Ingersoll Rand 47667845001 54601513 Air/Oil Separator Element
Ingersoll Rand 47667845001 54601513 Air/Oil Separator Element
0.0
Points
Brand:Ingersoll Rand Item No.: 47667845001 54601513 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47667845001 54601513 Air/Oil Separator Element is intended for scheduled service on compatible rotary screw compressors. The 47667845001 reference is associated with an 8,000-hour screw-machine maintenance package, while 54601513 identifies the air/oil separator element used across a range of Ingersoll Rand compressor configurations.
Oil-injected screw compressors use lubricant during compression for functions such as cooling, lubrication, and sealing. This creates an air/oil mixture that must be separated before compressed air enters the downstream system. The separator element performs this essential separation function, helping retain compressor oil while allowing compressed air to continue toward the outlet.
Good separator performance has a direct effect on compressor operating economics. Excessive oil carryover can increase lubricant consumption and introduce oil into downstream filters, dryers, piping, and production equipment. Maintaining the separator in suitable condition therefore contributes both to equipment protection and to compressed-air quality.
54601513 is documented for several compressor families, including EP75, EP100, HP75, HP100, XP75, XP100, XF75, and XF100 configurations. Because separator construction and fitment can vary between equipment generations, the complete machine identification should be checked before ordering a replacement.
Published supplier reference data gives approximate dimensions of 276 mm outside diameter, 295 mm maximum diameter, and 192 mm overall height, with a reported net weight of approximately 4.43 kg for one reference configuration. These values are aftermarket reference figures and should be verified against the applicable equipment documentation before installation planning.
For industrial maintenance teams, linking the 54601513 component reference with the 47667845001 service-package reference helps organize long-term service and spare-parts procurement. When separator maintenance is coordinated with oil-filter, air-filter, and coolant service, the result is a more comprehensive approach to compressor reliability.
Verify compressor model, serial number, and current parts documentation
Recommended Companion Models
Model
Product Name
39911631
Oil Filter Element
39708466
Air Filter Element
47638842001
Primary Air Filter Element
47638843001
Air Filter Safety Element
Frequently Selected Alternatives
Model
Product Name
54625942
Air/Oil Separator Element
54595442
Air/Oil Separator Element
54720735
Air/Oil Separator Element
54601513
Air/Oil Separator Element
Where It Excels in Industrial Use
8,000-Hour Screw Machine Maintenance: 47667845001 is associated with an 8,000-hour screw-machine maintenance package, supporting structured long-interval service planning.
Air/Oil Separation: 54601513 is an air/oil separator element designed for compatible Ingersoll Rand rotary screw compressor systems.
Compressed-Air Quality Management: Effective separation helps limit lubricant carryover into downstream compressed-air equipment and distribution systems.
Lubricant Recovery: The separator supports the recovery of entrained compressor oil from the compressed-air stream, helping maintain the intended oil circulation within the compressor.
Continuous Industrial Operation: Proper separator maintenance is important for compressors operating for extended periods under demanding production conditions.
Key Strengths at a Glance
Dedicated Separator Element: 54601513 is identified as an Ingersoll Rand separator-tank element for compatible compressor configurations.
Broad Application Range: Published application information associates the reference with EP75, EP100, HP75, HP100, XP75, XP100, XF75, and XF100 configurations.
Oil Carryover Control: Proper separator performance helps reduce the amount of compressor lubricant leaving with the compressed air.
Maintenance-Critical Component: Separator condition can influence oil consumption, compressed-air cleanliness, and overall compressor operating performance.
Application-Specific Fitment: Separator selection should be confirmed against the compressor model, serial number, and current service-parts documentation.
Technical FAQs
1. What is Ingersoll Rand 54601513?
54601513 is an Ingersoll Rand air/oil separator element used in compatible rotary screw compressor systems.
2. What is 47667845001?
47667845001 is associated with an 8,000-hour preventive maintenance package for an Ingersoll Rand screw machine.
3. What is the relationship between 47667845001 and 54601513?
47667845001 identifies the maintenance-package reference, while 54601513 identifies the separator element. The exact contents of the maintenance package should be confirmed against the applicable compressor parts documentation.
4. What does an air/oil separator do?
The separator removes entrained compressor oil from the compressed-air stream after the air/oil mixture leaves the compression stage.
5. Why is separator performance important?
Effective separation helps control oil carryover, reduce lubricant consumption, and protect downstream compressed-air equipment from excessive oil contamination.
6. Which compressor configurations are associated with 54601513?
Published application information includes EP75, EP100, HP75, HP100, XP75, XP100, XF75, and XF100 configurations. Exact compatibility must be verified for the individual compressor.
7. What can cause excessive oil carryover?
Possible causes include a saturated or damaged separator, excessive oil level, incorrect operating conditions, oil-return problems, or faults elsewhere in the separation system.
8. Can another separator be substituted based only on physical dimensions?
No. Separator media, airflow capacity, pressure characteristics, sealing configuration, and oil-return requirements must be compatible with the specific compressor.
9. What should be inspected during separator replacement?
Inspect the separator vessel, sealing surfaces, gaskets or O-rings, oil-return system, mounting arrangement, and related piping for contamination, leakage, or damage.
10. How should the separator replacement interval be determined?
Follow the compressor manufacturer's maintenance schedule while considering operating hours, separator differential pressure, oil carryover, lubricant condition, and actual operating environment.
