Introduction

The Allen Bradley MPL-A330P-MK74AA Servo Motor is a premium low-inertia brushless AC servo motor from the Allen Bradley MP-Series MPL range. It is designed for industrial motion systems where motor responsiveness and precise feedback are just as important as basic torque production.

The motor features a 100 mm frame size and a 76.2 mm magnet stack length, providing a compact mechanical package for machinery that requires high dynamic performance without using an excessively large motor. Its 5,000 RPM operating capability makes it suitable for high-cycle automation where rapid rotary motion is part of the production process.

One of the most important features is the multi-turn high-resolution absolute encoder. Unlike a basic incremental feedback arrangement, an absolute multi-turn feedback system can provide position information across multiple revolutions, making it particularly valuable in applications where accurate position tracking is essential.

The integrated 24 V DC holding brake adds another practical advantage. In applications involving vertical loads or positioning at rest, a holding brake can help secure the shaft when the servo system is not actively driving the motor. The brake should, however, be treated as a holding device and not as the primary method of controlling machine deceleration.

The motor also uses a keyless shaft extension and right-angle SpeedTEC DIN connectors. These details are important when replacing an existing motor because mechanical shaft interfaces and connector arrangements need to match the machine's existing design.

For maintenance teams, exact model identification is especially important with servo motors. Two motors from the same MPL family may share a similar frame but have different magnet-stack lengths, feedback systems, brake options, shaft configurations, or electrical characteristics.

The MPL-A330P-MK74AA is therefore well suited to applications that demand fast response, accurate feedback, compact construction, and dependable integration within an Allen Bradley motion-control environment.

Technical Specifications

Specification	Details
Brand	Allen Bradley
Manufacturer	Rockwell Automation
Product Family	MP-Series MPL
Model	MPL-A330P-MK74AA
Product Type	AC Servo Motor
Motor Type	Low-Inertia Brushless Servo Motor
Voltage Class	230 V AC
Frame Size	100 mm
Magnet Stack Length	76.2 mm (3.00 in.)
Rated Speed	5,000 RPM
Rated Torque	4.18 N·m
Feedback	Multi-Turn High-Resolution Absolute Encoder
Shaft Type	Keyless Shaft Extension
Connector	SpeedTEC DIN, Right Angle, 180° Rotatable
Brake	24 V DC Holding Brake
Mounting	IEC Metric, Free Mounting Holes
Environmental Protection	IP50 Standard Housing
Dimensions	Not supplied
Weight	4.60 kg (10.14 lb)
Application	Industrial Motion Control

Weight: 4.60 kg (10.14 lb)

The frame size, voltage class, speed, feedback, brake, connector arrangement, and other technical characteristics above correspond to the identified MPL-A330P-MK74AA configuration. The supplied product information did not include overall motor dimensions, so no unverified dimensional value has been added.

Recommended Related Models

For customers maintaining Allen Bradley MP-Series MPL servo systems, the following models are useful related references:

Allen Bradley MPL-A310P-MK72AA – Servo Motor
Allen Bradley MPL-A320P-MK72AA – Servo Motor
Allen Bradley MPL-A330P-MK74AA – Servo Motor
Allen Bradley MPL-A430P-MK74AA – Servo Motor
Allen Bradley MPL-A450P-MK74AA – Servo Motor

The MPL-A310P-MK72AA and MPL-A320P-MK72AA provide shorter stack-length alternatives within the 100 mm frame class, while the MPL-A430P-MK74AA moves to a larger 115 mm frame. Exact electrical, feedback, brake, and mechanical specifications must be checked before selecting a replacement.

Popular Related Models

For industrial customers working with Allen Bradley servo-motion equipment, these models are also useful references:

Allen Bradley MPL-A310P-MK72AA – Servo Motor
Allen Bradley MPL-A320P-MK72AA – Servo Motor
Allen Bradley MPL-A430P-MK74AA – Servo Motor
Allen Bradley MPL-A453F-MK72AA – Servo Motor
Allen Bradley MPL-A454F-MK74AA – Servo Motor

When sourcing the Allen Bradley MPL-A330P-MK74AA Servo Motor, always use the complete catalog number. The suffix identifies important characteristics such as feedback, shaft design, connector arrangement, and brake configuration, so matching only the general MPL series or frame size is not sufficient for a reliable replacement.

Applications

The Allen Bradley MPL-A330P-MK74AA Servo Motor is a low-inertia brushless AC servo motor from the MP-Series MPL family, developed for industrial motion-control applications where rapid response, repeatable positioning, and smooth dynamic performance are important.

Its 100 mm frame size, 5,000 RPM rated speed, multi-turn high-resolution absolute encoder, and 24 V DC holding brake make it well suited to machines that demand accurate motion while maintaining a compact motor footprint.

The motor can be applied to:

Automated assembly machines
Packaging equipment
Material handling systems
Pick-and-place machinery
Machine tools
Semiconductor and electronics equipment
Printing and converting machinery
Industrial indexing systems
Precision positioning applications
Automated production lines
Robotic auxiliary axes
High-speed manufacturing equipment

The low-inertia rotor design is particularly useful in motion applications where rapid acceleration and deceleration are important. When paired with a suitable Allen Bradley Kinetix servo drive and correctly configured motion controller, the MPL-A330P-MK74AA can provide responsive and repeatable machine movement.

Advantages

Low-inertia motion performance
The MPL-A330P-MK74AA is designed around a low-inertia brushless servo motor architecture, making it well suited to applications requiring rapid changes in speed and direction.

High-speed operation
With a rated speed of up to 5,000 RPM, the motor can support fast machine cycles where high rotational speed is an important design requirement.

High-resolution absolute feedback
The integrated multi-turn high-resolution encoder provides absolute position feedback, supporting applications where accurate positioning and repeatable motion are critical.

Integrated 24 V DC brake
The motor incorporates a 24 V DC brake, providing a useful holding function for applications where the motor shaft needs to remain secured when the drive is disabled.

230 V AC servo platform
The motor is designed for the 230 V class of Allen Bradley MP-Series MPL servo systems, providing a suitable foundation for compatible Kinetix motion-control applications.

Keyless shaft configuration
The keyless shaft extension simplifies the mechanical interface for compatible machine designs and should be matched with the specified coupling arrangement.

Rotatable right-angle connectors
The SpeedTEC DIN connector arrangement is designed for practical machine integration, with the connector assembly capable of right-angle orientation.

Long-term service value
The MPL family is well established in industrial motion applications, making the MPL-A330P-MK74AA a useful replacement and maintenance option for existing motion-control systems.
