Introduction
The Siemens 6AG4010-5AB10-0FX5 belongs to the SIMATIC IPC3000 SMART V2 range of industrial PCs developed for reliable computing within automation and manufacturing environments. Its 19-inch, 4U rack format makes it suitable for standard industrial cabinets and equipment racks where a conventional rack-mounted computer is preferred.
The 5AB10 configuration is based on an Intel Pentium G3260 dual-core processor, 2 GB DDR3 memory, and a 1000 GB internal SATA hard disk. Its combination of two Gigabit Ethernet ports, two configurable serial interfaces, VGA and DVI-D outputs, USB connectivity, and conventional peripheral interfaces provides a practical foundation for industrial software, visualization, data handling, and machine-level communication.
The 6AG4010-5AB10-0FX5 should be selected according to the exact factory configuration required by the application. In particular, the operating-system and market-specific characteristics associated with the suffix should be confirmed before procurement and deployment.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Article Number | 6AG4010-5AB10-0FX5 |
| Product Family | SIMATIC IPC3000 SMART V2 |
| Product Type | Industrial PC |
| Mounting Format | 19-inch rack |
| Height | 4U |
| Processor | Intel Pentium G3260, dual-core, 3.3 GHz, 3 MB cache |
| Memory | 2 GB DDR3 SDRAM, 1 × 2 GB |
| Storage | 1000 GB internal SATA hard disk |
| Optical Drive | Not fitted in the documented 5AB10 configuration |
| Ethernet | 2 × Gigabit Ethernet |
| Serial Interfaces | 2 × serial interfaces, RS-232/RS-422/RS-485 capability |
| USB | 6 × USB, 2 front and 4 rear |
| Video | 1 × VGA, 1 × DVI-D |
| Keyboard/Mouse | 2 × PS/2 |
| Audio | Audio interface |
| Expansion | Industrial PC expansion architecture; exact installed expansion configuration should be verified for the individual unit |
| Operating System | Factory configuration dependent; verify the 0FX5 configuration before ordering |
| Power Supply | Configuration dependent; verify against the individual unit documentation |
| Dimensions | Approx. 481 × 177 × 509 mm |
| Weight | Configuration dependent; verify the supplied unit |
| Installation | 19-inch rack or industrial cabinet |
Recommended Companion Models
| Model | Product Name |
|---|
| 6AG4010-5AA10-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB10-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AA12-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AA20-0FX5 | SIMATIC IPC3000 SMART Industrial PC |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 6AG4010-5AA22-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AA22-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AA32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Technical FAQs
1. What type of industrial computer is the Siemens 6AG4010-5AB10-0FX5?
The 6AG4010-5AB10-0FX5 is part of the SIMATIC IPC3000 SMART V2 family and uses a 19-inch, 4U rack-mounted industrial PC design for automation, manufacturing, visualization, data-processing, and machine-level computing applications.
2. What processor is used in this IPC configuration?
The 6AG4010-5AB10 configuration is associated with the Intel Pentium G3260 dual-core processor, operating at 3.3 GHz with 3 MB cache. The processor provides a practical computing platform for conventional industrial automation and control applications.
3. How much memory does the 6AG4010-5AB10 configuration provide?
The documented 5AB10 configuration uses 2 GB DDR3 SDRAM installed as a single 2 GB module. This configuration is intended for industrial applications with relatively moderate operating-system and application memory requirements.
4. What storage is provided?
The 5AB10 configuration is specified with an internal 1000 GB SATA hard disk. This provides substantial local capacity for operating-system files, industrial applications, production data, logs, and other locally stored information.
5. Does the unit include an optical disk drive?
The documented 5AB10 configuration is supplied without an optical disk drive. This keeps the rack-mounted system focused on its industrial computing and network-based data functions.
6. What network interfaces are available?
The configuration provides two Gigabit Ethernet interfaces. These can be used for industrial Ethernet communication, plant networks, engineering access, data exchange, and connection to other automation or information systems.
7. What serial communication interfaces are available?
Two serial interfaces are provided, with RS-232/RS-422/RS-485 communication capability. This makes the IPC suitable for connecting conventional serial automation equipment and legacy devices alongside Ethernet-based systems.
8. Which display interfaces are provided?
The IPC configuration provides one VGA interface and one DVI-D interface. These outputs support connection to industrial monitors and other compatible display equipment used for visualization, diagnostics, and operator access.
9. What USB and peripheral interfaces are available?
The documented configuration provides two front USB ports and four rear USB ports, together with two PS/2 interfaces and audio connectivity. This arrangement supports common engineering, maintenance, keyboard, mouse, and peripheral requirements.
10. What should be checked before ordering the 6AG4010-5AB10-0FX5?
The complete article number should be checked against the equipment label and purchasing documentation, particularly because the 0FX5 suffix identifies a specific factory configuration. Storage, operating-system, market authorization, and other configuration details should be confirmed against the unit being supplied before installation.
