Siemens 6AG4010-6EB50-0XX5 SIMATIC IPC3000 Smart V3 Industrial Rack PC
Siemens 6AG4010-6EB50-0XX5 SIMATIC IPC3000 Smart V3 Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4010-6EB50-0XX5 Product Origin: Germany Product Dimensions:110 × 66.8 × 50 mm Product Weight:14 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction: A Rack PC Designed for Industrial Integration
The Siemens SIMATIC IPC3000 Smart V3 6AG4010-6EB50-0XX5 is a rack-mount industrial computer intended for automation, visualization, and production information systems.
Its Intel Core i7-6700 processor, 32 GB DDR4 memory, and 1 TB hard disk provide a practical computing platform for compatible industrial applications. Dual Ethernet interfaces, serial ports, USB connections, and display outputs offer flexibility when integrating the computer with existing equipment.
Supplied without a preinstalled operating system, this configuration gives system integrators greater control over software selection and deployment. Its 19-inch, 4U format is suited to centralized installations in industrial control rooms and equipment racks.
For replacement projects and new installations, confirming the complete ordering code and regional configuration helps ensure the selected computer matches the intended application.
Technical Specifications
Parameter
Specification
Brand
Siemens
Product Family
SIMATIC IPC3000 Smart V3
Model Number
6AG4010-6EB50-0XX5
Product Type
Industrial Rack PC
Chassis Format
19-inch, 4U
Processor
Intel Core i7-6700
CPU Cores / Threads
4 / 4
Base Frequency
3.4 GHz
Maximum Turbo Frequency
4.0 GHz
CPU Cache
8 MB
Installed Memory
32 GB DDR4 SDRAM
Memory Configuration
2 × 16 GB
Storage
1 TB HDD
Ethernet
2 × LAN
Serial Interfaces
2 × serial interfaces
Serial Communication
RS-232 / RS-422 / RS-485 support
Front USB
2 ports
Rear USB
4 ports
Display Outputs
VGA and DisplayPort
Additional Interfaces
2 × PS/2, audio
Optical Drive
Not included
Power Supply
350 W
Operating System
Not included
Regional Configuration
China-market version
Dimensions (W × H × D)
Approx. 481 × 176 × 509 mm; confirm against the exact mechanical drawing
- Factory Automation and Equipment Control:The Siemens SIMATIC IPC3000 Smart V3 provides a centralized computing platform for industrial applications that require reliable processing and integration with automation equipment.
- SCADA and HMI Visualization:The Intel Core i7-6700 processor and 32 GB DDR4 memory support compatible supervisory control, operator-interface, and industrial visualization applications.
- Production Data Processing:The integrated 1 TB hard disk provides local storage for manufacturing records, application files, and operational data.
- PLC Communication and Network Integration:Dual Ethernet connections and serial interfaces support communication with compatible PLCs, industrial networks, and peripheral devices.
- Industrial Control Room Installations:The 19-inch, 4U rack-mount format suits centralized computing installations in control rooms, equipment racks, and industrial IT cabinets.
Key Strengths at a Glance
- Quad-Core Intel Processing:The Intel Core i7-6700 operates at a base frequency of 3.4 GHz and supports turbo frequencies up to 4.0 GHz, offering computing capacity for a variety of industrial workloads.
- 32 GB DDR4 Memory:The installed memory supports multitasking and applications that require substantial working memory.
- Broad Connectivity Options:Ethernet, serial, USB, VGA, and DisplayPort interfaces simplify integration with compatible industrial equipment and operator peripherals.
- 1 TB Local Storage:The hard disk provides space for application software, production data, and local records.
- Rack-Mount Installation:The 4U chassis supports organized integration into standard 19-inch equipment racks.
- Operating-System Flexibility:Supplied without a preinstalled operating system, this configuration allows integrators to select a compatible software environment based on application requirements.
Technical FAQs
1. Which processor is installed in the Siemens 6AG4010-6EB50-0XX5?
This configuration uses an Intel Core i7-6700 processor with four cores, four threads, a 3.4 GHz base frequency, a maximum turbo frequency of 4.0 GHz, and 8 MB of cache.
2. How much memory does this industrial rack PC provide?
The system is configured with 32 GB of DDR4 SDRAM, arranged as two 16 GB modules, supporting multitasking and compatible industrial applications.
3. Does the 6AG4010-6EB50-0XX5 include an operating system?
No. This ordering variant is supplied without a preinstalled operating system, allowing the integrator to select a compatible software environment.
4. Which network interfaces are available?
The computer provides two Ethernet LAN interfaces for communication with compatible industrial networks, PLCs, supervisory systems, and other networked devices.
5. Can the system communicate with RS-232 and RS-485 equipment?
Yes. The specified interface configuration includes serial connectivity supporting RS-232 and RS-422/RS-485 communication, depending on the port and device configuration.
6. Which display connections are supported?
The system provides VGA and DisplayPort outputs for compatible monitors and industrial operator displays.
7. Can this computer be used for SCADA and HMI applications?
Yes. Its processor, memory, and network connectivity make it suitable for compatible SCADA, HMI, visualization, and monitoring software, subject to operating-system requirements.
8. Can it communicate with Siemens SIMATIC PLCs?
Yes. It can operate as a supervisory or engineering computer connected to compatible SIMATIC PLCs through supported Ethernet or serial communication methods. The required software and protocols depend on the controller.
9. Does this configuration include a DVD drive?
No. The specified configuration does not include an optical drive. Supported USB media or network-based deployment can be used for software installation and maintenance.
10. What should be considered when deploying this model in an existing automation system?
Confirm software compatibility, communication protocols, driver availability, network settings, power requirements, and expansion needs. The model is designated for the Chinese market, so regional power-cable and support requirements should also be checked.
