Name: Ingersoll Rand 47572168001 23564446 PDM Filter Module
Brand: Ingersoll Rand
SKU: 18985
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

Ingersoll Rand 47572168001 23564446 combines the 47572168001 maintenance package with the 23564446 PDM filter element used in compatible compressor electrical-enclosure ventilation systems.

Unlike the primary compressor intake filter, the PDM filter serves a localized protective function around electrical and control equipment. It helps prevent airborne dust and debris from entering the enclosure while allowing ventilation airflow to pass through the designated filter path.

The 23564446 element is identified as a PDM filter and is associated with starter-box filtration applications. Its compact panel-style construction makes it suitable for installations where maintaining clean enclosure airflow is important without adding unnecessary bulk.

Filter condition can have a direct influence on ventilation performance. As particulate accumulates in the media, airflow resistance can increase. In dusty environments, regular inspection is therefore especially valuable, allowing maintenance teams to replace the element before restriction becomes significant.

For industrial compressor operators, 23564446 is a small but important maintenance component. Keeping the PDM filtration system clean supports enclosure ventilation, helps manage electrical-component temperatures, and contributes to dependable compressor operation.

Technical Specifications

Specification	Details
Brand	Ingersoll Rand
Maintenance Package Number	47572168001
Component Part Number	23564446
Product Type	PDM Filter Element
Module Type	PDM Filter Module
Primary Function	Electrical-enclosure air filtration
Associated System	Compressor starter / electrical enclosure
Filter Configuration	Panel-type filter element
Length	Approx. 279 mm
Width	Approx. 268 mm
Thickness	Approx. 17 mm
Approx. Dimensions	279 × 268 × 17 mm
Approx. Weight	0.10 kg
Packaged Weight	Approx. 0.18 kg
Service Role	Preventive maintenance
Compatibility	Verify compressor model and serial number

Recommended Companion Models

Model	Product Name
23424922	Ingersoll Rand Oil Filter Element
23487457	Ingersoll Rand Air Filter Element
23523772	Ingersoll Rand Pre-Filter Pad
23545841	Ingersoll Rand Air/Oil Separator Element

Frequently Selected Alternatives

Model	Product Name
23531593	Ingersoll Rand Inlet Valve Service Kit
23545840	Ingersoll Rand Air/Oil Separator Element
23566938	Ingersoll Rand Air/Oil Separator Element
40068371	Ingersoll Rand PDM Filter Element

Where It Excels in Industrial Use

Electrical enclosure protection: 23564446 is used as a PDM filter element to help keep airborne dust and particulate matter away from protected compressor electrical and control components.
Compressor ventilation: Supports clean airflow through the designated starter-box or electrical-enclosure ventilation path, helping maintain suitable thermal conditions.
Dust-prone production areas: Particularly useful in manufacturing and industrial environments where airborne contamination can accumulate quickly around compressor packages.
Scheduled maintenance: Provides a practical replacement option when inspection shows the existing filter is loaded, damaged, or no longer providing adequate airflow.

Key Strengths at a Glance

Dedicated PDM filtration: 23564446 is identified as an Ingersoll Rand PDM filter element for compatible compressor configurations.
Effective particulate control: Helps reduce dust and debris entering the protected electrical enclosure.
Supports cooling airflow: A clean filter helps maintain ventilation through the enclosure while avoiding unnecessary airflow restriction.
Compact panel construction: Its low-profile format is suited to the designated compressor filter assembly.
Maintenance-friendly replacement: Designed for straightforward renewal during routine compressor service.

Technical FAQs

1. What is Ingersoll Rand 23564446?

Ingersoll Rand 23564446 is a PDM filter element used in compatible compressor electrical-enclosure or starter-box ventilation systems.

2. What is the relationship between 47572168001 and 23564446?

47572168001 identifies the applicable maintenance package, while 23564446 identifies the individual PDM filter element.

3. What is the primary purpose of a PDM filter?

The filter helps remove airborne particulate contamination from ventilation air entering the protected electrical enclosure.

4. Why does electrical-enclosure filtration matter?

Reducing dust accumulation helps preserve airflow and supports effective heat dissipation around electrical and control components.

5. What types of contaminants can the filter help control?

It is intended to reduce airborne dust, dirt, fibers, and other particulate contaminants present in the surrounding compressor environment.

6. What happens when the filter becomes heavily loaded?

A heavily loaded filter can increase airflow resistance and reduce ventilation effectiveness, potentially contributing to higher enclosure temperatures.

7. Can poor enclosure ventilation affect electrical components?

Yes. Reduced airflow can interfere with heat dissipation and may increase thermal stress on temperature-sensitive electrical equipment.

8. Should the filter housing be cleaned during replacement?

Yes. The housing, retaining structure, sealing surfaces, and surrounding ventilation passages should be inspected and cleaned as necessary.

9. Can another filter with similar dimensions be substituted?

Not automatically. Filtration efficiency, airflow resistance, media characteristics, thickness, sealing, and physical compatibility should all be evaluated.

10. What should be verified before installing 23564446?

Confirm the compressor model, serial number, PDM/starter-box configuration, existing part number, filter arrangement, and applicable maintenance procedure.
