Brand:Ingersoll Rand Item No.:47653455001 54601513 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47653455001 54601513 Air/Oil Separator Module combines a preventive-maintenance reference with a high-capacity air/oil separator designed for compatible Ingersoll Rand rotary screw compressor systems.
The 54601513 separator performs an essential function in oil-injected compression. During compression, lubricant is introduced into the airend for sealing, cooling, and lubrication. As a result, the compressed-air stream contains fine oil aerosols that must be removed before the air is delivered to the plant air network.
The separator element captures these oil particles through a coalescing process. Separated oil collects and is returned through the compressor's oil-return system, while the treated compressed air continues downstream. Maintaining this separation stage helps control oil carryover and contributes to cleaner compressed air.
54601513 is commonly associated with EP75, EP100, HP75, HP100, XF75, XF100, XP75, and XP100 rotary screw compressors. It also serves as the replacement reference for 39894597 in applicable assemblies.
Its large-format construction is suited to higher-capacity compressor systems. Available specifications place the separator body at approximately 276 mm in diameter and 192 mm in height, with a product net weight of approximately 4.43 kg.
For maintenance teams, replacing the separator at the appropriate service interval is more than a routine filter change. A healthy separator helps maintain efficient oil recovery, control pressure drop, reduce downstream oil contamination, and support stable compressor performance.
The dimensions and weight refer to the 54601513 separator element, not the complete 47653455001 maintenance package.
Recommended Companion Models
Model
Product Name
39911631
Oil Filter Element
47553060001
Air Filter Element
38034914
Motor Bearing Grease
39894597
Air/Oil Separator Element
Frequently Selected Alternatives
Model
Product Name
54509435
Air/Oil Separator Element
54639802
Air/Oil Separator Element
88248950
Air/Oil Separator Element
42542787
Air/Oil Separator Element
Where It Excels in Industrial Use
• Long-Interval Compressor Maintenance — The 47653455001 maintenance reference supports planned extended-service programs, while 54601513 provides the critical air/oil separation function required by compatible rotary screw compressors.
• Compressed-Air Oil Separation — 54601513 separates fine oil droplets from the compressed-air stream, helping reduce oil carryover and maintain cleaner air for downstream equipment.
• EP75 and EP100 Compressor Service — 54601513 is associated with Ingersoll Rand EP75, EP100, HP75, HP100, XF75, XF100, XP75, and XP100 rotary screw compressor configurations.
• Continuous Industrial Production — Maintaining the separator at the appropriate service interval helps control pressure drop through the separator vessel and supports efficient compressor operation during demanding production cycles.
Key Strengths at a Glance
• Dedicated Air/Oil Separation — 54601513 is specifically designed as an air/oil separator element for compatible Ingersoll Rand compressors.
• Proven Compressor Compatibility — The part is widely associated with EP75 and EP100 machines and their corresponding XF, HP, and XP 75/100 configurations.
• Established Replacement Reference — 54601513 is the replacement reference for 39894597 in applicable compressor assemblies.
• High-Capacity Separator Format — The separator uses a large industrial-format construction with an approximate 276 mm body diameter and 192 mm overall height, providing substantial separation capacity for high-output compressor systems.
Technical FAQs
1. What is Ingersoll Rand 47653455001?
47653455001 is an Ingersoll Rand preventive maintenance package reference for compatible compressor service applications.
2. What is Ingersoll Rand 54601513?
54601513 is an air/oil separator element used in compatible Ingersoll Rand rotary screw compressors.
3. What is the primary function of 54601513?
Its main function is to separate entrained compressor oil from compressed air before the air enters the downstream air system.
4. Which compressors commonly use 54601513?
The part is associated with EP75, EP100, HP75, HP100, XF75, XF100, XP75, and XP100 rotary screw compressors.
5. What is the relationship between 54601513 and 39894597?
39894597 is an earlier part-number reference that has been replaced by 54601513 for applicable compressor configurations.
6. How does the separator remove oil from compressed air?
The separator element uses coalescing filtration to capture fine oil aerosols. The droplets combine into larger droplets and are returned to the compressor lubrication circuit through the oil-return system.
7. What happens when the separator becomes restricted?
As the separator becomes loaded, differential pressure can increase. Excessive pressure drop may reduce compressor efficiency and increase the energy required to maintain the desired operating conditions.
8. What happens when separator efficiency deteriorates?
Reduced separation efficiency can increase oil carryover into the compressed-air system, potentially affecting downstream dryers, filters, piping, and production equipment.
9. How often should 54601513 normally be replaced?
For applicable compressor configurations, a commonly specified service interval is approximately 4,000 operating hours or once per year, whichever occurs first. The actual maintenance schedule for the individual machine should be followed.
10. What should be verified before installing 54601513?
The compressor model, serial number, existing separator reference, separator-vessel configuration, sealing surfaces, and oil-return arrangement should be checked before installation.
