Allen Bradley 20BC140G0ANNANC0 PowerFlex 700 AC Drive
Allen Bradley 20BC140G0ANNANC0 PowerFlex 700 AC Drive
0.0
Points
Brand:Allen Bradley PLC Item No.:20BC140G0ANNANC0 Product Origin:USA Product Dimensions:1574.8 x 609.6 x 450.7 mm Product Weight:102.51 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 20BC140G0ANNANC0 PowerFlex 700 AC Drive is a high-current variable frequency drive designed for controlling AC motors in industrial automation and manufacturing applications. It combines a 140 A current rating with a 400 VAC three-phase electrical configuration and a wall or machine-mount enclosure suitable for more demanding industrial environments.
The model is specified for 75 kW normal-duty operation and 55 kW heavy-duty operation. Its vector-control architecture with 24 V I/O provides a practical solution for applications requiring controlled motor operation and integration with external automation equipment.
One of the most important differences between this model and many cabinet-mounted PowerFlex 700 configurations is its enclosure and mounting arrangement. The 20BC140G0ANNANC0 is specified as a wall/machine-mount drive with IP54 and NEMA Type 12 protection. This allows it to be used in installations where increased enclosure protection is required.
The drive is supplied with an EMC filter and common-mode choke. These features are useful considerations when designing an industrial motor-control system where electromagnetic compatibility and electrical noise need to be managed.
The supplied dimensions are 1574.8 × 609.6 × 450.7 mm, and the weight is 102.51 kg. With this substantial physical size and weight, mechanical installation requires careful planning. Mounting supports must be capable of carrying the drive safely, while adequate space should be provided for cable connections, ventilation, inspection, and servicing.
The drive is intended for a 400 VAC nominal system with a 380–480 VAC rating. Before commissioning, the plant supply should be checked to ensure compatibility with the drive. Motor voltage and current must also be compared with the drive's rating and the requirements of the actual machine.
The 20BC140G0ANNANC0 does not include an internal brake resistor or brake IGBT. This is an important consideration for applications involving high-inertia loads, rapid stopping, or frequent acceleration and deceleration. If regenerative energy is expected, an appropriate external braking arrangement should be evaluated.
During commissioning, technicians should verify incoming power, grounding, motor wiring, control signals, safety interlocks, and parameter settings. The motor nameplate information should be entered accurately so that the drive's control system can operate according to the characteristics of the connected motor.
Initial operation should be performed at a controlled speed. Motor current, rotation direction, acceleration, deceleration, and mechanical response should be monitored before the machine is operated across its full speed range.
For troubleshooting, technicians should avoid assuming that every fault is caused by the drive. Mechanical overload, damaged motor cables, incorrect parameters, poor ventilation, control interlocks, and unstable reference signals can all produce symptoms that appear to be drive-related.
For replacement projects, the full catalog number is especially important. A different 140 A PowerFlex 700 may have a different enclosure, mounting arrangement, control voltage, feedback option, braking configuration, or communication setup.
The Allen Bradley 20BC140G0ANNANC0 is therefore best suited to industrial motor-control applications where its 400 VAC, 140 A, wall/machine-mount, IP54 configuration matches the electrical, mechanical, and environmental requirements of the installation.
