Siemens 6AG2677-2DB40-2AA0 SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC

Where It Excels in Industrial Use

• Railway automation systems requiring compact industrial computing hardware.
• Distributed control architectures combining ET 200SP I/O with PC-based applications.
• Industrial visualization, data processing, and communication tasks at the machine level.
• Applications requiring multiple Ethernet connections and flexible peripheral connectivity.
• Control cabinets exposed to extended temperature ranges and challenging environmental conditions.
• Edge-level data collection and exchange between industrial networks and higher-level systems.
• Replacement and maintenance requirements for compatible SIPLUS ET 200SP CPU 1515SP PC2 installations.

Key Strengths at a Glance

• SIPLUS ET 200SP CPU 1515SP PC2 RAIL industrial PC.
• Based on the SIMATIC ET 200SP CPU 1515SP PC2, article number 6ES7677-2DB40-0AA0.
• Intel Atom E3940 quad-core processor operating at 1.6 GHz.
• 8 GB RAM for industrial computing workloads.
• Designed as a spare part; supplied without a CFast card.
• CFast and SD/MMC card slots for supported storage configurations.
• PROFINET connection through an ET 200SP BusAdapter.
• Additional Gigabit Ethernet interface for industrial communication.
• Two USB 3.0 ports and two USB 2.0 ports.
• DisplayPort interface for connecting a compatible display.
• 24 V DC supply with a permissible range of 19.2–28.8 V DC.
• Conformal coating for railway and demanding industrial environments.
• Operating temperature from -40 °C to +60 °C, with +70 °C permitted for 10 minutes under the specified temperature profile.

Technical FAQs

1. What is the Siemens 6AG2677-2DB40-2AA0 used for?

This product is a SIPLUS ET 200SP CPU 1515SP PC2 RAIL industrial PC spare part. It provides a compact computing platform for compatible industrial applications requiring PC-based processing and integration with the ET 200SP system.

2. Which processor is installed in the CPU 1515SP PC2?

The unit uses an Intel Atom E3940 quad-core processor running at 1.6 GHz. This processor supports industrial computing tasks such as communication, data handling, and compatible application execution.

3. How much RAM is provided?

The device is equipped with 8 GB of RAM. Available application performance depends on the installed software, operating environment, and workload.

4. Does this article number include a CFast card?

No. The 6AG2677-2DB40-2AA0 is specified as a spare part supplied without a CFast card. Storage media and any required software should be checked against the intended system configuration.

5. Which storage interfaces are available?

The device provides one CFast card slot and one SD/MMC card slot. The supported media types and their intended use should be confirmed against the applicable Siemens documentation.

6. What network interfaces does the unit provide?

The industrial PC has a PROFINET connection through an ET 200SP BusAdapter and an additional 10/100/1000 Mbit/s Industrial Ethernet interface. The BusAdapter determines the available physical PROFINET connector arrangement.

7. Which USB and display interfaces are available?

The unit provides two USB 3.0 ports, two USB 2.0 ports, and one DisplayPort interface. These connections support compatible peripherals, maintenance equipment, and display devices.

8. Does the device include a preinstalled software controller or visualization package?

The specified 6AG2677-2DB40-2AA0 is identified as a spare CPU 1515SP PC2 and is listed without installed visualization or control software. Software licensing, installation media, and compatibility should be verified for the intended application.

9. What supply voltage does the industrial PC require?

The device uses a nominal 24 V DC supply, with a permissible range of 19.2–28.8 V DC. The power supply should be selected to accommodate the actual load, connected ET 200SP modules, and attached USB devices.

10. What environmental protection does the SIPLUS RAIL version provide?

The product features conformal-coated electronics and is designed for railway applications. Its specified operating range is -40 °C to +60 °C, with +70 °C permitted for 10 minutes under the applicable temperature profile.
