Introduction
The Siemens 6AG4010-5AB12-0XX5 is part of the SIMATIC IPC3000 SMART V2 family of industrial PCs designed for computing tasks in automation and manufacturing environments. Its 19-inch, 4U rack-mounted construction provides a practical solution for installations requiring a conventional industrial computer inside a control cabinet or equipment rack.
The platform combines two Gigabit Ethernet interfaces with serial communication, VGA and DVI-D display outputs, USB connectivity, and PCI/PCIe expansion capability. This interface combination makes the IPC suitable for industrial visualization, machine-level computing, engineering applications, data processing, and automation software.
Because the exact factory configuration associated with this article number is not sufficiently documented in the available product records, processor, memory, storage, operating-system, power-supply, and detailed peripheral specifications should be verified against the actual unit before procurement. The article number should always be used as the primary reference when matching a replacement or system configuration.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Article Number | 6AG4010-5AB12-0XX5 |
| Product Family | SIMATIC IPC3000 SMART V2 |
| Product Type | Industrial PC |
| Mounting Format | 19-inch rack |
| Height | 4U |
| Processor | Factory configuration dependent; verify individual unit |
| Memory | Factory configuration dependent; verify individual unit |
| Storage | Internal SATA storage; exact capacity to be verified |
| Optical Drive | Factory configuration dependent |
| Ethernet | 2 × Gigabit Ethernet |
| Serial Communication | 2 × serial interfaces; exact configuration to be verified |
| USB | Multiple USB interfaces; exact arrangement to be verified |
| Video | VGA and DVI-D |
| Audio | Factory configuration dependent |
| Expansion | PCI and PCIe expansion architecture |
| Operating System | Factory configuration dependent |
| Power Supply | Factory configuration dependent |
| Dimensions | Approx. 481 × 177 × 509 mm |
| Weight | Configuration dependent; verify supplied unit |
| Installation | 19-inch rack / industrial cabinet |
Recommended Companion Models
| Model | Product Name |
|---|
| 6AG4010-5AB12-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB10-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB10-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AA12-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 6AG4010-5AA12-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AA20-0FX5 | SIMATIC IPC3000 SMART Industrial PC |
| 6AG4010-5AA22-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Technical FAQs
1. What is the Siemens 6AG4010-5AB12-0XX5?
The 6AG4010-5AB12-0XX5 is a SIMATIC IPC3000 SMART V2 industrial PC using a 19-inch, 4U rack-mounted form factor. It is intended for industrial computing applications such as visualization, automation software, data processing, and machine-level information handling.
2. What mounting format does this industrial PC use?
The unit uses a standard 19-inch rack-mounted chassis with a height of approximately 4U. This format allows the IPC to be integrated into compatible industrial cabinets, control racks, and equipment enclosures.
3. What processor is used in the 6AG4010-5AB12-0XX5?
The exact processor configuration associated with article 6AG4010-5AB12-0XX5 should be confirmed against the unit's factory documentation. The article belongs to the IPC3000 SMART V2 platform, but configuration-specific processor details should not be assumed from the family designation alone.
4. What memory configuration does it have?
The exact installed memory should be verified against the individual unit documentation. This is particularly important when the IPC is being matched with a specific operating system, industrial application, or replacement system.
5. What type of storage does the IPC use?
The platform uses internal SATA storage. The exact drive type and capacity for the 6AG4010-5AB12-0XX5 should be confirmed from the supplied equipment documentation before procurement or system replacement.
6. What Ethernet interfaces are available?
The IPC3000 SMART V2 platform provides two Gigabit Ethernet interfaces. These can be used for industrial network connections, plant networks, engineering access, server communication, and other Ethernet-based applications.
7. Does the 6AG4010-5AB12-0XX5 support serial communication?
Yes. The platform provides two serial communication interfaces for connecting conventional industrial and legacy equipment. The precise RS-232, RS-422, and RS-485 assignment should be confirmed for the individual factory configuration.
8. Which display interfaces are available?
The platform provides VGA and DVI-D display outputs. These interfaces support compatible industrial monitors used for visualization, diagnostics, engineering, and operator access.
9. Can PCI and PCIe expansion cards be installed?
The IPC3000 SMART V2 platform provides PCI and PCIe expansion capability. Compatible communication, acquisition, I/O, and other expansion cards can therefore be integrated according to the available slot arrangement of the specific configuration.
10. What should be checked before purchasing this article number?
The complete article number should be matched with the equipment label and original purchasing documentation. Processor, memory, storage, operating-system, power-supply, and other factory-specific characteristics should be confirmed for 6AG4010-5AB12-0XX5 before installation or replacement.
