Introduction
Ingersoll Rand 47572176001 is a preventive maintenance kit, while 23545841 is an air/oil separator element used in applicable oil-injected rotary screw compressor systems.
The air/oil separator performs a critical role after the compression stage. Compressor lubricant is introduced during compression to provide cooling, sealing, and lubrication, creating an air-oil mixture that must subsequently be separated. The separator captures the majority of entrained lubricant and supports its return to the compressor oil circuit while allowing compressed air to continue downstream.
Maintaining the separator is especially important in compressors operating for long periods or under high utilization. As the element accumulates contaminants, pressure drop can increase and separation performance can gradually decline. Replacing 23545841 during planned maintenance helps preserve oil recovery, control oil carryover, and support reliable compressor operation.
Technical Specifications
| Specification | Details |
|---|
| Brand | Ingersoll Rand |
| Preventive Maintenance Kit | 47572176001 |
| Separator Element | 23545841 |
| Product Type | Preventive Maintenance Kit and Air/Oil Separator Element |
| Component Type | Air/Oil Separator Element |
| Primary Function | Lubricant Separation |
| Main Performance Role | Oil Carryover Control |
| Secondary Function | Lubricant Recovery |
| Application | Oil-Injected Rotary Screw Compressor |
| Installation Position | Compressor Air/Oil Separation System |
| Dimensions | Not specified in the available product data |
| Weight | Not specified in the available product data |
Recommended Companion Models
| Model | Product Name |
|---|
| 23424922 | Coolant Oil Filter Element |
| 23523772 | Intake Pre-Filter Pad |
| 39218193 | High-Temperature Motor Grease |
| 99289894 | Minimum Pressure Valve Repair Kit |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 23487457 | Air/Oil Separator |
| 23566938 | Air/Oil Separator |
| 23708423 | Air/Oil Separator |
| 42841276 | Air/Oil Separator Element |
Technical FAQs
1. What is Ingersoll Rand 47572176001 used for?
47572176001 is a preventive maintenance kit associated with applicable Ingersoll Rand compressor configurations.
2. What is Ingersoll Rand 23545841?
23545841 is an air/oil separator element used in applicable Ingersoll Rand oil-injected rotary screw compressor systems.
3. What does an air/oil separator element do?
It separates compressor lubricant from the compressed-air stream after compression, allowing recovered oil to return to the lubrication circuit.
4. Why is oil carryover control important?
Excessive oil carryover can increase lubricant consumption and contaminate downstream compressed-air equipment and production systems.
5. What can cause separator differential pressure to rise?
Contamination, lubricant degradation, deposits, extended service intervals, and demanding operating conditions can progressively increase flow resistance.
6. What are typical indicators of separator deterioration?
Increasing oil consumption, visible oil downstream, contaminated air-treatment components, or abnormal compressor operating conditions can indicate reduced separation performance.
7. Can 23545841 be replaced with a separator having similar dimensions?
Not automatically. Filtration characteristics, construction, sealing arrangement, pressure capability, dimensions, and compressor compatibility must be verified.
8. Why are separator seals critical?
Correct sealing prevents air and lubricant from bypassing the intended separation path. Damaged or improperly fitted seals can significantly reduce separation effectiveness.
9. What should be checked during separator replacement?
Inspect the separator housing, sealing surfaces, oil-return path, connections, and surrounding components for contamination, deposits, leakage, damage, or abnormal wear.
10. How should 23545841 compatibility be verified?
Confirm the compressor model, serial number, separator configuration, existing element identification, and applicable Ingersoll Rand parts information before ordering or installation.
