Siemens 6AG2512-1DK01-4AB0 SIPLUS ET 200SP CPU 1512SP-1 PN RAIL Central Processing Unit

Where It Excels in Industrial Use

• Railway automation systems operating under extended temperature requirements.
• Distributed control installations exposed to environmental contaminants and demanding operating conditions.
• Industrial machinery requiring fast PLC execution and synchronized PROFINET communication.
• Compact control cabinets where distributed I/O and centralized program management are needed.
• Rail vehicle and infrastructure applications designed around the SIMATIC ET 200SP platform.

Key Strengths at a Glance

• Extended temperature capability: Supports operation from -40°C to +70°C, with short-duration operation up to +85°C for 10 minutes under specified conditions.
• Fast processing: Delivers 48 ns bit performance for responsive control applications.
• Integrated network switching: Features PROFINET IRT with a built-in three-port switch.
• Practical work memory: Provides 200 KB for programs and 1 MB for data.
• Conformal coating: Helps protect electronic assemblies in challenging environments.
• Railway-oriented construction: Designed for applications requiring enhanced environmental resilience.
• Compact ET 200SP integration: Fits distributed automation architectures with compatible system components.

Technical FAQs

1. Which communication protocol does this CPU support?

The CPU supports PROFINET IO with Isochronous Real-Time (IRT) capability, enabling cyclic communication and synchronized control in compatible automation systems.

2. How many ports are provided by the integrated PROFINET switch?

The CPU includes a three-port PROFINET switch. This TX RAIL version does not accept a pluggable BusAdapter, so the interface arrangement must be planned according to the specified hardware configuration.

3. What work memory is available for control programs and data?

The CPU provides 200 KB of program work memory and 1 MB of data work memory for application logic, process variables, and operating data.

4. What is the CPU's bit-processing performance?

Its specified bit-processing performance is 48 ns, supporting responsive execution of logic operations in machine and process automation applications.

5. Is a SIMATIC Memory Card required?

Yes. A compatible SIMATIC Memory Card is required. Select the card and configure its use according to the project's program storage and commissioning requirements.

6. Which software is used to configure the CPU?

The CPU is configured using Siemens STEP 7 in TIA Portal. The supported functions and available configuration options depend on the software version and the project's hardware configuration.

7. What is the permitted operating temperature range?

The specified operating range is -40°C to +70°C. Temperatures up to +85°C are permitted for 10 minutes under the manufacturer's stated conditions; this short-duration allowance should not be treated as a continuous operating temperature.

8. How does the TX RAIL version differ from the -1AB0 version?

Both variants provide 200 KB of program memory, 1 MB of data memory, and 48 ns bit performance. The -4AB0 TX RAIL version supports a wider temperature range of -40°C to +70°C, with a short-duration limit of +85°C for 10 minutes, while the -1AB0 version has a different specified environmental temperature profile.

9. Does the CPU support synchronized automation tasks?

Yes. PROFINET IRT and isochronous operation support synchronized communication and control when the connected devices, network configuration, and engineering project are designed for these functions.

10. Is 6AG2512-1DK01-4AB0 still the current ordering model?

This article number has been cancelled, and Siemens identifies 6AG2512-1DM03-4AB0 as its substitute. The replacement provides 400 KB of program memory, 2 MB of data memory, and 25 ns bit performance. Confirm application, firmware, environmental, and installation compatibility before substituting it into an existing system.
