Brand:Ingersoll Rand Item No.: 47689371003 / 96751516 Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47689371003 / 96751516 Airend Lock Nut Module is intended for coordinated maintenance of compatible compressor equipment. Part 47689371003 is identified as the CDM134 OJ airend replacement kit, while 96751516 is an Ingersoll Rand DIN 981 KM10 lock nut.
The configuration is suited to planned airend service where the specified locking component is required alongside the replacement airend. Correct compatibility and installation requirements should be confirmed against the equipment-specific parts documentation.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Primary Part Number
47689371003
Associated Part Number
96751516
Primary Component
Airend replacement kit
Airend Configuration
CDM134 OJ
Associated Component
Lock nut
Lock Nut Standard
DIN 981
Lock Nut Size
KM10
Application
Compatible Ingersoll Rand compressor assemblies
Dimensions
Not reliably published as a fixed value for the complete configuration
Weight
Not reliably published as a fixed value for the complete configuration
Recommended Companion Models
Model
Product Name
CDM134 OJ
CDM134 OJ Airend Configuration
CDM134
CDM134 Compressor
CDM Series
CDM Series Compressor
Centac
Centac Centrifugal Compressor
Frequently Selected Alternatives
Part Number
Product Name
47689371004
CDM134 WJ Airend Replacement Module
47689371005
CDM80 OJ Airend Replacement Module
47689371006
CDM80 WJ Airend Replacement Module
96751524
DIN 981 KM11 Lock Nut Module
Where It Fits in Industrial Applications
• Used for applicable Ingersoll Rand CDM134 OJ airend replacement and service applications.
• Supports major airend exchange work where the 47689371003 replacement kit is specified.
• Provides the associated 96751516 lock nut for compatible rotating and mechanical assemblies.
• Suitable for planned airend maintenance, replacement, and related shaft or bearing assembly service.
Key Strengths at a Glance
• 47689371003 is identified as an airend replacement kit for the CDM134 OJ configuration.
• 96751516 is identified as an Ingersoll Rand lock nut conforming to DIN 981, KM10.
• Provides a dedicated locking component for the applicable mechanical assembly.
• Combines the primary airend replacement configuration with an associated OEM mechanical component.
Technical FAQs
1. What is Ingersoll Rand 47689371003?
47689371003 is an Ingersoll Rand airend replacement kit identified for the CDM134 OJ configuration.
2. What is part 96751516?
96751516 is an Ingersoll Rand lock nut identified as DIN 981, KM10.
3. Why are 47689371003 and 96751516 listed together?
For this product listing, the two supplied part numbers are treated as one coordinated service configuration combining the CDM134 OJ airend replacement kit with the specified lock nut.
4. What is the function of a lock nut in a compressor assembly?
A lock nut secures a compatible threaded component and helps maintain the required mechanical position during compressor operation.
5. What standard is associated with 96751516?
96751516 is identified as a DIN 981 KM10 lock nut.
6. What equipment is associated with 47689371003?
47689371003 is identified as the replacement airend kit for the CDM134 OJ configuration.
7. When should 96751516 be replaced?
Replacement should follow the applicable service instructions. A lock nut should be replaced when it is damaged, deformed, worn, corroded, or no longer provides the required locking function.
8. Can another KM10 lock nut be substituted for 96751516?
Substitution should only be made when the replacement matches the required thread, dimensions, locking characteristics, material, and applicable Ingersoll Rand specification.
9. Does 47689371003 include the 96751516 lock nut?
The exact contents of the 47689371003 airend replacement kit should be confirmed against the applicable Ingersoll Rand parts list. In this listing, 96751516 is treated as the associated component supplied with the primary part number.
10. What should be verified before ordering this configuration?
Confirm the compressor model, serial number, CDM134 OJ configuration, both part numbers, lock-nut specification, and applicable service documentation before ordering or installation.
