Brand:Schneider PLC Item No.:TM5SPDG6D6F Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SPDG6D6F Power Distribution Module is a compact and reliable power management component designed for Modicon TM5 automation systems. It provides dedicated 24 V DC and 0 V DC distribution points, helping engineers simplify field wiring while improving the reliability of industrial control installations.
With integrated fuse protection, high current distribution capability, and a modular DIN rail design, the TM5SPDG6D6F supports efficient power management in demanding automation environments. It is especially suitable for machine builders, OEM control panels, and industrial systems requiring flexible and structured I/O power distribution.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM5SPDG6D6F
Product Family
Modicon TM5
Module Type
Power Distribution Module
Distribution Type
0 V DC / 24 V DC Distribution
Number of 0 V DC Connections
6
Number of 24 V DC Connections
6
Rated Supply Voltage
24 V DC
Power Source
24 V DC I/O Power Segment
Maximum Current Capacity
6.3 A
Protection Type
Replaceable Slow-Blow Fuse
Fuse Rating
6.3 A / 250 V
TM5 Bus Current Consumption
24 mA
Maximum Power Dissipation
1.27 W
Status Indicators
Module Status / Operating State
Mounting Type
DIN Rail
Protection Rating
IP20
Operating Temperature
0°C to +60°C
Dimensions
Approx. 12.5 × 99 × 75 mm
Weight
Approx. 25 g
Recommended Companion Models
Model
Product Name
Schneider TM5ACBM15
TM5 Addressable Bus Base Module
Schneider TM5ACTB12
TM5 Terminal Block
Schneider TM5SPS2
TM5 Power Supply Module
Schneider TM5SDI6D
TM5 Digital Input Module
Frequently Selected Alternatives
Model
Product Name
Schneider TM5SPDG12F
TM5 Power Distribution Module
Schneider TM5SPDG6U
TM5 Power Distribution Module
Schneider TM5SPS2
TM5 Power Supply Module
Schneider TM5ACBM11
TM5 Bus Base Module
Where It Excels in Industrial Use
• Distributed I/O Power Management Systems
Designed for Modicon TM5 automation architectures requiring efficient 24 V DC power distribution to multiple I/O devices while maintaining organized field wiring.
• Complex Machine Control Cabinets
Ideal for large automation systems where multiple sensors, actuators, and I/O modules require separated and reliable 0 V DC and 24 V DC distribution points.
• OEM Machinery and Modular Automation Equipment
Provides a practical power distribution solution for machine builders creating scalable control systems with simplified wiring layouts.
• Industrial Field Device Integration
Suitable for applications where multiple field devices need stable power connections through a compact DIN rail mounted module.
Key Strengths at a Glance
• Dedicated 24 V DC Power Distribution
Provides six 0 V DC and six 24 V DC distribution connections from the TM5 24 V DC I/O power segment, improving wiring organization and system flexibility.
• Integrated Fuse Protection Design
Includes a replaceable 6.3 A slow-blow fuse to enhance circuit protection and improve maintenance efficiency.
• High Current Distribution Capability
Supports up to 6.3 A current handling for the 24 V DC I/O power segment, making it suitable for demanding industrial control applications.
• Compact TM5 Modular Architecture
Designed for seamless integration into Modicon TM5 systems, helping reduce cabinet space requirements while maintaining reliable power distribution.
Technical FAQs
1. What type of module is the Schneider TM5SPDG6D6F?
The Schneider TM5SPDG6D6F is a power distribution module designed for the Modicon TM5 modular I/O system.
2. What is the main function of the TM5SPDG6D6F?
The module distributes 0 V DC and 24 V DC power connections from the TM5 I/O power segment to connected field devices and I/O components.
3. How many power distribution connections does the TM5SPDG6D6F provide?
The module provides six 0 V DC connections and six 24 V DC connections.
4. What supply voltage does the TM5SPDG6D6F use?
The module operates with a 24 V DC I/O power segment supply.
5. Does the TM5SPDG6D6F include short-circuit protection?
Yes. The module includes an integrated replaceable 6.3 A slow-blow fuse for circuit protection.
6. Which Schneider Electric controllers are compatible with the TM5SPDG6D6F?
The module is designed for Modicon TM5 systems and can be used with compatible controllers such as Modicon M258 and LMC058 platforms.
7. Can the TM5SPDG6D6F supply external field devices?
Yes. The module provides distributed 24 V DC and 0 V DC connection points for compatible field devices connected within the same I/O power segment.
8. What type of installation does the TM5SPDG6D6F support?
The module is designed for DIN rail installation within industrial control cabinets.
9. Does the TM5SPDG6D6F provide diagnostic indication?
Yes. The module includes status indicators for monitoring operating conditions and module status.
10. What applications commonly use the TM5SPDG6D6F?
Typical applications include industrial automation cabinets, machine control systems, distributed I/O stations, and OEM equipment requiring organized 24 V DC power distribution.
