Brand:Ingersoll Rand Item No.:47653455001 39911631 Product Origin:USA Product Dimensions:650 × 120 × 90 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47653455001 39911631 Oil Filter Module combines an extended preventive-maintenance reference with a dedicated oil-filtration component for compatible Ingersoll Rand compressor systems.
The associated 39911631 is a spin-on oil filter designed for compressor lubrication applications. Its role is to remove particulate contamination from circulating lubricant before the oil reaches sensitive working components. This filtration stage is particularly important in oil-injected rotary screw compressors, where lubricant continuously moves through the airend and related components.
Available technical specifications identify 39911631 with inorganic microfiber filtration media rated at approximately 12 µm. The filter has an approximately 121 mm outside diameter and 299.1 mm total height, together with a 1-3/4 inch, 12-thread female connection. Its published working pressure is approximately 25 bar, with a burst pressure of approximately 54 bar.
The same filter reference appears across a broad range of Ingersoll Rand compressor applications. MANN-FILTER's compressor cross-reference documentation lists 39911631 for several Nirvana models, while other application information identifies it for EP75/EP100 and various HP, XP, HXP, and EPE machines. This broad application range makes exact model and serial-number verification important before ordering.
For maintenance teams, pairing the correct oil-filter reference with scheduled preventive service provides a practical way to maintain lubricant cleanliness. Timely replacement can help control contamination, maintain oil circulation, and support dependable operation of critical compressor components.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Main Part Number
47653455001
Main Product Type
8,000-Hour Preventive Maintenance Package
Associated Part Number
39911631
Component Type
Oil Filter Element
Module Type
Oil Filter Module
Filter Type
Spin-On
Primary Function
Compressor Oil Filtration
Filtration Media
Inorganic Microfibers
Filtration Rating
Approx. 12 µm
Outside Diameter
Approx. 121 mm
Body Height
Approx. 295 mm
Total Height
Approx. 299.1 mm
Thread
1-3/4 in Female, 12 TPI
Working Pressure
Approx. 25 bar
Burst Pressure
Approx. 54 bar
Net Weight
Approx. 2.08 kg
Approx. Product Dimensions
121 × 121 × 299.1 mm
Application
Ingersoll Rand Rotary Screw Compressors
Installation
Professional compressor maintenance recommended
The dimensions and weight above refer to 39911631, not the complete 47653455001 maintenance package. Published product specifications give a net weight of approximately 2.08 kg, an outside diameter of 121 mm, and a total height of 299.1 mm.
Recommended Companion Models
Model
Product Name
47553060001
Air Filter Element
39894597
Air/Oil Separator Element
38034914
Motor Bearing Grease
54601513
Air/Oil Separator Element
Frequently Selected Alternatives
Model
Product Name
39911615
Oil Filter Element
39796982
Oil Filter Element
54672654
Oil Filter Element
92888262
Oil Filter Element
Where It Excels in Industrial Use
• 8,000-Hour Preventive Maintenance — The Ingersoll Rand 47653455001 maintenance package is intended for extended scheduled compressor service, providing a structured maintenance reference for long-interval equipment care.
• Lubricant Circuit Protection — The associated 39911631 is an Ingersoll Rand oil filter designed to remove particulate contamination from compressor oil before the lubricant returns to critical working components.
• Heavy-Duty Rotary Screw Operation — Effective oil filtration is particularly valuable in compressors operating for extended periods under sustained thermal and mechanical loads, where lubricant cleanliness directly affects component protection.
• Reliable Oil Circulation — Maintaining the correct oil filter helps control contamination within the lubrication circuit and supports stable operation of the airend, bearings, gears, and other lubricated components.
Key Strengths at a Glance
• Dedicated OEM Oil Filter Reference — 39911631 is a defined Ingersoll Rand oil-filter part number used across multiple compatible compressor configurations.
• Microfiber Filtration Media — Available technical specifications identify inorganic microfiber media with an approximately 12 µm filtration rating, providing fine particulate filtration for compressor lubricant.
• High-Pressure Filter Construction — The filter is specified with approximately 25 bar working pressure and 54 bar burst pressure, supporting demanding compressor lubrication environments.
• Large Industrial Filter Format — 39911631 has an approximate 121 mm outside diameter and 299.1 mm total height, giving it a substantial filtration surface for industrial compressor service.
Technical FAQs
1. What is Ingersoll Rand 47653455001?
47653455001 is identified as an Ingersoll Rand 8,000-hour preventive maintenance package for compatible compressor equipment.
2. What is Ingersoll Rand 39911631?
39911631 is an Ingersoll Rand oil filter element used in compatible rotary screw compressor lubrication systems.
3. What is the primary function of 39911631?
The filter removes particulate contamination and debris from compressor oil before the lubricant is returned to the compression and lubrication circuit.
4. What filtration media is used in 39911631?
Available technical data identifies the filtration media as inorganic microfibers with an approximately 12 µm rating.
5. What are the pressure specifications of 39911631?
Current product specifications list approximately 25 bar working pressure and 54 bar burst pressure.
6. What thread specification does 39911631 use?
The filter is listed with a 1-3/4 inch, 12-thread female connection.
7. Which compressor applications use 39911631?
Ingersoll Rand 39911631 is used across a range of compressor configurations. MANN-FILTER documentation, for example, lists it for several Nirvana compressor models, while other application data associates it with EP, HP, XP, HXP, and EPE configurations. Exact compatibility should be confirmed against the machine's parts documentation.
8. Can 39911631 be replaced by 39911615?
Both references appear in Ingersoll Rand compressor applications, but they should not be assumed interchangeable. The compressor model, serial number, filter head, thread specification, and applicable parts list should be checked before substitution.
9. What can happen if the oil filter becomes heavily contaminated?
Contaminant loading can increase pressure differential across the filter and restrict oil flow. If filtration performance deteriorates significantly, lubrication conditions and protection of downstream components may be affected.
10. Why should 39911631 be replaced at the recommended service interval?
Regular replacement maintains effective contaminant removal and helps prevent excessive pressure drop. It also reduces the risk of degraded oil cleanliness affecting bearings, gears, seals, and other lubricated compressor components.
