Ingersoll Rand 47560122001 92888262 Water Cooled Preventive Maintenance Kit
Ingersoll Rand 47560122001 92888262 Water Cooled Preventive Maintenance Kit
0.0
Points
Brand:Ingersoll Rand Item No.:47560122001 92888262 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47560122001 92888262 Water Cooled Preventive Maintenance Kit is designed for planned major service on compatible industrial rotary screw compressor systems. The 47560122001 reference represents the water cooled preventive maintenance configuration, while 92888262 identifies the associated filtration element used within the compressor fluid circuit.
The 92888262 component is widely identified as an oil or coolant filter element for compatible Ingersoll Rand compressor applications. Its role is to help retain contamination from circulating lubricant, supporting cleaner fluid circulation and helping protect internal compressor components.
For maintenance teams managing demanding industrial equipment, scheduled filter replacement remains an important part of a disciplined preventive maintenance strategy. Using the complete product designation helps maintain consistency between purchasing, inventory control, and service planning.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Complete Model
47560122001 92888262
Module Type
Water Cooled Preventive Maintenance Kit
Maintenance Interval
8000 hours
Cooling Configuration
Water cooled
Associated Compressor Family
M200 250 2S
Maintenance Kit Reference
47560122001
Filter Reference
92888262
Filter Type
Oil Filter Element
Alternate Description
Coolant Filter Element
Filtration Application
Compressor lubricant and coolant circuit
Filter Quantity
2
Filtration Rating
5 micron
Outer Diameter
Approximately 137 mm
Height
Approximately 305 mm
Thread
UN 1.1 2 inch female
Working Pressure
Up to 20 bar
Filter Net Weight
Approximately 2.09 kg
Complete Kit Dimensions
Dependent on supplied components and packaging configuration
Complete Kit Weight
Dependent on supplied components and packaging configuration
The published specifications above describe the individual 92888262 filter element. Complete maintenance kit dimensions and shipment weight can vary according to the supplied components and packaging configuration.
Recommended Companion Models
Model
Product Name
47560122001 22125249
Water Cooled Preventive Maintenance Kit with Thermostatic Valve Element
47560122001 22219174
Water Cooled Preventive Maintenance Kit with Separator Element
47560122001 39218193
Water Cooled Preventive Maintenance Kit with Motor Grease SHC220
47560122001 47701890001
Water Cooled Preventive Maintenance Kit with Air Filter Element
Frequently Selected Alternatives
Model
Product Name
47560122001 99289894
Water Cooled Preventive Maintenance Kit with Minimum Pressure Valve Repair Kit
47560122001 47556927001
Water Cooled Preventive Maintenance Kit with Water Cooler Seal Kit
47560121001 92888262
Water Cooled Preventive Maintenance Kit with Oil Filter Element
47560116001 92888262
Air Cooled Preventive Maintenance Kit with Oil Filter Element
Where It Excels in Industrial Use
• Designed for scheduled 8000 hour preventive maintenance on compatible Ingersoll Rand M200 250 2S water cooled rotary screw compressor systems.
• Incorporates 92888262, a coolant and oil filtration element used for compatible M200 350 compressor applications.
• Supports cleaner lubricant circulation by capturing contamination and wear particles within the compressor fluid circuit.
• Well suited to industrial facilities where dependable filtration, planned maintenance, and long term compressor reliability are essential.
Key Strengths at a Glance
• Complete model designation is Ingersoll Rand 47560122001 92888262.
• 47560122001 identifies the water cooled preventive maintenance configuration for the applicable M200 250 2S compressor family.
• 92888262 is identified as an oil filter element and coolant filter element for compatible Ingersoll Rand compressor systems.
• The maintenance configuration specifies two 92888262 filter elements for the relevant service application.
• Proper filter replacement helps maintain clean lubricant circulation and supports protection of critical compressor components.
Technical FAQs
What is the Ingersoll Rand 47560122001 92888262?
The Ingersoll Rand 47560122001 92888262 is a complete product designation combining a water cooled preventive maintenance kit reference with the specified 92888262 oil and coolant filter element.
What maintenance interval is associated with 47560122001?
The 47560122001 reference is associated with an 8000 hour preventive maintenance configuration for compatible water cooled M200 250 2S compressor systems.
What is 92888262?
92888262 is an Ingersoll Rand filtration component described as a coolant filter and oil filter element for compatible compressed air equipment.
What is the primary function of the 92888262 filter?
The filter captures contamination and particles circulating in the compressor lubricant or coolant circuit to help protect internal components.
How many 92888262 filters are associated with the maintenance configuration?
The available maintenance listing identifies two 92888262 coolant filter elements for the relevant service configuration.
Why is oil filtration important in a rotary screw compressor?
Clean lubricant circulation helps reduce the movement of contaminants and wear particles through the compressor system, supporting reliable operation and component protection.
Is 92888262 a complete preventive maintenance kit?
No. 92888262 identifies the individual filtration component, while 47560122001 identifies the preventive maintenance kit reference.
Can the filter be used as a universal replacement?
No. Compatibility should be verified against the compressor model, serial number, operating configuration, and current parts documentation before installation.
What should be checked before replacing the filter?
The correct part number, compressor application, service interval, and fluid system configuration should be confirmed before replacement.
Why should the complete model designation be retained?
Using the full designation Ingersoll Rand 47560122001 92888262 helps maintain accurate identification of the requested maintenance configuration and associated filtration component.
