Ingersoll Rand 47689371003 / 96749833 Airend Dowel Pin Module

Where It Fits in Industrial Applications

• Used for applicable Ingersoll Rand CDM134 OJ airend replacement and service applications.

• Supports major airend exchange work where the 47689371003 replacement kit is specified.

• Provides the associated 96749833 precision dowel pin for compatible compressor assemblies.

• Suitable for planned airend maintenance, replacement, alignment, and mechanical assembly work.

Key Strengths at a Glance

• 47689371003 is identified as an Ingersoll Rand airend replacement kit for the CDM134 OJ configuration.

• 96749833 is identified as a genuine Ingersoll Rand precision dowel pin.

• The 96749833 pin is also listed as a parallel pin, with a 10 × 28 mm specification in applicable parts references.

• Combines the primary airend replacement configuration with an associated locating component for coordinated service.

Technical FAQs

1. What is Ingersoll Rand 47689371003?

47689371003 is an Ingersoll Rand airend replacement kit identified for the CDM134 OJ configuration.

2. What is part 96749833?

96749833 is a genuine Ingersoll Rand precision dowel pin, also identified as a 10 × 28 mm parallel pin in applicable parts references.

3. Why are 47689371003 and 96749833 listed together?

For this product listing, the two supplied part numbers are treated as one coordinated service configuration combining the CDM134 OJ airend replacement kit with the specified dowel pin.

4. What is the function of a precision dowel pin?

A precision dowel pin provides accurate locating and alignment between compatible mechanical components while maintaining their relative position during assembly and operation.

5. What is the listed size of 96749833?

Applicable parts references identify 96749833 as a 10 × 28 mm parallel pin.

6. What equipment is associated with 47689371003?

47689371003 is identified as the CDM134 OJ airend replacement kit.

7. Should the 96749833 pin be replaced during airend service?

Replacement should follow the applicable service instructions. A dowel pin should be replaced if it is worn, damaged, deformed, corroded, or no longer provides the required locating fit.

8. Can another parallel pin substitute for 96749833?

Substitution should only be made when the replacement matches the required diameter, length, tolerance, material, and equipment specification.

9. Does 47689371003 include the 96749833 dowel pin?

The exact contents of the 47689371003 airend replacement kit should be confirmed against the applicable Ingersoll Rand parts list. In this listing, 96749833 is treated as the associated component supplied with the primary part number.

10. What should be verified before ordering this configuration?

Confirm the compressor model, serial number, CDM134 OJ configuration, both part numbers, dowel-pin specification, and applicable service documentation before ordering or installation.
