.68 kg net weight, with package dimensions of approximately 51 × 75 × 75 mm. These figures refer to the individual shaft-sleeve product/package and not the complete 47588685001 maintenance package.
Recommended Companion Models
Model
Product Name
89244024
High-Pressure Shaft Seal
89244040
Shaft Seal Housing
95023107
Standard O-Ring -156
96958111
Standard O-Ring -142
Frequently Selected Alternatives
Model
Product Name
89292460
Shaft Sleeve
89292445
High-Pressure Shaft Seal
88122450
Shaft Seal
42486597
Shaft Seal Kit
Where It Excels in Industrial Use
• Gearbox and Drivetrain Maintenance — The Ingersoll Rand 47588685001 Gear Box Maintenance Package is designed for planned service of compatible screw compressor drivetrain assemblies, helping maintenance teams keep critical rotating components in dependable working condition.
• Motor Shaft Sealing Applications — The associated 89246524 is a shaft sleeve installed as part of the motor shaft sealing assembly, working together with the shaft seal and seal housing to maintain the integrity of the rotating shaft interface.
• Industrial Screw Compressor Service — This component is particularly relevant to compressor maintenance operations where shaft condition, lubricant containment, and accurate mechanical alignment are essential to reliable long-term performance.
• Preventive Drivetrain Maintenance — Replacing worn shaft-interface components during scheduled maintenance can help reduce the risk of seal damage, lubricant leakage, abnormal wear, and unexpected compressor downtime.
Key Strengths at a Glance
• Application-Specific Shaft Component — 89246524 is identified as a shaft sleeve rather than a generic seal, providing a dedicated wear and sealing surface within the compatible motor shaft assembly.
• Works with the Shaft-Seal Assembly — Parts documentation places 89246524 alongside 89244024 Shaft Seal, 89244040 Seal Housing, and associated O-rings, confirming its role within the complete shaft-sealing arrangement.
• Precision-Fit Drivetrain Component — The sleeve is designed to fit over the motor shaft and provide the appropriate surface for the shaft-seal lip, making correct component selection important for reliable sealing performance.
• Supports Long-Term Equipment Reliability — A properly maintained shaft sleeve can help protect the sealing interface and reduce the likelihood of premature seal wear or lubricant leakage around the rotating shaft.
Technical FAQs
1. What is Ingersoll Rand 47588685001?
Ingersoll Rand 47588685001 is identified as a Gear Box Maintenance Package for compatible Ingersoll Rand screw compressor systems.
2. What is Ingersoll Rand 89246524?
89246524 is an Ingersoll Rand shaft sleeve, also described as a sleeve for the motor shaft. It forms part of the shaft-sealing assembly used in compatible compressor drivetrain configurations.
3. Is 89246524 a shaft seal?
No. 89246524 is the shaft sleeve. The corresponding high-pressure shaft seal in the documented assembly is 89244024.
4. What is the function of the 89246524 shaft sleeve?
The shaft sleeve provides a controlled surface around the motor shaft for the shaft-seal lip to operate against. It helps maintain the sealing interface and can protect the underlying shaft from direct wear.
5. Which components work with 89246524?
The documented sealing assembly includes 89246524 Shaft Sleeve, 89244024 Shaft Seal, 89244040 Seal Housing, 95023107 O-Ring, and 96958111 O-Ring.
6. Why is the shaft sleeve important to seal performance?
The shaft-seal lip operates against the sleeve surface. A worn, damaged, or incorrectly installed sleeve can compromise the sealing interface and contribute to premature seal leakage or wear.
7. What can indicate shaft-sleeve wear?
Lubricant leakage around the shaft area, visible scoring or surface damage, abnormal seal wear, or deterioration discovered during seal replacement can indicate that the shaft sleeve should also be inspected.
8. Can 89246524 be replaced with a generic sleeve?
A generic replacement should not be selected solely by approximate dimensions. Material, surface finish, shaft fit, sealing geometry, and compatibility with the specific compressor assembly should all be confirmed.
9. Should the shaft seal be replaced at the same time as 89246524?
Not in every situation, but the shaft seal and sleeve should be inspected together because they operate as a paired sealing interface. If either component shows significant wear or damage, replacing the affected components together can provide a more reliable service result.
10. What should be checked before ordering 89246524?
The compressor model, existing part number, motor configuration, shaft-seal assembly, and applicable parts documentation should be verified before ordering to ensure the sleeve matches the installed drivetrain configuration.
