Brand:Siemens Item No.:6AG1222-1BH32-4XB0 Product Origin:Germany Product Dimensions:45 × 100 × 75 mm Product Weight:0.206 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1222-1BH32-4XB0 Digital Output Module is part of the SIPLUS S7-1200 SM 1222 product family. It is designed to provide reliable digital output control in compatible industrial automation systems, combining 16 transistor outputs with a compact form factor.
Operating with a nominal output voltage of 24 V DC, the module can be used to switch compatible actuators, relays, signal devices, and other control loads within its specified electrical limits. Its conformal coating provides additional protection against certain environmental influences, making it suitable for installations where environmental conditions are an important consideration.
With dimensions of 45 × 100 × 75 mm and a weight of 0.206 kg, the Siemens 6AG1222-1BH32-4XB0 is a practical option for control cabinet integration. Before purchasing or replacing the module, users should confirm the exact product variant and verify its electrical and environmental specifications for the intended application.
Technical Specifications
Parameter
Specification
Brand
Siemens
Model
6AG1222-1BH32-4XB0
Product Family
SIPLUS S7-1200 SM 1222
Product Type
Digital Output Module
Base Product Design
6ES7222-1BH32-0XB0
Number of Digital Outputs
16
Output Type
Transistor
Rated Output Voltage
24 V DC
Rated Output Current
0.5 A per channel
Conformal Coating
Yes
Protection Rating
IP20
Dimensions
45 × 100 × 75 mm
Weight
0.206 kg / 0.45 lb
Recommended Related Models
Siemens 6ES7222-1BH32-0XB0 – Standard SIMATIC S7-1200 SM 1222 digital output module with 16 transistor outputs.
Siemens 6AG1222-1BH32-2XB0 – SIPLUS S7-1200 SM 1222 digital output module variant for applications with different environmental requirements.
Siemens 6ES7222-1BF32-0XB0 – S7-1200 digital output module variant with a different output configuration.
Siemens 6ES7214-1AG40-0XB0 – SIMATIC S7-1200 CPU for compatible automation system configurations.
Popular Related Models
Siemens 6ES7222-1BH32-0XB0
Siemens 6AG1222-1BH32-2XB0
Siemens 6ES7222-1BF32-0XB0
Siemens 6ES7214-1AG40-0XB0
Siemens 6ES7221-1BH32-0XB0
Applications
The Siemens 6AG1222-1BH32-4XB0 is a SIPLUS S7-1200 SM 1222 digital output module designed for industrial automation systems. Featuring 16 digital transistor outputs and 24 V DC operation, it supports the control of compatible actuators and switching devices in a wide range of industrial applications.
Typical applications include:
Industrial Machine Control: Switching compatible DC loads in automated machinery and production equipment.
Manufacturing Automation: Controlling output devices across assembly lines and manufacturing systems.
Process Automation: Operating compatible valves, relays, and signal devices.
Control Panel Integration: Expanding the digital output capacity of compatible SIMATIC S7-1200 systems.
Industrial Environments: Supporting automation installations that benefit from additional protection provided by conformal coating.
Advantages
16 Digital Output Channels: Provides multiple output points for industrial control applications.
24 V DC Operation: Supports common industrial control voltage requirements.
Transistor Output Technology: Enables electronic switching of compatible DC loads.
0.5 A Rated Current per Channel: Supports a range of control devices within specified electrical limits.
Conformal Coating: Helps protect electronic components against certain environmental influences.
Compact Installation: The 45 × 100 × 75 mm dimensions help conserve space inside control cabinets.
SIMATIC S7-1200 Compatibility: Designed for integration into suitable Siemens automation configurations.
