Ingersoll Rand 47579613001 / 39911615 Heavy-Duty 8,000-Hour Air-Cooled Sierra 200-300 Maintenance Package with Oil Filter Element
Ingersoll Rand 47579613001 / 39911615 Heavy-Duty 8,000-Hour Air-Cooled Sierra 200-300 Maintenance Package with Oil Filter Element
0.0
Points
Brand:Ingersoll Rand Item No.: 47579613001 39911615 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47579613001 / 39911615 configuration is intended for scheduled maintenance of Sierra 200-300 air-cooled compressor systems. Part number 47579613001 identifies the 8,000-hour air-cooled maintenance package, while 39911615 identifies the associated oil filter element.
The 39911615 filter supports oil filtration in applicable compressor lubrication systems. Available filter specifications identify an approximately 223.6 mm overall height, 97 mm outside diameter, and 1-3/8-inch UNF 12-thread connection, with an approximate net weight of 1.21 kg.
For replacement planning, the compressor model, configuration, and existing filter part number should be verified before installation.
Technical Specifications
Specification
Details
Manufacturer
Ingersoll Rand
Maintenance Package Part Number
47579613001
Associated Component Part Number
39911615
Maintenance Package Type
Air-cooled maintenance package
Maintenance Interval
8,000 hours
Applicable Compressor Range
Sierra 200-300
Component Type
Oil filter element
Application
Compressor oil filtration
Filter Height
Approx. 223.6 mm
Outside Diameter
Approx. 97 mm
Connection
1-3/8-inch UNF, 12 thread
Approximate Filter Weight
1.21 kg
Filter Media
Inorganic microfibers, 25 µm specification
Working Pressure
Approx. 35 bar
Element Collapse Pressure
Approx. 20 bar
Complete Configuration Dimensions
Not reliably published as a fixed value
Complete Configuration Weight
Not reliably published as a fixed value
Recommended Companion Models
• 47579611001 — 8,000-Hour Air-Cooled Maintenance Package – Sierra 37-75
• 47579612001 — 8,000-Hour Air-Cooled Maintenance Package – Sierra 90-150
• 47579354001 — 8,000-Hour Water-Cooled Maintenance Kit – Sierra 200-300
• 47578985001 — 2,000-Hour Maintenance Package – Sierra 200-300
• 47579187001 — 4,000-Hour Maintenance Package – Sierra 200-300
• 47579628001 — Water-Cooled Hose Package – Sierra 200-300
Where It Fits in Industrial Applications
• Designed for scheduled 8,000-hour maintenance of Ingersoll Rand Sierra 200-300 air-cooled compressor systems.
• Combines the scheduled maintenance package with the 39911615 oil filter element for applicable compressor configurations.
• Supports filtration of compressor lubricant to help reduce the circulation of particles and contaminants.
• Suitable for planned maintenance programs where the compressor oil filter is replaced during scheduled servicing.
• Supports industrial compressor service operations and organized spare-parts inventory management.
Key Strengths at a Glance
• 8,000-hour air-cooled maintenance package for Sierra 200-300 applications.
• Includes the 39911615 oil filter element as the associated component.
• Designed for compressor oil filtration in applicable Ingersoll Rand systems.
• Published filter specifications identify an approximately 223.6 mm height and 97 mm outside diameter.
• Suitable for scheduled lubrication-system maintenance and oil-filter replacement.
Technical FAQs
1. What is Ingersoll Rand 47579613001?
47579613001 is an 8,000-hour air-cooled maintenance package identified for Ingersoll Rand Sierra 200-300 compressor applications.
2. What is Ingersoll Rand 39911615?
39911615 is an oil filter element used in applicable Ingersoll Rand compressor lubrication systems.
3. What is the function of the 39911615 oil filter?
The element filters contaminants from compressor oil to help maintain the cleanliness of the lubricant circulating through the applicable system.
4. What are the published dimensions of 39911615?
Available filter specifications identify an approximate overall height of 223.6 mm and an outside diameter of 97 mm.
5. What connection is used on the 39911615 filter?
The published specification identifies a 1-3/8-inch UNF connection with 12 threads.
6. What maintenance interval is associated with 47579613001?
47579613001 is identified as an 8,000-hour air-cooled maintenance package for the Sierra 200-300 range.
7. Is 39911615 suitable for every Ingersoll Rand compressor?
No. Compatibility depends on the compressor model and configuration. The existing filter part number and equipment documentation should be checked before replacement.
8. What is the approximate weight of 39911615?
A published filter specification lists an approximate net weight of 1.21 kg.
9. Why should the oil filter be replaced during scheduled maintenance?
Regular filter replacement helps maintain effective oil filtration and reduces the accumulation of contaminants within the compressor lubrication circuit.
10. Are the dimensions and weight of the complete 47579613001 / 39911615 configuration fixed?
No. Reliable fixed package-level dimensions and weight are not published for the complete maintenance configuration.
