Siemens 6AG4010-5AA12-0XX5 SIMATIC IPC3000 SMART V2 Industrial PC

Where It Excels in Industrial Use

• Industrial automation systems requiring a rack-mounted computer for machine-level processing.
• Production monitoring, manufacturing data collection, and industrial application hosting.
• Legacy equipment integration using Ethernet and serial communication interfaces.
• Industrial control cabinets requiring PCI and PCI Express expansion options.
• Factory computing applications that need local hard-disk storage and optical media access.
• Maintenance and modernization projects involving Siemens SIMATIC IPC3000 SMART V2 systems.

Key Strengths at a Glance

• Industrial rack format: 19-inch, 4U chassis designed for industrial cabinet installations.
• Processor: Intel Pentium G3260 dual-core CPU operating at 3.3 GHz.
• Memory: 2 GB DDR3-1600 SDRAM in the specified configuration.
• Storage: 500 GB, 3.5-inch SATA hard disk running at 7,200 rpm.
• Optical drive: DVD±R/RW drive for compatible optical media.
• Network connectivity: Two Gigabit Ethernet ports.
• Serial communication: COM interfaces supporting RS-232, RS-422, and RS-485 according to interface configuration.
• Display support: VGA and DVI-D outputs with integrated Intel graphics.
• Expansion: Four PCI slots and PCI Express expansion options.
• Power input: 220 V AC, 50/60 Hz, with a 350 W power supply.
• Operating system: No operating system preinstalled.

Technical FAQs

1. What is the Siemens 6AG4010-5AA12-0XX5?

The Siemens 6AG4010-5AA12-0XX5 is a SIMATIC IPC3000 SMART V2 industrial PC configured for industrial computing, production support, equipment monitoring, and automation-related applications.

2. Which processor is installed in this model?

This configuration uses an Intel Pentium G3260 dual-core processor with a 3.3 GHz operating frequency and 3 MB cache, providing computing capacity for conventional industrial software and machine-level data processing.

3. How much memory and storage does the computer provide?

The standard configuration includes 2 GB of DDR3-1600 memory and a 500 GB, 3.5-inch SATA hard disk operating at 7,200 rpm. Actual hardware should be checked against the delivered unit if the computer has been upgraded or refurbished.

4. Does this model include an optical drive?

Yes. The 6AG4010-5AA12-0XX5 configuration includes a DVD±R/RW drive, allowing compatible optical media to be read and written.

5. Is an operating system preinstalled?

No. This configuration is supplied without a preinstalled operating system. Before commissioning, select a compatible operating system and confirm that required drivers, licenses, and industrial applications are supported.

6. Which Ethernet interfaces are available?

The computer provides two RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication. These can be used for connections to industrial networks, supervisory computers, and compatible Ethernet-enabled equipment.

7. Can the IPC communicate with serial industrial devices?

Yes. The platform provides serial communication interfaces. COM1 supports RS-232, while COM2 can be configured for RS-232, RS-422, or RS-485 through the supported hardware and BIOS settings.

8. Which monitor connections does it support?

The IPC includes VGA and DVI-D display outputs using integrated Intel graphics. The supported resolution depends on the display interface, monitor, and configuration; the platform documentation specifies support up to 1920 × 1200 pixels at 60 Hz.

9. Can the system be expanded with additional cards?

Yes. The chassis supports four PCI slots, one PCI Express x1 slot, one PCI Express x8 slot with two lanes, and one PCI Express x16 slot. Check card compatibility, dimensions, and driver support before installation.

10. What should be checked before replacing an existing industrial PC?

Confirm the processor workload, available memory, storage capacity, operating-system compatibility, serial communication requirements, Ethernet configuration, expansion cards, power input, and mounting clearance. These checks help ensure that the replacement meets the requirements of the existing automation system.
