Ingersoll Rand 47579615001 23969298 Air-Cooled Service and Condensate Drain Configuration

Where It Excels in Industrial Use

• The complete 47579615001 23969298 configuration combines an 8,000-hour air-cooled maintenance package with the specified condensate drain solenoid valve for compatible Ingersoll Rand oil-free compressor systems.

• Designed for industrial installations where extended-interval compressor servicing must be coordinated with reliable automatic condensate discharge.

• Well suited to manufacturing plants, process-air facilities, utilities, and other continuous-duty applications using compatible IRN 90–160 kW oil-free compressors.

• The 23969298 component is identified as a condensate drain solenoid valve and is listed as a replacement for 22410286 in applicable configurations.

• Provides a consolidated service reference covering both major scheduled maintenance and an important condensate-management component.

Key Strengths at a Glance

• Extended service planning: 47579615001 is identified as an 8,000-hour air-cooled maintenance package for the IRN160K-of platform.

• Automatic condensate discharge: 23969298 provides electrically actuated control of condensate drainage in applicable compressor systems.

• Moisture management: Proper condensate discharge helps prevent accumulated moisture from remaining in the designated drainage circuit.

• Air-cooled application: The primary maintenance package is associated with the air-cooled IRN160K-of configuration.

• Service coordination: The combined reference helps maintenance teams organize extended-interval service alongside inspection or replacement of the condensate drain valve.

Technical FAQs

1. What is Ingersoll Rand 47579615001?

47579615001 is an 8,000-hour air-cooled maintenance package identified for the IRN160K-of oil-free compressor platform.

2. What is 23969298?

23969298 is a condensate drain solenoid valve used in applicable Ingersoll Rand compressor configurations and is identified as a replacement for 22410286 in relevant applications.

3. What does the condensate drain solenoid valve do?

The valve electrically controls the discharge of accumulated condensate from the applicable drainage circuit.

4. Why is condensate drainage important in compressor systems?

Removing accumulated condensate helps prevent moisture from remaining in the designated drainage system and supports proper operation of downstream condensate-management components.

5. Is 23969298 part of the compressor's main air-compression circuit?

No. It is associated with the condensate drainage system rather than the primary compressed-air generation path.

6. What should be checked before installing 23969298?

The compressor model, serial number, existing drain assembly, valve reference, electrical requirements, connection arrangement, and current Ingersoll Rand parts documentation should be verified.

7. What can indicate a condensate drain valve problem?

Persistent condensate accumulation, failure to discharge, continuous leakage, abnormal cycling, or electrical faults can indicate that the drain valve or its control circuit requires inspection.

8. What operating conditions can affect condensate-drain performance?

Ambient temperature, humidity, compressor loading, condensate volume, contamination, and the condition of the drainage circuit can all influence condensate-management performance.

9. Can 23969298 be replaced solely based on voltage or physical fit?

No. Electrical characteristics, connection configuration, pressure conditions, valve function, and compressor-specific approval should all be confirmed before replacement.

10. Does the 47579615001 23969298 configuration modify compressor controls?

No. The configuration concerns scheduled maintenance and condensate drainage and does not constitute a modification to the compressor's primary control or drive system.
