Brand:Ingersoll Rand Item No.:24784910 22744908 Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 24784910 / 22744908 configuration combines the 24784910 oil relief valve service kit with the 22744908 OEM check valve cartridge. The service kit is intended for maintenance of the applicable oil relief valve, while the check valve cartridge provides the associated cartridge-style check-valve component.
This configuration is suitable for planned service and repair work on compatible Ingersoll Rand industrial air compressor oil systems. Exact applicability should be confirmed against the compressor model, serial number, and current parts documentation before installation.
Technical Specifications
Parameter
Specification
Brand
Ingersoll Rand
Primary Service Kit
24784910
Associated Component
22744908
Service Kit Type
Oil relief valve service kit
Component Type
Check valve cartridge
Component Status
OEM
Application
Compatible Ingersoll Rand industrial air compressors
Service Area
Compressor oil-control system
Product Type
Oil relief valve and check cartridge service configuration
Installation
Maintenance and service replacement
Dimensions
Not reliably published as a fixed value for the complete configuration
Weight
Not reliably published as a fixed value for the complete configuration
Ingersoll Rand RS315-355 Industrial Air Compressor
Frequently Selected Alternatives
Model
Product Name
24784910
Ingersoll Rand Oil Relief Valve Service Kit
22744908
Ingersoll Rand OEM Check Valve Cartridge
23650633
Ingersoll Rand Discharge Check Valve
47642922001
Ingersoll Rand Glass-Filled PTFE Check Valve Seat
Where It Fits in Industrial Applications
• Designed for maintenance of compatible Ingersoll Rand industrial air compressor oil-system assemblies.
• 24784910 is identified as a service kit for the oil relief valve.
• 22744908 is identified as an OEM check valve cartridge.
• The configuration is intended for service work involving the applicable oil relief and check-valve components.
Key Strengths at a Glance
• Combines the oil relief valve service kit with the associated check valve cartridge.
• Supports planned maintenance of the compressor oil-control circuit.
• Provides a coordinated configuration for servicing valve components associated with oil pressure and flow control.
• Suitable for maintenance programs where the specified equipment documentation calls for these two part numbers.
Technical FAQs
1. What is Ingersoll Rand 24784910?
24784910 is identified as an Ingersoll Rand service kit for the oil relief valve.
2. What is Ingersoll Rand 22744908?
22744908 is identified as an OEM check valve cartridge for compatible Ingersoll Rand compressor equipment.
3. What is the purpose of combining these two part numbers?
For this product listing, the two supplied part numbers are treated as one complete service configuration, combining the oil relief valve service kit with the associated check valve cartridge.
4. Is 22744908 a complete check valve assembly?
22744908 is identified as a check valve cartridge, so it should not automatically be interpreted as a complete external valve assembly.
5. What is the function of an oil relief valve?
An oil relief valve forms part of the compressor oil circuit and helps control oil pressure by providing the applicable pressure-relief function.
6. Is 24784910 a standalone valve?
No. 24784910 is identified as a service kit for the oil relief valve.
7. Can this configuration be used on every Ingersoll Rand compressor?
No. Compatibility depends on the compressor model, serial number, oil-system design, and applicable parts documentation.
8. Is 22744908 an OEM component?
Yes. 22744908 is identified as an OEM Ingersoll Rand check valve cartridge.
9. Should the check valve cartridge be replaced at every maintenance interval?
Not necessarily. Replacement should follow the applicable service procedure and the condition of the installed component.
10. What should be verified before ordering this configuration?
The compressor model, serial number, existing oil relief valve and check-valve part numbers, service requirements, and current Ingersoll Rand parts documentation should be verified before ordering.
