Siemens 6AG4010-5AB20-0XX5 SIMATIC IPC3000 SMART V2 Industrial PC

Where It Excels in Industrial Use

• Industrial automation systems requiring a conventional 19-inch rack-mounted computer.
• Production-line visualization, data acquisition, monitoring, and industrial software applications.
• Manufacturing environments combining Gigabit Ethernet with serial automation equipment.
• Control cabinets and equipment racks where a 4U industrial PC format is appropriate.
• Applications requiring substantial local storage for industrial software, logs, recipes, and production data.
• Automation modernization projects requiring PCI/PCIe expansion and conventional peripheral interfaces.

Key Strengths at a Glance

• SIMATIC IPC3000 SMART V2 industrial PC in a 19-inch, 4U rack format.
• Intel Pentium G3260 dual-core processor, 3.3 GHz, with 3 MB cache.
• 4 GB DDR3 SDRAM installed as a single 4 GB module.
• 1000 GB internal SATA hard disk.
• Two Gigabit Ethernet interfaces.
• Two serial COM interfaces supporting RS-232/RS-422/RS-485.
• Six USB ports, with four at the rear and two at the front.
• VGA and DVI-D display outputs.
• Two PS/2 interfaces and audio connectivity.
• No optical disk drive.
• No operating system supplied.
• Configuration approved specifically for the China market.

Technical FAQs

1. What is the Siemens 6AG4010-5AB20-0XX5?

The 6AG4010-5AB20-0XX5 is a SIMATIC IPC3000 SMART V2 industrial PC designed in a 19-inch, 4U rack-mounted format for industrial automation, visualization, data processing, and machine-level computing.

2. Which processor is used in this configuration?

The IPC uses an Intel Pentium G3260 dual-core processor with 2 cores and 2 threads, a 3.3 GHz clock frequency, and 3 MB cache.

3. How much RAM does the 6AG4010-5AB20-0XX5 provide?

The configuration includes 4 GB DDR3 SDRAM installed as one 4 GB module. The documented configuration specifies the memory arrangement as single-module DDR3 memory.

4. What storage is installed?

The unit includes a 1000 GB internal SATA hard disk. This provides local capacity for the operating environment, industrial applications, production data, logs, and other files.

5. Does this model include an optical disk drive?

No. The documented 6AG4010-5AB20-0XX5 configuration is supplied without an optical disk drive.

6. What Ethernet interfaces are available?

Two Gigabit Ethernet interfaces are provided. They can be used for industrial networking, plant communication, engineering access, server connections, and data exchange with other Ethernet-based systems.

7. Which serial interfaces are included?

The IPC provides two serial COM interfaces with RS-232/RS-422/RS-485 capability. These interfaces allow the computer to communicate with conventional serial automation equipment and legacy devices.

8. What display and USB interfaces are available?

The unit provides one VGA output and one DVI-D output. It also has six USB ports, consisting of four rear USB ports and two front USB ports, supporting displays, engineering peripherals, storage devices, and other compatible equipment.

9. What are the main expansion and peripheral interfaces?

The IPC3000 SMART V2 platform provides PCI/PCIe expansion capability in addition to its Ethernet, serial, USB, VGA, DVI-D, PS/2, and audio interfaces. This allows the system to be adapted to application-specific communication and expansion requirements.

10. Is an operating system included with the 6AG4010-5AB20-0XX5?

No. The documented configuration is supplied without an operating system. The article is also designated for use in the China market, so both software requirements and regional approval should be considered when planning deployment.
