Siemens 6AG4010-5AB20-0FX5 SIMATIC IPC3000 SMART V2 Industrial PC

Where It Excels in Industrial Use

• Industrial automation and manufacturing applications requiring a rack-mounted IPC.
• Machine-level visualization, monitoring, data processing, and industrial software execution.
• Production systems combining Gigabit Ethernet with serial automation equipment.
• Control cabinets and equipment racks using the standard 19-inch format.
• Industrial modernization projects requiring PCI and PCIe expansion capability.
• Applications requiring local processing and substantial internal SATA storage.

Key Strengths at a Glance

• SIMATIC IPC3000 SMART V2 industrial PC platform.
• 19-inch, 4U rack-mounted construction.
• Intel Pentium G3260 dual-core processor platform.
• 4 GB DDR3 SDRAM configuration.
• 1000 GB internal SATA hard disk.
• Two Gigabit Ethernet interfaces.
• Two serial communication interfaces supporting RS-232/RS-422/RS-485.
• Six USB interfaces, with front and rear connectivity.
• VGA and DVI-D display outputs.
• Two PS/2 interfaces and audio connectivity.
• PCI and PCIe expansion architecture.
• Designed for industrial cabinet and rack integration.

Technical FAQs

1. What is the Siemens 6AG4010-5AB20-0FX5?

The 6AG4010-5AB20-0FX5 is a SIMATIC IPC3000 SMART V2 industrial PC in a 19-inch, 4U rack-mounted format. It is designed for industrial computing applications including visualization, automation software, data processing, and machine-level information handling.

2. What processor does the 6AG4010-5AB20-0FX5 use?

The 5AB20 configuration uses an Intel Pentium G3260 dual-core processor operating at 3.3 GHz with 3 MB cache. It provides a practical processing platform for conventional industrial automation and visualization applications.

3. How much memory is installed?

The documented 5AB20 configuration provides 4 GB DDR3 SDRAM installed as one 4 GB module. The memory architecture supports the requirements of typical industrial operating-system and application environments.

4. What storage is included?

The configuration uses a 1000 GB internal SATA hard disk. This provides local capacity for industrial applications, system files, production information, logs, and other data generated by the automation environment.

5. What network interfaces are available?

Two Gigabit Ethernet interfaces are provided. They can be used for industrial Ethernet networks, plant communication, engineering access, server connections, and data exchange with other networked automation equipment.

6. Which serial communication interfaces are provided?

The IPC has two serial COM interfaces with RS-232/RS-422/RS-485 communication capability. These interfaces allow connection to conventional automation devices and legacy serial equipment.

7. Which display interfaces are available?

The configuration provides VGA and DVI-D display outputs. These interfaces can be connected to compatible industrial monitors for visualization, diagnostics, engineering, and operator access.

8. How many USB ports does the unit provide?

The documented configuration provides six USB ports in total, with two located on the front and four on the rear. This arrangement supports common engineering, maintenance, keyboard, mouse, and peripheral connections.

9. Does the IPC support PCI and PCIe expansion?

Yes. The IPC3000 SMART V2 platform provides PCI and PCIe expansion capability, allowing compatible communication, acquisition, I/O, and other expansion cards to be integrated according to the available slot configuration.

10. What should be verified before ordering this article number?

The complete article number should be matched against the equipment label and purchasing documentation. Processor, memory, storage, operating-system, power-supply, and market-specific details should be confirmed for the 6AG4010-5AB20-0FX5 configuration before installation.
