Brand:Ingersoll Rand Item No.:47688515001 24073306 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47688515001 / 24073306 Intercooler Gasket Repair Module is intended for service work involving compatible water-cooled YS intercooler systems. Part 47688515001 is identified as a water-cooled intercooler kit, while 24073306 is a 12-inch inlet bonnet gasket. Together, they provide a practical configuration for intercooler maintenance where both service components and inlet-side sealing requirements need to be addressed.
The configuration is intended for industrial compressed-air equipment and should be matched against the compressor's actual model, cooling arrangement, and maintenance documentation before installation.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Product Type
Intercooler Gasket Repair Module
Primary Part Number
47688515001
Associated Part Number
24073306
47688515001 Description
Kit, Intercooler, Water-Cooled (YS)
24073306 Description
Gasket, 12-inch Inlet Bonnet
Cooling Type
Water-cooled
Equipment Family
Applicable Ingersoll Rand YS configurations
Gasket Nominal Size
12 inch inlet bonnet
Dimensions
Not reliably published as a fixed value for the complete configuration
Weight
Not reliably published as a fixed value for the complete configuration
Recommended Companion Models
Model
Product Name
Ingersoll Rand Centac YS
Water-Cooled Intercooler Compressor
Ingersoll Rand YS Series
Centrifugal Compressor
Ingersoll Rand YS 100
Water-Cooled Centrifugal Compressor
Ingersoll Rand YS 150
Water-Cooled Centrifugal Compressor
Frequently Selected Alternatives
Model
Product Name
47688513001
Water-Cooled Aftercooler Kit
47688515001
Water-Cooled Intercooler Kit
47715345001
Water-Cooled Intercooler Service Kit
47685788001
Intercooler O-Ring
Where It Fits in Industrial Applications
• Used for maintenance of water-cooled intercooler assemblies on applicable Ingersoll Rand YS compressor configurations.
• Supports service work where the intercooler assembly and associated inlet bonnet sealing interface require attention.
• Suitable for planned maintenance, repair activities, and component replacement within industrial compressed-air systems.
• Helps maintain proper sealing at the inlet bonnet interface during compressor service.
Key Strengths at a Glance
• Water-cooled intercooler service configuration designed for applicable YS equipment.
• Combines an intercooler maintenance kit with a dedicated 12-inch inlet bonnet gasket.
• Supports controlled maintenance of the intercooler and associated sealing surfaces.
• Suitable for professional compressor service environments where correct replacement-part matching is important.
Technical FAQs
1. What is Ingersoll Rand 47688515001?
Ingersoll Rand 47688515001 is identified as a water-cooled intercooler kit for YS compressor configurations.
2. What is the function of 24073306?
Part 24073306 is a 12-inch inlet bonnet gasket used to provide sealing at the applicable inlet bonnet interface.
3. How do the two part numbers relate to this product configuration?
For this product listing, 47688515001 and 24073306 are treated as one service configuration combining intercooler maintenance with the associated inlet bonnet sealing component.
4. What type of cooling system does 47688515001 support?
The 47688515001 kit is specifically identified as a water-cooled intercooler kit for YS configurations.
5. Where is the gasket installed?
The 24073306 gasket is associated with the 12-inch inlet bonnet and is used at the corresponding sealing interface.
6. What maintenance work can this configuration support?
It can support intercooler-related inspection, replacement, resealing, and planned service work on compatible compressor assemblies.
7. Is 24073306 a filter or cooling element?
No. It is a gasket used for sealing the applicable inlet bonnet connection.
8. Can this configuration be used on every Ingersoll Rand compressor?
No. Application depends on the compressor configuration and service documentation, so the equipment model and existing part number should be checked before installation.
9. Is this configuration suitable for water-cooled compressor service?
Yes. The 47688515001 portion is specifically identified as a water-cooled intercooler kit for applicable YS configurations.
10. What should be checked before ordering?
The compressor model, cooling arrangement, intercooler configuration, and existing part numbers should be verified to ensure that both components match the intended service application.
