Brand:Ingersoll Rand Item No.:47689371001 96748322 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47689371001 / 96748322 Gear Exchange Pin Module is intended for maintenance of compatible CD26M gear-drive assemblies. Part 47689371001 is identified as a bearing exchange gear kit, while 96748322 is an OEM cylinder pin specified to ISO 8733 with a 10 × 20 mm nominal size.
The cylinder pin provides a precision mechanical locating or retaining function within a compatible assembly. Together, the supplied part numbers provide a service-oriented configuration for gear maintenance and associated mechanical component replacement.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Product Type
Gear Exchange Pin Module
Primary Part Number
47689371001
Associated Part Number
96748322
47689371001 Description
Kit, Bearing Exchange Gear, CD26M
96748322 Description
Cylinder Pin, ISO 8733
Pin Standard
ISO 8733
Pin Diameter
10 mm
Pin Length
20 mm
Pin Type
Cylindrical / parallel pin
Applicable Equipment
CD26M configurations
Service Function
Gear exchange and mechanical positioning
Complete Configuration Dimensions
Not reliably published as a fixed value
Complete Configuration Weight
Not reliably published as a fixed value
Recommended Companion Models
Model
Product Name
Ingersoll Rand CD26M
Centrifugal Compressor
Ingersoll Rand CD26
Centrifugal Compressor
Ingersoll Rand CD Series
Centrifugal Compressor
Ingersoll Rand Centac
Industrial Centrifugal Compressor
Frequently Selected Alternatives
Model
Product Name
22502348001
6312/C3 Deep-Groove Ball Bearing
54479308
Cylindrical Roller Bearing
22848196
No-Lead Wear Sleeve
22862700
CD26M Single-Lip Seal
Where It Fits in Industrial Applications
• Used for gear-drive maintenance on compatible Ingersoll Rand CD26M compressor configurations.
• Supports service work involving the bearing exchange gear assembly and its associated locating or retaining pin.
• Suitable for planned compressor overhaul and maintenance of gear-drive components.
• Intended for industrial compressed-air equipment where accurate mechanical alignment and OEM part matching are important.
Key Strengths at a Glance
• 47689371001 is identified as a bearing exchange gear kit for CD26M.
• 96748322 is an OEM cylinder pin manufactured to ISO 8733 specifications.
• The 96748322 pin has a nominal 10 × 20 mm size.
• Combines a dedicated gear exchange kit with a precision mechanical pin for related service work.
Technical FAQs
1. What is Ingersoll Rand 47689371001?
Ingersoll Rand 47689371001 is identified as a bearing exchange gear kit for CD26M compressor configurations.
2. What is Ingersoll Rand 96748322?
Ingersoll Rand 96748322 is an OEM cylinder pin specified to ISO 8733 with a nominal 10 × 20 mm size.
3. Why are these two part numbers listed together?
For this product listing, the two supplied part numbers are treated as one service configuration combining the CD26M bearing exchange gear kit with its associated cylinder pin.
4. What standard applies to 96748322?
Part 96748322 is identified as a cylinder pin manufactured according to ISO 8733.
5. What are the nominal dimensions of 96748322?
The pin is specified as 10 mm in diameter and 20 mm in length.
6. What is the function of a cylinder pin in a gear assembly?
A cylinder pin can provide accurate positioning, alignment, or mechanical retention between compatible components within an assembly.
7. Is 96748322 suitable for every Ingersoll Rand compressor?
No. Pin compatibility depends on the assembly design, bore dimensions, fit requirements, and applicable equipment documentation.
8. What maintenance activities can this configuration support?
It can support gear assembly inspection, bearing exchange, component alignment, pin replacement, and related compressor overhaul work.
9. When should the cylinder pin be replaced?
The pin should be inspected during applicable gear-drive service and replaced if it shows deformation, wear, corrosion, damage, or does not meet the specified fit requirements.
10. What should be verified before installation?
The compressor model, gear assembly, pin location, pin dimensions, fit specification, and existing part numbers should be verified before installation.
