Brand:Ingersoll Rand Item No.:47588693001 39911631 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47588693001 39911631 Oil Filter Module combines a compressor maintenance reference with a dedicated lubrication-filtration component designed for compatible Ingersoll Rand compressor systems.
The 39911631 oil filter element plays an important role in maintaining compressor lubrication quality. During operation, compressor oil continuously circulates through components exposed to friction, heat, and mechanical stress. Without effective filtration, contaminants can accumulate and circulate through the lubrication system.
By capturing particles and debris before the oil returns to critical components, 39911631 helps support cleaner lubrication conditions and protects components such as bearings, gears, and the compressor airend.
This filter reference is widely used in industrial compressor applications, including EP75 and EP100 rotary screw compressor families, as well as additional HP, XP, HXP, and related models. Proper filter selection is essential because different compressor configurations may require different filtration specifications.
For maintenance teams, combining the correct service reference with the appropriate oil filter element creates a more reliable maintenance process. Regular oil-filter replacement supports stable lubrication, reduces contamination risks, and contributes to dependable compressor performance.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Main Part Number
47588693001
Associated Part Number
39911631
Main Product Type
Compressor Maintenance Reference
Component Type
Oil Filter Element
Module Type
Oil Filter Module
Primary Function
Compressor Oil Filtration
Application
Rotary Screw Compressor Lubrication System
Compatible Series
EP75, EP100, HP, XP, HXP Series
Filter Style
Spin-On Oil Filter
Filtration Purpose
Removal of Oil Contaminants and Particles
Thread Specification
1-3/4"-12 UNF
Approx. Outside Diameter
121 mm
Approx. Height
296 mm
Approx. Product Dimensions
121 × 121 × 296 mm
Approx. Net Weight
2.11 kg
Installation Position
Compressor Oil Circuit
Installation
Professional compressor maintenance recommended
The dimensions and weight refer to the 39911631 oil filter element, not the complete 47588693001 maintenance reference.
Recommended Companion Models
Model
Product Name
47553060001
Air Filter Element
54601513
Air/Oil Separator Element
38034914
Motor Bearing Grease
47588682001
Temperature Control Valve Maintenance Kit
Frequently Selected Alternatives
Model
Product Name
39911615
Oil Filter Element
39796982
Oil Filter Element
54672654
Oil Filter Element
39329602
Oil Filter Element
Where It Excels in Industrial Use
• Compressor Lubrication Protection — The Ingersoll Rand 47588693001 maintenance reference supports scheduled compressor servicing, while 39911631 provides essential oil filtration for compatible rotary screw compressor lubrication systems.
• Contaminant Removal in Oil Circuits — The 39911631 oil filter element removes particles and debris from circulating compressor oil, helping protect critical lubricated components such as bearings and rotating assemblies.
• Heavy-Duty Compressor Operation — Designed for industrial compressor environments, 39911631 is commonly associated with Ingersoll Rand EP75, EP100, HP, XP, HXP, and related compressor applications where clean lubrication is required.
• Preventive Maintenance Efficiency — Replacing the oil filter at scheduled intervals helps maintain consistent lubrication performance and supports reliable compressor operation during continuous-duty applications.
Key Strengths at a Glance
• Dedicated Oil Filtration Component — 39911631 is an Ingersoll Rand oil filter element designed for compressor lubrication systems.
• Lubrication System Protection — The filter helps reduce contaminant circulation, supporting cleaner oil flow to the compressor airend and other lubricated components.
• Wide Application Coverage — The element is used across multiple Ingersoll Rand compressor configurations, including EP75 and EP100 series applications.
• Maintenance-Friendly Replacement — A defined OEM-style reference simplifies service planning and helps maintain the original filtration requirements of the compressor system.
Technical FAQs
1. What is Ingersoll Rand 47588693001?
47588693001 is an Ingersoll Rand compressor maintenance reference used for scheduled service applications.
2. What is Ingersoll Rand 39911631?
39911631 is an Ingersoll Rand oil filter element designed for compatible compressor lubrication systems.
3. What is the primary function of 39911631?
The oil filter removes contaminants and particles from compressor lubricant before the oil returns to critical internal components.
4. Why is oil filtration important in rotary screw compressors?
Compressor oil performs lubrication, sealing, and cooling functions. Effective filtration helps maintain cleaner lubricant conditions and reduces contamination-related wear.
5. What happens when an oil filter becomes restricted?
A restricted filter can increase pressure loss within the lubrication circuit and may affect oil circulation efficiency.
6. What contaminants does 39911631 help remove?
The filter is designed to capture suspended particles, debris, and contamination present in the compressor oil system.
7. Which compressor models commonly use 39911631?
39911631 is commonly associated with EP75 and EP100 rotary screw compressors and is also used in various HP, XP, HXP, and related compressor configurations.
8. Can 39911631 replace any compressor oil filter with similar dimensions?
9. What should be checked before installing 39911631?
The filter housing, sealing surface, mounting connection, lubricant condition, and compressor service requirements should be inspected before installation.
10. Why should the compressor model and serial number be verified before ordering?
Different compressor generations may use different oil-filter designs. Verification helps ensure the replacement element matches the installed lubrication system.
