Brand:Ingersoll Rand Item No.: 24784910 22744916 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 24784910 / 22744916 configuration combines the 24784910 oil relief valve service kit with the 22744916 check valve cartridge. The service kit is intended for maintenance of the applicable oil relief valve, while 22744916 provides the associated cartridge-style check valve in a listed 3 bar configuration.
This configuration is suitable for planned service and repair work on compatible Ingersoll Rand industrial air compressor oil systems. Exact applicability should be confirmed against the compressor model, serial number, and current parts documentation before installation.
Technical Specifications
Parameter
Specification
Brand
Ingersoll Rand
Primary Service Kit
24784910
Associated Component
22744916
Service Kit Type
Oil relief valve service kit
Component Type
Check valve cartridge
Check Valve Configuration
3 bar
Application
Compatible Ingersoll Rand industrial air compressors
Service Area
Compressor oil-control system
Product Type
Oil relief valve and check cartridge service configuration
Installation
Maintenance and service replacement
Dimensions
Not reliably published as a fixed value for the complete configuration
Weight
Not reliably published as a fixed value for the complete configuration
Ingersoll Rand RS315-355 Industrial Air Compressor
Frequently Selected Alternatives
Model
Product Name
22744908
Ingersoll Rand Check Valve Cartridge
22744916
Ingersoll Rand 3 Bar Check Valve Cartridge
23650633
Ingersoll Rand Discharge Check Valve
47642922001
Ingersoll Rand Glass-Filled PTFE Check Valve Seat
Where It Fits in Industrial Applications
• Designed for maintenance of compatible Ingersoll Rand industrial air compressor oil-system assemblies.
• 24784910 is identified as a service kit for the oil relief valve.
• 22744916 is identified as a check valve cartridge, with listings identifying the cartridge as a 3 bar configuration.
• The configuration is intended for service work involving the applicable oil relief and check-valve components.
Key Strengths at a Glance
• Combines the oil relief valve service kit with the associated check valve cartridge.
• Supports planned maintenance of compressor oil-pressure and flow-control components.
• The 22744916 cartridge provides a defined check-valve function within the applicable oil circuit.
• Suitable for maintenance programs where the specified compressor documentation calls for these two part numbers.
Technical FAQs
1. What is Ingersoll Rand 24784910?
24784910 is identified as an Ingersoll Rand service kit for the oil relief valve.
2. What is Ingersoll Rand 22744916?
22744916 is identified as an Ingersoll Rand check valve cartridge and is listed as a 3 bar cartridge configuration.
3. What is the purpose of combining these two part numbers?
For this product listing, the two supplied part numbers are treated as one complete service configuration, combining the oil relief valve service kit with the associated check valve cartridge.
4. Is 22744916 a complete external check valve assembly?
No. It is identified specifically as a check valve cartridge rather than a complete external valve assembly.
5. What does the 3 bar designation refer to?
The 3 bar designation identifies the pressure configuration associated with the 22744916 check valve cartridge.
6. What is the function of an oil relief valve?
An oil relief valve forms part of the compressor oil circuit and provides the applicable pressure-relief function within the system.
7. Is 24784910 a standalone oil relief valve?
No. 24784910 is identified as a service kit for the oil relief valve.
8. Can 22744916 be used on every Ingersoll Rand compressor?
No. Compatibility depends on the compressor model, serial number, oil-system design, pressure configuration, and applicable parts documentation.
9. Should the check valve cartridge be replaced during every service interval?
Not necessarily. Replacement should follow the applicable service procedure and the condition of the installed cartridge.
10. What should be verified before ordering this configuration?
The compressor model, serial number, existing oil-system components, required check-valve pressure configuration, and current Ingersoll Rand parts documentation should be verified before ordering.
