Siemens 6AG2677-2DB42-2GB0 SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC
Siemens 6AG2677-2DB42-2GB0 SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC
0.0
Points
Brand:Siemens Item No.:6AG2677-2DB42-2GB0 Product Origin: Germany Product Dimensions:142 × 189 × 92 mm Product Weight:830 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2677-2DB42-2GB0 SIPLUS ET 200SP CPU 1515SP PC2 RAIL is a compact industrial computing platform that combines PC-based processing with integrated PLC control. Based on the 6ES7677-2DB42-0GB0 platform, it comes with an Intel Atom E3940 quad-core processor, 8 GB RAM, 128 GB CFast storage, Windows 10 IoT Enterprise 64-bit, and the S7-1500 Software Controller CPU 1505SP preinstalled.
This combination allows supported automation tasks and PC applications to operate on the same hardware platform. It is suitable for applications requiring local data processing, machine-level control, industrial communication, and integration with distributed ET 200SP I/O.
The interface selection includes PROFINET connectivity through an ET 200SP BusAdapter, a separate Gigabit Ethernet interface, four USB ports, and DisplayPort. These connections provide flexibility for network integration, compatible peripheral devices, and local display requirements.
Designed for railway and demanding industrial environments, the SIPLUS RAIL version features conformal coating and an extended operating temperature range. For system integrators and maintenance teams, it provides a preconfigured computing and control platform for applications where compact design, software integration, and environmental robustness are important.
Technical Specifications
Specification
Details
Product
SIPLUS ET 200SP CPU 1515SP PC2 RAIL
Article Number
6AG2677-2DB42-2GB0
Base Module
6ES7677-2DB42-0GB0
Product Type
Industrial PC / Open Controller
Processor
Intel Atom E3940
Processor Frequency
1.6 GHz
Processor Cores
4
RAM
8 GB
Storage
128 GB CFast
Operating System
Windows 10 IoT Enterprise 64-bit
Preinstalled PLC Software
S7-1500 Software Controller CPU 1505SP
PROFINET Interface
1 connection through ET 200SP BusAdapter
Additional Ethernet
1 × 10/100/1000 Mbit/s
USB Interfaces
2 × USB 3.0; 2 × USB 2.0
Display Interface
1 × DisplayPort
SD/MMC Slot
1
Rated Supply Voltage
24 V DC
Permissible Supply Range
19.2–28.8 V DC
Maximum Active Power Input
Approx. 43 W, depending on configuration
Typical Power Loss
Approx. 16 W
Backplane Bus Power
Approx. 8.75 W
Conformal Coating
Yes
Railway Application
Yes
Operating Temperature
-40 °C to +60 °C
Short-Term Temperature
+70 °C for 10 minutes
Protection Class
IP20
Dimensions
Approx. 142 × 189 × 92 mm
Weight
Approx. 830 g
Recommended Companion Models
Model
Product Name
6AG2677-2DB40-2AA0
SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC
6AG2677-2DB40-2GB0
SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC
6AG2512-1DK01-1AB0
SIPLUS ET 200SP CPU 1512SP-1 PN RAIL
6AG2193-6AF00-4AA0
SIPLUS ET 200SP BusAdapter Module
Frequently Selected Alternatives
Model
Product Name
6AG2677-2DB42-2GB1
SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC, successor version
6ES7677-2DB42-0GB0
SIMATIC ET 200SP CPU 1515SP PC2 Open Controller
6AG2677-2DB40-2AA0
SIPLUS ET 200SP CPU 1515SP PC2 RAIL Industrial PC
6AG2510-1DJ01-1AB0
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
Where It Excels in Industrial Use
Railway automation installations requiring an industrial PC with integrated PLC control functionality.
Distributed control systems combining PC-based processing with ET 200SP I/O.
Machine-level visualization, data acquisition, and industrial communication applications.
Transportation and infrastructure systems operating under demanding temperature conditions.
Industrial edge applications that process equipment data locally before passing it to higher-level systems.
Control architectures requiring both PROFINET connectivity and standard Gigabit Ethernet.
Existing ET 200SP CPU 1515SP PC2 installations requiring a replacement with preinstalled software.
Key Strengths at a Glance
SIPLUS ET 200SP CPU 1515SP PC2 RAIL with preinstalled S7-1500 Software Controller CPU 1505SP.
Intel Atom E3940 quad-core processor operating at 1.6 GHz.
8 GB RAM and 128 GB CFast storage.
Windows 10 IoT Enterprise 64-bit preinstalled.
PROFINET connectivity through an ET 200SP BusAdapter.
Additional 10/100/1000 Mbit/s Ethernet interface.
Two USB 3.0 ports and two USB 2.0 ports.
DisplayPort interface for compatible displays.
Integrated PLC control and PC computing capabilities in a compact industrial platform.
Conformal coating for enhanced environmental resistance.
24 V DC power supply with a permissible range of 19.2–28.8 V DC.
Railway-oriented operating temperature range of -40 °C to +60 °C, with +70 °C permitted for 10 minutes under the specified temperature profile.
Technical FAQs
1. What is the primary function of the Siemens 6AG2677-2DB42-2GB0?
This product is a SIPLUS ET 200SP CPU 1515SP PC2 RAIL industrial PC with the S7-1500 Software Controller CPU 1505SP preinstalled. It combines PC-based computing with PLC control functionality for compatible industrial automation applications.
2. Which processor does the unit use?
The industrial PC uses an Intel Atom E3940 quad-core processor operating at 1.6 GHz. This processor supports the combined computing, communication, and automation workloads for which the platform is designed.
3. How much memory and storage are included?
The unit includes 8 GB of RAM and a 128 GB CFast storage card. The storage configuration provides space for the operating system, installed applications, and supported automation software.
4. Which operating system is preinstalled?
Windows 10 IoT Enterprise 64-bit is preinstalled. The system also includes the S7-1500 Software Controller CPU 1505SP, allowing supported PLC control tasks to run alongside compatible PC applications.
5. How does the industrial PC connect to PROFINET?
PROFINET connectivity is provided through an ET 200SP BusAdapter connection. The selected BusAdapter determines the physical connector arrangement, such as supported copper or fiber-optic Ethernet connections.
6. Does the device have a separate Gigabit Ethernet interface?
Yes. In addition to the PROFINET connection through the BusAdapter, the unit provides a separate 10/100/1000 Mbit/s Ethernet interface for compatible network and application requirements.
7. Which peripheral interfaces are available?
The device provides two USB 3.0 ports, two USB 2.0 ports, and one DisplayPort interface. These can be used with compatible peripherals, service equipment, and display devices.
8. Can the software controller communicate with ET 200SP I/O modules?
Yes. The software controller can be integrated with supported ET 200SP I/O configurations through the applicable PROFINET architecture. Hardware configuration, device support, and software compatibility should be checked in the Siemens engineering environment before commissioning.
9. What power supply does the unit require?
The industrial PC operates from a nominal 24 V DC supply, with a permissible range of 19.2–28.8 V DC. The power supply should be sized for the PC, connected I/O modules, peripherals, and peak operating demand.
10. What environmental conditions are supported?
The SIPLUS RAIL version uses conformal-coated electronics and is specified for operation from -40 °C to +60 °C, with +70 °C permitted for 10 minutes under the specified temperature profile. Installation conditions and mounting orientation should be checked against the applicable Siemens technical documentation.
