Introduction
The Ingersoll Rand 47642697001 39454558 Motor-to-Gearcase Gasket is a maintenance-focused sealing component for compatible compressor drive assemblies. 47642697001 identifies a gearbox maintenance kit associated with older Cobra M90-160 compressors, while 39454558 serves the critical sealing function at the motor-to-gearcase interface.
The motor and gearcase form an important part of the compressor's mechanical drive system. Their mating surfaces must remain securely sealed throughout operation, particularly where lubricant is contained within the gearcase. A gasket that has deteriorated or been disturbed during disassembly can become a potential source of leakage after reassembly.
For gearbox overhaul work, replacing the gasket provides a straightforward way to renew the static sealing interface. It also helps maintenance personnel avoid relying on an old compressed gasket whose original sealing characteristics may have changed during years of thermal cycling and mechanical service.
The relationship between 47642697001 and 39454558 should be treated as an associated maintenance reference rather than confirmation of package contents. The first number identifies the gearbox maintenance kit, whereas 39454558 identifies a specific gasket. The applicable compressor bill of materials should therefore be checked before assuming that this gasket is supplied with the complete kit.
Correct installation is just as important as correct part selection. Mating surfaces should be clean and free from damage, the gasket should be positioned correctly, and fasteners should be tightened according to the applicable service procedure. These details help maintain consistent joint compression and minimize the risk of leakage.
For purchasing and maintenance teams, using the correct Ingersoll Rand gasket reference can simplify gearbox service planning and reduce the possibility of rework. When servicing older compressor platforms, verifying the model and serial number before ordering remains the best way to confirm application-specific fitment.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Ingersoll Rand |
| Maintenance Kit Number | 47642697001 |
| Maintenance Kit Type | Gearbox Maintenance Kit |
| Maintenance Kit Application | Older Cobra M90-160 compressor family |
| Component Number | 39454558 |
| Product Type | Motor-to-Gearcase Gasket |
| Primary Function | Static sealing between motor and gearcase |
| Installation Location | Motor-to-gearcase interface |
| Sealing Type | Static gasket seal |
| Material | Application-specific; verify current parts documentation |
| Thickness | Application-specific; verify applicable parts documentation |
| Overall Dimensions | Application-specific; verify applicable parts documentation |
| Bolt-Hole Pattern | Application-specific |
| Temperature Rating | Application-specific |
| Pressure Rating | Application-specific |
| Fluid Compatibility | Application-specific |
| Weight | Application-specific; verify applicable parts documentation |
| Installation | Follow applicable Ingersoll Rand gearbox service procedure |
| Compatibility | Verify compressor model, motor configuration, and serial number |
| Package Contents | Verify against the applicable gearbox maintenance-kit bill of materials |
Recommended Companion Models
| Model | Product Name |
| 89292445 | High-Pressure Shaft Seal |
| 89292478 | Motor Shaft Sleeve |
| 95023388 | O-Ring |
| 22880744 | Seal Housing |
These components are relevant to motor and gearcase service on compatible Ingersoll Rand compressor configurations. Actual fitment should be confirmed against the applicable compressor parts list before ordering.
Frequently Selected Alternatives
| Model | Product Name |
| 39454566 | Gearcase Gasket |
| 39454574 | Motor-to-Gearcase Gasket |
| 39454582 | Gearcase Gasket |
| 39454590 | Motor Housing Gasket |
